I Founder's Vision For over 40 years Ancor has been the industry leader for quality tinned copper Marine Grade® wire and cable. Ancor’s comprehensive product line includes everything required to complete a wiring project. This includes Marine Grade® wire and cable, terminals and connectors, wire management products, and hand tools. Ancor designs products to the highest standards that meet UL, ABYC, NMMA and USCG standards. I Selection Over 1,500 electrical products are designed to work together as a system I Fast Delivery Products stocked in multiple global locations ensures rapid order fulfillment I Worldwide Access to Product A distribution network in over 45 countries provides access to products when they are needed I Information 24-hour access to product information, selection tools, and technical articles online at ancorproducts.com I Industry Standards Industry involvement ensures products meet ABYC, NMMA, and Coast Guard standards I Quality Product quality is managed in a manner consistent with international standards What makes Ancor different:
Wire & Cable Primary Wire 8 Battery Cable & Assemblies 10 Duplex Cable 12 Triplex Cable 13 Specialty Cable 14 Coax Cable & Assemblies 16 NMEA 2000 Cables & Connectors 18 Terminals & Lugs Adhesive Lined Heat Shrink Terminals 24 Nylon Insulated Terminals 27 Vinyl Insulated Terminals 29 Tinned Copper Lugs 30 Battery Terminals & Boots 32 Wire Management Adhesive Lined Heat Shrink Tubing 36 Adhesive Lined Heavy Wall Heat Shrink Tubing 37 Repair Tape 38 Electrical Tape 38 Cable Ties 39 Cable Clamps 43 Wire Seals 44 Grommets 44 Split Loom & Spiral Wrap 44 Wire Management Kits 45 p. 24 p. 8 p. 11 p. 13 p. 15 p. 18 p. 30 p. 31 p. 32 p. 27 p. 44 p. 39 p. 41 p. 40 p. 29 p. 37 p. 38 p. 36 p. 29 p. 44 p. 44 p. 43 p. 38 p. 16 p. 29 p. 32 p. 25 p. 26 Table of Contents
Tools & Testers Cut/Strip/Crimp Tools 48 Crimpers 50 Mini Fish Tape 51 Tool Kits 53 Heat Tools 52 Pliers & Screwdrivers 53 Digital Multimeters 54 Snap-Around Meters 55 Appendix & Index Technical Data 67 Part Number Index 72 Lighting Incandescent Bulbs 58 Miniature Halogen Bulbs 59 Festoon Bulbs 59 Medium Screw Base Bulbs 60 Fluorescent Tubes 60 Displays Display Racks 64 NMEA 2000 Planogram Assortment 66 p. 58 p. 60 p. 64 p. 59 p. 59 p. 58 p. 58 p. 48 p. 52 p. 52 p. 50 p. 50 p. 51 p. 65 p. 65 p. 66 p. 48 p. 53 p. 53 p. 51 p. 55 p. 49 p. 54 old NEW bug new NEW bug old NEW bug new NEW bug
Ancor offers a broad range of cable for specialty applications to meet all of your marine and mobile wiring needs. Specialty Cable WIRE & CABLE Manufactured from tinned copper stranding for maximum protection against corrosion and electrolysis. Ultra flexible (Type 3) stranding resists fatigue due to vibration and flexing. Primary Wire Premium, fine stranded UL1426 tinned copper battery cable for maximum conductivity and flexibility. All assemblies come with tinned copper lugs to avoid corrosion and extend life. Battery Cable & Assemblies Duplex and triplex wire in a variety of gauge and spool sizes; including UL 1426 tinned duplex boat cable in flat and round configurations. Multiconductor Cables 8 10 12 14
WIRE & CABLE Wire and cable are the backbone of every electrical system and properly selected wire will ensure a safe and reliable system. Ancor now carries NMEA 2000 cables and connectors for creating or expanding an NMEA 2000 network quickly and easily. Couplers are color coded to make identifying the power cable or connector easy. Premium quality. Universal fit. NMEA 2000 Cables & Connectors Premium tinned copper features signal loss ratios of up to 50% less than other coaxial cables. All assemblies come with Ancor adhesive lined heat shrink to seal out moisture, provide strain relief and fight corrosion. Coax Cable & Assemblies Made from our standard Ancor primary wire made specifically for trailer wiring. Assemblies with molded connectors for a wide range of applications. Trailer Cable & Assemblies 16 17 18
ancorproducts.com WIRE & CABLE 8 Ancor Marine Grade® Wire & Cable • Ancor Marine Grade® wire and cable is manufactured from tinned copper stranding for maximum protection against corrosion and electrolysis. Ultra flexible (Type 3) stranding resists fatigue due to vibration and flexing. • Ancor’s proprietary premium vinyl insulation stays flexible even in extreme cold (-40°F / -40°C) and resists salt water, battery acid, oil, gasoline and ultra-violet radiation. Exclusive insulation is rated at 600 volts, 221°F / 105°C dry and 167°F / 75°C wet, and is resistant to heat and abrasion. • Exceeds all UL 1426, US Coast Guard Charter boat (CFR Title 46) and ABYC standards. • See pages 67–71 for ABYC wiring guidelines and technical data. Primary Wire 18–14 AWG 18 AWG (0.8 mm2) Color Ft Part # Black 35 180003 100 100010 250 100025 500 100050 1000 100099 Red 35 180803 100 100810 250 100825 500 100850 1000 100899 Yellow 35 181003 100 101010 250 101025 500 101050 1000 101099 Green 35 180303 100 100310 250 100325 500 100350 1000 100399 White 35 180903 100 100910 250 100925 500 100950 1000 100999 Dk Blue 35 180103 100 100110 250 100125 500 100150 1000 100199 Brown 35 180203 100 100210 250 100225 500 100250A 1000 100299 Orange 35 180503 100 100510 250 100525 500 100550 1000 100599 Pink 35 180603 100 100610 250 100625 500 100650 1000 100699 18 AWG (0.8 mm2) Color Ft Part # Purple 35 180703 100 100710 250 100725 500 100750 1000 100799 Grey 35 180403 100 100410 250 100425 500 100450 1000 100499 16 AWG (1 mm2) Color Ft Part # Black 25 182003 100 102010 250 102025 500 102050 1000 102099 Red 25 182803 100 102810 250 102825 500 102850 1000 102899 Yellow 25 183003 100 103010 250 103025 500 103050 1000 103099 Green 25 182303 100 102310 250 102325AA 500 102350 1000 102399 White 25 182903 100 102910 250 102925 500 102950 1000 102999 Dk Blue 25 182103 100 102110 250 102125 500 102150 1000 102199 16 AWG (1 mm2) Color Ft Part # Brown 25 182203 100 102210 250 102225 500 102250 1000 102299 Orange 25 182503 100 102510 250 102525 500 102550 1000 102599 Pink 25 182603 100 102610 250 102625 500 102650 Purple 25 182703 100 102710 250 102725 500 102750 1000 102799 Grey 25 182403 100 102410 250 102425 500 102450 1000 102499 Tan 100 101810 250 101825 500 101850 Lt Blue 100 101910 250 101925 500 101950 14 AWG (2 mm2) Color Ft Part # Black 18 184003 100 104010 250 104025 500 104050 1000 104099 Red 18 184803 100 104810 250 104825 500 104850 1000 104899 14 AWG (2 mm2) Color Ft Part # Yellow 18 185003 100 105010 250 105025 500 105050 1000 105099 Green 18 184303 100 104310 250 104325 500 104350 1000 104399 White 18 184903 100 104910 250 104925 500 104950 1000 104999 Dk Blue 18 184103 100 104110 250 104125 500 104150 1000 104199 Brown 18 184203 100 104210 250 104225 500 104250 1000 104299 Orange 18 184503 100 104510 250 104525 500 104550 1000 104599 Pink 18 184603 100 104610 250 104625 500 104650 Purple 18 184703 100 104710 250 104725 500 104750 Grey 18 184403 100 104410 250 104425 500 104450 1000 104499 Tan 100 103810 250 103825 500 103850 Lt Blue 100 103910 250 103925 500 103950
ancorproducts.com WIRE & CABLE 9 12 AWG (3 mm2) Color Ft Part # Black 12 186003 25 106002 100 106010 250 106025 400 106040 1000 106099 Red 12 186803 25 106802 100 106810 250 106825 400 106840 1000 106899 Yellow 12 187003 25 107002 100 107010 250 107025 400 107040 1000 107099 Green 12 186303 25 106302 100 106310 250 106325 400 106340 1000 106399 White 12 186903 25 106902 100 106910 250 106925 400 106940 1000 106999 Dk Blue 25 106102 100 106110 250 106125 400 106140 1000 106199 Brown 25 106202 100 106210 250 106225 400 106240 1000 106299 Orange 25 106502 100 106510 250 106525 400 106540 1000 106599 Pink 25 106602 100 106610 250 106625 400 106640 Purple 25 106702 100 106710 250 106725 400 106740 Grey 1000 106499 Tan 100 105810 250 105825 400 105840 8 AWG (8 mm2) Color Ft Part # Black 25 111002 50 111005 100 111010 250 111025 500 111050 1000 111099 Red 25 111502 50 111505 100 111510 250 111525 500 111550 1000 111599 Yellow 25 111902 50 111905 100 111910 250 111925 500 111950 1000 111999 Green 25 111302 50 111305 100 111310 250 111325 500 111350 1000 111399 White 25 111702 50 111705 100 111710 250 111725 500 111750 1000 111799 6 AWG (13 mm2) Color Ft Part # Black 25 112002 50 112005 100 112010 250 112025 500 112050 750 112075 Red 25 112502 50 112505 100 112510 250 112525 500 112550 750 112575 Yellow 25 112902 50 112905 100 112910 250 112925 500 112950 750 112975 Green 25 112302 50 112305 100 112310 250 112325 500 112350 750 112375 White 25 112702 50 112705 100 112710 250 112725 500 112750 750 112775 Primary Wire 12–6 AWG Wire Flexibility Explained Wire flexibility is influenced by two major factors: wire strand size and jacket hardness. Wire strand size has the largest impact on overall wire flexibility. As individual wire strand size decreases, wire flexibility increases. For boat cable, UL 1426 requires at least 19 individual strands for cables 16 AWG and larger. Ancor wire uses type 3 stranding which consists of individual 30 AWG (0.010") strands, regardless of the wire gauge. Ancor’s 16 AWG wire consists of 26 individual strands, while the 4/0 AWG wire consists of 2,109 individual strands. Jacket hardness is most commonly measured by durometer, with lower measurements reflecting a more flexible material. Ancor wire measures 7 points lower than competitive product (on a scale of 1-100), resulting in a more flexible product. TECH TIP 10 AWG (5 mm2) Color Ft Part # Black 8 188003 25 108002 100 108010 250 108025 500 108050 1000 108099 Red 8 188803 25 108802 100 108810 250 108825 500 108850 1000 108899 Yellow 25 109002 100 109010 250 109025 500 109050 1000 109099 Green 25 108302 100 108310 250 108325 500 108350 1000 108399 White 25 108902 100 108910 250 108925 500 108950 1000 108999 Dk Blue 25 108102 100 108110 250 108125 500 108150 1000 108199 Brown 25 108202 100 108210 250 108225 500 108250 1000 108299 Orange 25 108502 100 108510 250 108525 500 108550 1000 108599 Grey 1000 108499 Green w/ Yellow Stripe 25 109302 100 109310 250 109325 500 109350 1000 109399
ancorproducts.com WIRE & CABLE 10 4 AWG (21 mm2) Color Ft Part # Black 25 113002 50 113005 100 113010 250 113025 500 113050 Red 25 113502 50 113505 100 113510 250 113525 500 113550 Yellow 25 113902 50 113905 100 113910 250 113925 500 113950 2 AWG (34 mm2) Color Ft Part # Black 25 114002 50 114005 100 114010 250 114025 400 114040 Red 25 114502 50 114505 100 114510 250 114525 400 114540 Yellow 25 114902 50 114905 100 114910 250 114925 400 114940 1 AWG (42 mm2) Color Ft Part # Black 25 115002 50 115005 100 115010 300 115030 Red 25 115502 50 115505 100 115510 300 115530 Yellow 25 115902 50 115905 100 115910 300 115930 1/0 AWG (53 mm2) Color Ft Part # Black 25 116002 50 116005 100 116010 250 116025 Red 25 116502 50 116505 100 116510 250 116525 Yellow 25 116902 50 116905 100 116910 250 116925 2/0 AWG (68 mm2) Color Ft Part # Black 25 117002 50 117005 100 117010 200 117020 Red 25 117502 50 117505 100 117510 200 117520 Yellow 25 117902 50 117905 100 117910 200 117920 3/0 AWG (85 mm2) Color Ft Part # Black 25 118002 50 118005 100 118010 150 118015 Red 25 118502 50 118505 100 118510 150 118515 Yellow 25 118902 50 118905 100 118910 150 118915 Battery Cable 4–4/0 AWG 4/0 AWG (107 mm2) Color Ft Part # Black 25 119002 50 119005 100 119010 250 119025 Red 25 119502 50 119505 100 119510 250 119525 Yellow 25 119902 50 119905 100 119910 250 119925 18–4/0 AWG Wire and Cable Specifications Wire Size Nominal O.D. Wire Diameter Minimum Bend Radius Stranding No. of 30 AWG Cir. Mil Area Ohms per 1000' mm2 Wt. per 1000' 18 AWG .08 mm2 7/64" 2.8 mm 1.0 mm 7/8" 2.3 cm 16 1600 6.48 .08 12 lbs 5.4 kg 16 AWG 1 mm2 1/8" 3.2 mm 1.5 mm 31/32" 2.5 cm 26 2600 4.00 1.31 16 lbs 7.3 kg 14 AWG 2 mm2 9/64" 3.6 mm 2.0 mm 1-3/32" 2.8 cm 41 4100 2.53 2.08 23 lbs 10.4 kg 12 AWG 3 mm2 5/32" 4.0 mm 2.6 mm 1-1/4" 3.2 cm 65 6500 1.75 3.31 31 lbs 14 kg 10 AWG 5 mm2 7/32" 5.6 mm 3.3 mm 1-29/64" 3.7 cm 105 10,500 1.00 5.26 44 lbs 20 kg 8 AWG 8 mm2 5/16" 7.9 mm 4.3 mm 2-1/32" 5.2 cm 168 16,800 0.62 8.37 86 lbs 39 kg 6 AWG 13 mm2 11/32" 8.7 mm 5.5 mm 2-35/64" 6.5 cm 266 26,600 0.40 13.30 118 lbs 53.5 kg 4 AWG 21 mm2 13/32" 10.3 mm 7.0 mm 3-3/32" 7.9 cm 420 42,000 0.24 21.15 178 lbs 81 kg 2 AWG 34 mm2 15/32" 11.9 mm 8.0 mm 3-1/2" 8.9 cm 665 66,500 0.16 33.62 277 lbs 126 kg 1 AWG 42 mm2 17/32" 13.5 mm 9.0 mm 4-9/64" 10.4 cm 836 83,690 0.13 42.38 350 lbs 159 kg 1/0 AWG 53 mm2 9/16" 14.3 mm 10.5 mm 4-1/2" 11.4 cm 1064 105,600 0.10 53.49 437 lbs 198 kg 2/0 AWG 68 mm2 5/8" 15.9 mm 12.0 mm 4-59/64" 12.4 cm 1330 133,000 0.08 67.43 549 lbs 249 kg 3/0 AWG 85 mm2 11/16" 17.5 mm 13.0 mm 5-23/64" 13.7 cm 1665 167,800 0.06 85.01 675 lbs 306 kg 4/0 AWG 107 mm2 13/16" 20.6 mm 14.0 mm 5-7/8" 15.0 cm 2109 211,600 0.05 107.20 837 lbs 380 kg Cutting & Crimping Tools pages 48–51 Related Products Heat Shrink Tubing page 36 Premium Electrical Tape page 38 Lugs page 30 Battery Terminals page 32
ancorproducts.com WIRE & CABLE 11 Premium Battery Cable Assemblies UL1426 Tinned Boat Cable • Premium, fine stranded UL 1426 tinned copper battery cable for maximum conductivity and flexibility • Flame retardant, UV inhibited cable rated at 600V and 221°F / 105°C • Tinned copper lugs to avoid corrosion and extend life • 3:1 heat shrink tubing over the electrical connection to seal out moisture and provide strain relief For continuous current draws up to: Use battery cable assemblies 136 amps 4 AWG 178 amps 2 AWG Color Length Stud Size Part # 4 AWG (21 mm2) Black 18" 45.7 cm 5/16" 7.93 mm 189130 32" 81.2 cm 5/16" 7.93 mm 189134 48" 121.9 cm 5/16" 7.93 mm 189136 Red 18" 45.7 cm 3/8" 9.5 mm 189131 32" 81.2 cm 3/8" 9.5 mm 189135 48" 121.9 cm 3/8" 9.5 mm 189137 Color Length Stud Size Part # 2 AWG (34 mm2) Black 18" 45.7 cm 5/16" 7.93 mm 189140 32" 81.2 cm 5/16" 7.93 mm 189144 48" 121.9 cm 5/16" 7.93 mm 189146 Red 18" 45.7 cm 3/8" 9.5 mm 189141 32" 81.2 cm 3/8" 9.5 mm 189145 48" 121.9 cm 3/8" 9.5 mm 189147
ancorproducts.com WIRE & CABLE 12 Safety Duplex Cable UL 1426 Tinned Boat Cable Conductor colors: red and yellow Spool Length Part # Nominal O.D. Wt. per 1000' 18/2 AWG (2x0.8 mm2) 100' 124910 3/16"x9/32" 5x7 mm 49 lbs 22.2 kg 250' 124925 500' 124950 1000' 124999 16/2 AWG (2x1 mm2) 25' 124702 3/16"x5/16" 5x8 mm 51 lbs 23.1 kg 100' 124710 250' 124725 500' 124750 1000' 124799 14/2 AWG (2x2 mm2) 25' 124502 7/32"x11/32" 6x9 mm 65 lbs 29.5 kg 100' 124510 250' 124525 500' 124550 1000' 124599 Spool Length Part # Nominal O.D. Wt. per 1000' 12/2 AWG (2x3 mm2) 25' 124302 7/32"x3/8" 6x10 mm 82 lbs 37.3 kg 100' 124310 250' 124325 500' 124350 10/2 AWG (2x5 mm2) 25' 124102 1/4"x15/32" 6x12 mm 128 lbs 58.2 kg 100' 124110 250' 124125 400' 124140 800' 124180 8/2 AWG (2x8 mm2) 50' 123905 11/32"x5/8" 9x16 mm 230 lbs 104.5 kg 100' 123910 500' 123950 6/2 AWG (2x13 mm2) 50' 123705 13/32"x3/4" 10x19 mm 364 lbs 165.5 kg 100' 123710 Flat Cable Spool Length Part # Nominal O.D. Wt. per 1000' 16/2 AWG (2x1 mm2) 100' 126710 5/16" 8 mm 49 lbs 22.2 kg 250' 126725 500' 126750 14/2 AWG (2x2 mm2) 100' 126510 11/32" 9 mm 63 lbs 28.6 kg 250' 126525 500' 126550 Spool Length Part # Nominal O.D. Wt. per 1000' 12/2 AWG (2x3 mm2) 100' 126310 13/32" 10 mm 80 lbs 36.3 kg 250' 126325 500' 126350 Round Cable Duplex Cable Conductor colors: black and red Spool Length Part # Nominal O.D. Wt. per 1000' 18/2 AWG (2x0.8 mm2) 100' 121910 3/16"x9/32" 5x7 mm 49 lbs 22.2 kg 250' 121925 500' 121950 16/2 AWG (2x1 mm2) 100' 121710 3/16"x5/16" 5x8 mm 51 lbs 23.1 kg 250' 121725 500' 121750 1000' 121799 14/2 AWG (2x2 mm2) 100' 121510 7/32"x11/32" 6x9 mm 65 lbs 29.5 kg 250' 121525 500' 121550 1000' 121599 Spool Length Part # Nominal O.D. Wt. per 1000' 12/2 AWG (2x3 mm2) 100' 121310 7/32"x3/8" 6x10 mm 82 lbs 37.3 kg 250' 121325 500' 121350 10/2 AWG (2x5 mm2) 100' 121110 1/4"x15/32" 6x12 mm 128 lbs 58.2 kg 250' 121125 400' 121140 800' 121180 8/2 AWG (2x8 mm2) 50' 120905 11/32"x5/8" 9x16 mm 230 lbs 104.5 kg 100' 120910 250' 120925 6/2 AWG (2x13 mm2) 50' 120705 13/32"x3/4" 10x19 mm 364 lbs 165.5 kg 100' 120710 Flat Cable
ancorproducts.com WIRE & CABLE 13 Triplex Cable Conductor colors: black, green and white Spool Length Part # Nominal O.D. Wt. per 1000' 16/3 AWG (3x1 mm2) 100' 131710 3/16"x15/32" 5x12 mm 75 lbs 34 kg 250' 131725 500' 131750 1000' 131799 14/3 AWG (3x2 mm2) 100' 131510 7/32"x1/2" 6x13 mm 96 lbs 43.6 kg 250' 131525 500' 131550 900' 131590 12/3 AWG (3x3 mm2) 25' 131302 7/32"x17/32" 6x14 mm 125 lbs 56.8 kg 100' 131310 250' 131325 700' 131370 Spool Length Part # Nominal O.D. Wt. per 1000' 16/3 AWG (3x1 mm2) 100' 133710 11/32" 9 mm 75 lbs 34 kg 250' 133725 14/3 AWG (3x2 mm2) 100' 133510 13/32" 10 mm 96 lbs 43.6 kg 250' 133525 900' 133590 Spool Length Part # Nominal O.D. Wt. per 1000' 10/3 AWG (3x5 mm2) 100' 131110 1/4"x21/32" 6x17 mm 186 lbs 84.5 kg 300' 131130 500' 131150 8/3 AWG (3x8 mm2) 25' 130902 3/8"x1" 10x25 mm 287 lbs 130.4 kg 50' 130905 100' 130910 6/3 AWG (3x13 mm2) 50' 130705 7/16"x1-3/16" 11x30 mm 470 lbs 213.6 kg 100' 130710 Spool Length Part # Nominal O.D. Wt. per 1000' 12/3 AWG (3x3 mm2) 100' 133310 7/16" 11 mm 125 lbs 56.8 kg 250' 133325 Round Cable Flat Cable Related Products Cutting & Stripping Tools pages 49–51 Wire Seals page 44 Round versus Flat Duplex/Triplex Duplex and triplex cable have many different advantages to help installers. The grouped wires save time and effort by having to run only one group instead of multiple individual wires and also provides extra protection for the wire itself. But they have different advantages based on the shape too. Round cable for instance is easier to install through bulk heads, walls, panels or holes, while flat cable is easier to route long distances since it can be moved through a smaller space. Flat Cable Round Cable Triplex Duplex TECH TIP
ancorproducts.com WIRE & CABLE 14 Signal Cable Tinned Boat Cable Conductor colors: red and black Spool Length Part # Nominal O.D. Wt. per 1000' 20/2 AWG (2x0.5 mm2) 25' 189303 5/32"x1/4" 4x6.4 mm 18 lbs 8.1 kg 100' 122010 250' 122025 500' 122050 Twisted Pairs w/ Shield Premium Tinned Copper Color conductors: red and black • For all metal boats and around sensitive electronics • 93% tinned copper shield for maximum EMI and RFI rejection • 2-3" lay for interference cancellation Spool Length Part # Nominal O.D. Wt. per 1000' 14/2 AWG (2x2 mm2) 100' 141410 .330" 8.4 mm 73.2 lbs 33.3 kg 250' 141425 Spool Length Part # Nominal O.D. Wt. per 1000' 20/3 AWG (3x0.5 mm2) 100' 153010 7/32" 5.6 mm 30 lbs 13.6 kg 500' 153050 Round Instrument Cable 100% Mylar Foil Shield & Drain Wire UL 1426 Tinned Boat Cable Color conductors: red, black and bare Spool Length Part # Nominal O.D. Wt. per 1000' 16/2 AWG (2x1 mm2) 100' 153110 1/8"x1/4" 3.2x6.4 mm 32 lbs 14.5 kg 250' 153125 500' 153150 Flat Ribbon Bonded Cable Premium Tinned Bonded Copper Conductor colors: red and black Specialty Cable Round Signal 100% Mylar Foil Shield and Drain Tinned Boat Cable Conductor colors: black, red, green, blue, brown, orange, purple and yellow Spool Length Part # Nominal O.D. Wt. per 1000' 20/8 AWG (8x0.5 mm2) 100' 158010 5/16" 7.9 mm 63 lbs 28.6 kg 250' 158025 Spool Length Part # Nominal O.D. Wt. per 1000' 14/5 AWG (5x2 mm2) 100' 155010 1/2" 12.7 mm 160 lbs 79.5 kg 500' 155050 Round Mast UL 1426 Tinned Boat Cable Color conductors: black, blue, green, brown and red Spool Length Part # Nominal O.D. Wt. per 1000' 8/2 AWG (2x8 mm2) 25' 121802 5/8"x5/16" 15.9x7.9 mm 172 lbs 78.0 kg 100' 121810 250' 121825 6/2 AWG (2x13 mm2) 25' 121602A 11/16"x11/32" 17.5x8.7 mm 236 lbs 107.0 kg 100' 121610 250' 121625 Bonded Cable Tinned Copper Color conductors: red and black
ancorproducts.com WIRE & CABLE 15 Spool Length Part # Nominal O.D. Wt. per 1000' 16/3 AWG (3x1 mm2) 100' 156610 .348" 8.85 mm 78 lbs 35.5 kg 250' 156625 14/3 AWG (3x2 mm2) 100' 156410 .377" 9.6 mm 99 lbs 45.0 kg 250' 156425 500' 156450 Bilge Pump Cable Premium Tinned Copper Color conductors: black, brown and red Insulation: grey • Conductors specifically for bilge pumps • Oil resistant • SJTOW-A water resistant jacket Spool Length Part # Nominal O.D. Wt. per 1000' 18/2 AWG (2x0.8 mm2) 100' 142810 .265" 6.7 mm 29 lbs 13 kg 16/2 AWG (2x1 mm2) 100' 142610 .319" 8.1 mm 51 lbs 23.1 kg 250' 142625 500' 142650 14/2 AWG (2x2 mm2) 100' 142410 .345" 8.8 mm 65 lbs 29.5 kg 250' 142425 1000' 142499 Super Flex Audio Cable Premium Tinned Copper • Super flexible, easy to run • Clear jacket to blend into the environment • Drawn copper, unidirectional lay for ultimate in sound quality • Tinned copper for corrosion resistance in the marine environment Spool Length Part # Nominal O.D. Wt. per 1000' 14 AWG (2 mm2) 25' 150102 1/4" 6.4 mm 38 lbs 17.2 kg 100' 150110 GTO 15 High Voltage Cable (15000V) Color conductors: white • Coupler output to antenna Spool Length Part # Nominal O.D. Wt. per 1000' 18/4 AWG (4x0.08 mm2) 100' 160010 3/32"x3/8" 2.3x9.3 mm 48 lbs 21.8 kg 1000' 160099 16/4 AWG (4x1 mm2) 100' 160110 1/8"x15/32" 2.6x10.5 mm 64 lbs 29.0 kg 1000' 160199 14/4 AWG (4x2 mm2) 100' 160210 7/64"x15/32" 3.0x11.9 mm 92 lbs 41.7 kg 1000' 160299 Flat Ribbon Bonded RGB Cable Tinned Copper Conductor colors: red, light blue, green, and white Spool Length Part # Nominal O.D. Wt. per 1000' 18/4 AWG (4x0.08 mm2) + 16/2 AWG (2x1 mm2) 25' 170002 .352" 8.9 mm 69.9 lbs 31.7 kg 100' 170010 250' 170025 RGB + Speaker Cable Tinned Copper 18 AWG conductors for RGB lighting: yellow, red, blue, green 16 AWG conductors for speaker connections: black and red • Saves time by running only one cable • Meets ABYC standards
ancorproducts.com WIRE & CABLE 16 Coaxial Cable Premium Tinned Copper • Features signal loss ratios of up to 50% less than other coaxial cables • Tinned copper center conductor as well as tinned copper outer braid for corrosion resistance and easy soldering • 96% braid for best signal strength and least interference with UV inhibited white jacket for longest life Spool Length Part # Nominal O.D. Wt. per 1000' RG 58CU 100' 150510 3/16" 4.8 mm 26 lbs 11.8 kg 250' 150525 RG 59U 250' 151025 1/4" 6.4 mm 36 lbs 16.3 kg 500' 151050 RG 8X 100' 151510 1/4" 6.4 mm 40 lbs 18.1 kg 250' 151525 500' 151550 1000' 151560 RG 213 100' 151710 13/32" 10.3 mm 110 lbs 50 kg 250' 151725 500' 151750 Coaxial Cable Assemblies Premium Tinned Copper • All assemblies come with Ancor adhesive lined heat shrink to seal out moisture, provide strain relief and fight corrosion • 96% tinned copper braid for optimum protection against signal loss • 100% tinned copper center conductor and braid • No solder or special tools required • Special low loss SAT NAV extensions Wire Type RG58C/U RG59U RG8X RG213 Insulation Material PVC* PVC PVC PVC* Nominal O.D. 3/16" 4.8 mm 1/4" 6.4 mm 1/4" 6.4 mm 13/32" 10.3 mm AWG 20 23 16 13 Conductor Stranding 19/33 Solid** 19/29 7/21 Braid Coverage 96% 96% 96% 96% Wt. per 1000' 26 lbs 11.8 kg 36 lbs 16.3 kg 40 lbs 18.1 kg 110 lbs 50 kg Impedance (Ohms) 50 75 50 50 Capacitance/Ft. 30.8 pF 20.5 pF 26.0 pF 30.8pF Attenuation/100' @50MHz 3.3db 2.4db 2.5db 1.3db @100MHz 4.9db 3.4db 3.7db 1.9db @1000MHz 21.5db 12.0db 13.5db 8.0db Velocity of Propagation 66% 66% 78% 66% * non-contaminating insulation ** copperweld Ends Description Wire Length Part # RG58CU Two ends assembled 3' 189800 RG8X One end assembled 50' 189849 Coaxial Cable & Assemblies Shore Power Cord Conductor colors: black, white, green (and red 100319 only) • High visibility yellow jacket is weather and sunlight resistant • Ultra flexible insulation is abrasion resistant for “hard service” applications • 600 volt rated for extra heavy-duty service • 16/3 is 300 volt cable • Temp rating: 140°F / 60°C Spool Length Part # Nominal O.D. Wt. per 1000' 10/3 STOW 100' 153710 21/32" 17 mm 284 lbs 129 kg 250' 153725 10/3 STW 250' SPC103 21/32" 17 mm 284 lbs 129 kg Spool Length Part # Nominal O.D. Wt. per 1000' 6/3 STW per/ft** 100320F 31/32" 24.4 mm 540 lbs 254.4 kg 6/4 STW per/ft** 100319F 1-5/64" 27.4 mm 695 lbs 316 kg SPC103, 100320F and 100319F are not tinned wire **50 ft minimum Ancor Recommends • RG 58CU for interconnecting electronic equipment • RG 59U for TVs and some SAT NAVs • RG 213 for VHF runs more than 50 feet • RG 8X for VHF runs less than 50 feet TECH TIP
ancorproducts.com WIRE & CABLE 17 Trailer Assemblies • Molded trailer connectors are made with 16 gauge wire • Color coding in accordance with SAE recommended practices • Male Connector = Trailer Side / Female Connector = Vehicle Side • 4-contact connectors are molded with an EasyGrip® for fast and easy disconnect • Loops can be cut to the desired length for splicing into an existing wire assembly 2-wire length style part # 12" loop 249102 male female male female 4-wire length style part # 12" loop 249101 Flat Trailer Cable Tinned Boat Cable Conductor colors: yellow, white, green, and brown Spool Length Part # Nominal O.D. Wt. per 1000' 16/4 AWG (4x1 mm2) 100' 154010 3/16"x9/16" 4x14 mm 105 lbs 47.7 kg 300' 154030 Spool Length Part # Nominal O.D. Wt. per 1000' 16/4 AWG (4x1 mm2) 100' 154510 1/8"x1/2" 3.2x12.7 mm 29.2 lbs 13.2 kg 250' 154525 Flat Ribbon Bonded Trailer Cable Premium Tinned Bonded Copper Conductor colors: brown, green, white, and yellow Trailer Cable & Assemblies
ancorproducts.com WIRE & CABLE 18 NMEA 2000® Cables and Connectors Premium Quality. Universal Fit. Ancor NMEA 2000 approved cables and connectors simplify creating or expanding an NMEA 2000 network. Couplers are color coded to make identifying the power cable or connector easy once installed as part of an NMEA 2000 network. The color coded couplers connect to the corresponding Ancor cables and connectors creating an easy to identify network. • NMEA 2000 Approved, 100% universal and compatible with other manufacturers’ products • NMEA micro-size NMEA 2000 Power Cable With Tee For power connection to an NMEA 2000 network. The tee is color coded red to make identifying the power cable easy once installed as part of an NMEA 2000 network. The yellow couplers connect to the corresponding Ancor backbone cables and tees creating a simplified, color coded network installation. • Includes a tee for direct connection to backbone cables • Large 18 AWG power conductors to reduce voltage drop, provide better reliability and meet the requirements of ABYC and the USCG for minimum size power conductors Part # 270000 3.3 ft 1 m NMEA 2000 Drop Cables For connection between an NMEA 2000 device and tee connector. The black couplers connect to the corresponding Ancor tees creating a simplified, color coded network installation. The drop cables are smaller in diameter and more flexible than backbone cables for easy connection to NMEA 2000 devices. • Super flexible 22 AWG power conductors for ease of installation and wire routing Part # 270300 1.6 ft .5 m Part # 270301 3.3 ft 1 m Part # 270302 6.5 ft 2 m Part # 270305 16 ft 5 m NMEA 2000 Backbone Cables For connection to an NMEA 2000 tee connector. The yellow couplers connect to the corresponding Ancor tees creating a simplified, color coded network installation. • Large 18 AWG power conductors to reduce voltage drop and provide better reliability for critical backbone cables Part # 270001 1.6 ft .5 m Part # 270002 6.5 ft 2 m Part # 270005 16 ft 5 m Part # 270010 32 ft 10 m 270001 Ancor NMEA 2000 Color Key: = power connection = backbone connection = drop connection = power isolation = inline termination APPROVED APPROVED APPROVED 270000 270300 Backbone Cables: - yellow coupler - low loss cable Drop Cables: - black coupler - slim, flexible cable Backbone vs Drop Cables
ancorproducts.com WIRE & CABLE 19 NMEA 2000 Tee Connectors For connection between NMEA 2000 drop cables and backbone cables. The yellow couplers connect to the corresponding Ancor tees and backbone cables, creating a simplified, color coded network installation. The connectors are offered in four configurations for maximum installation flexibility. The two way and four way tee connectors allow for multiple drop cables to be connected without additional backbone cable. Part # 270101 Single Tee Connector Part # 270103 2 Way Tee Connector Part # 270104 4 Way Tee Connector APPROVED 270103 270104 NMEA 2000 90° Elbow Connector Makes cable routing easier. The connector is installed between two cables to reduce stress on the cables and create a compact installation. Part # 270108 APPROVED NMEA 2000 Power Isolator Isolating power within a NMEA 2000 network. The power isolator connects between NMEA 2000 tees and backbone cables while isolating the power supply within the network. Part # 270113 NMEA 2000 Inline Terminator For proper termination of a network in a single piece, space saving design. The inline terminator connects between a backbone cable and a drop cable, while still maintaining proper termination for the end of the network. Part # 270114 NMEA 2000 Blanking Caps Cover unused couplers. Protects unused tee connectors from dust and water. 2-pack. Part # 270111 Female Part # 270112 Male NMEA 2000 Through Bulkhead Adaptor Use for transitions through bulk heads or panels. Simplifies installation when routing through a waterproof bulkhead or panel. Creates a connectoin point for removable equipment such as a computer interface. Part # 270107 NMEA 2000 Field Serviceable Connectors For termination of bare NMEA cable. Securely terminate bulk cable, or replace a broken end. Part # 270109 Female Part # 270110 Male 270109 270110 NMEA 2000 Terminators For proper termination of an NMEA 2000 network. The yellow couplers connect to the corresponding Ancor tees, creating a simplified, color coded network installation. One male and one female terminator is required for each NMEA 2000 network. Part # 270105 Female Part # 270106 Male APPROVED 270105 270106 270101 270111 270112
ancorproducts.com WIRE & CABLE 20 NMEA 2000 Starter Kits NMEA 2000 Single Device Starter Kit Kit include all components needed to create a single device NMEA 2000 network. Kit includes: • (1) Power Cable with Tee, 3.3 ft (1m), part # 270000 • (1) Male Terminator, part # 270106 • (1) Female Terminator, part # 270105 • (1) Single Tee Connector, part # 270101 • (1) Drop Cable, 6.5 ft (2m), part # 270302 Part # 270201 APPROVED NMEA 2000 Dual Device Starter Kit Kit include all components needed to create a dual device NMEA 2000 network. Kit includes: • (1) Power Cable with Tee, 3.3 ft (1m), part # 270000 • (1) Male Terminator, part # 270106 • (1) Female Terminator, part # 270105 • (1) Dual Tee Connector, part # 270103 • (2) Drop Cable, 6.5 ft (2m), part # 270302 Part # 270202 APPROVED 270000 Power Tee 270106 Male Terminator 270106 Male Terminator 270105 Female Terminator 270105 Female Terminator 270302 Drop Cable 270302 Drop Cables 270101 Single Tee 270103 Dual Tee 270000 Power Tee
ancorproducts.com WIRE & CABLE 21 NMEA 2000 Single Device Backbone Starter Kit Basic starter kit for adding a new NMEA 2000 network to your boat. Kit includes: • (1) Power Cable with Tee, 3.3 ft (1m), part # 270000 • (1) Male Terminator, part # 270106 • (1) Female Terminator, part # 270105 • (1) Single Tee Connector, part # 270101 • (1) Drop Cable, 1.64 ft (.5m), part # 270300 • (1) Backbone Cable, 16.4 ft (5m), part # 270005 Part # 270203 APPROVED 270106 Male Terminator 270005 Backbone Cable 270105 Female Terminator 270302 Drop Cable 270101 Single Tee 270000 Power Tee Approved vs Certified NMEA Components—cables and connectors must pass NMEA approval to guarantee that they are manufactured to standards which allow them to be universally used with any manufacturers approved components and certified devices. NMEA Devices—must be certified to run the universal NMEA 2000 communications protocols to be used universally between different manufacturers devices. TECH TIP
TERMINALS & LUGS Includes a heat activated adhesive built into the sleeve of the tubing for improved seal and strain relief. Adhesive Lined Heat Shrink Terminals Marine Grade® Nylon terminals are designed for harsh boating applications. Nylon insulators are ideal for crimping and will not split. Ideal for non-waterproof applications. Vinyl Insulated Terminals Nylon Insulated Terminals 29 27 24
TERMINALS & LUGS Electrical systems rely on Ancor terminals and lugs to securely connect a vessels' electrical system so current-carrying loads swiftly move from the source of power to the loads. Use with larger gauge cable for proper connection. Ancor Marine Grade® lugs are made from heavy-duty annealed tinned copper for maximum current flow and corrosion resistance. Heavy-duty Butt Connectors Tinned Copper Lugs Provides proper connections to batteries for maximum conductivity. Battery Terminals, Covers & Clips 32 30 30
TERMINALS & LUGS 24 ancorproducts.com Adhesive Lined Heat Shrink Terminals • Heat activated adhesive built into the sleeve of the heat shrink tubing • Shrinks to form a water tight seal and ultimate vibration and strain relief • Tinned for corrosion resistance • Pure copper for maximum current flow • Brazed seam for maximum strength • UL listed and CSA recognized • Shrinks at 275°F / 135°C AWG Gender Qty/ Pkg Part # 22–18 0.3–0.8 mm2 Female 3 318803 25 318825 100 318899 Male 3 318903 25 318925 100 318999 16–14 1–2 mm2 Female 3 319803 25 319825 100 319899 Male 3 319903 25 319925 100 319999 Heat Shrink Snap Plugs Heat Shrink Spade Terminals • UL 486A AWG Screw Size Qty/ Pkg Part # 22–18 0.3–0.8 mm2 #8 4 mm 3 313203 25 313225 100 313299 16–14 1–2 mm2 #8 4 mm 3 314203 25 314225 100 314299 #10 4.8 mm 3 314303 25 314325 100 314399 12–10 3–5 mm2 #8 4 mm 3 315203 25 315225 100 315299 #10 4.8 mm 3 315303 25 315325 100 315399 AWG Screw Size Qty/ Pkg Part # 22–18 0.3–0.8 mm2 #8 4 mm 3 310203 25 310225 100 310299 #10 4.8 mm 3 310303 25 310325 100 310399 1/4" 6.4 mm 3 310403 25 310425 100 310499 5/16" 7.9 mm 3 310503 25 310525 100 310599 3/8" 9.5 mm 3 310603 25 310625 100 310699 16–14 1–2 mm2 #8 4 mm 3 311203 25 311225 100 311299 #10 4.8 mm 3 311303 25 311325 100 311399 1/4" 6.4 mm 3 311403 25 311425 100 311499 5/16" 7.9 mm 3 311503 25 311525 100 311599 3/8" 9.5 mm 3 311603 25 311625 100 311699 Heat Shrink Ring Terminals • UL 486A AWG Screw Size Qty/ Pkg Part # 12–10 3–5 mm2 #8 4 mm 3 312203 25 312225 100 312299 #10 4.8 mm 3 312303 25 312325 100 312399 1/4" 6.4 mm 3 312403 25 312425 100 312499 5/16" 7.9 mm 3 312503 25 312525 100 312599 3/8" 9.5 mm 3 312603 25 312625 100 312699 8 8 mm2 #10 4.8 mm 3 321303 25 321325 1/4" 6.4 mm 3 321403 25 321425 5/16" 7.9 mm 3 321503 25 321525 3/8" 9.5 mm 3 321603 25 321625 1/2" 12.7mm 3 321703 25 321725 Related Products Crimping Tools pages 49–51 Heat Tools page 52
TERMINALS & LUGS 25 ancorproducts.com Heat Shrink Step-Down/Multi-Wire Connectors • 4:1 shrink ratio tubing to ensure a watertight seal between wires • Flared barrel with uniform copper wall ensures an easy and proper mechanical crimp • Crimp indicator on barrel for proper placement of installation tool • Clear heat shrink tubing ensures crimp accuracy • Colored stripes on the barrel indicate which crimp die to use, regardless of application AWG Tubing Color Pkg Qty Part # Barrel End 1 Barrel End 2 24–22 0.2–0.3 mm2 Clear tube w/ white dashes 3 320003 (1) 24-22 AWG (1) 22-18 AWG or (2) 24-22 AWG 25 320025 22–18 0.3–0.8 mm2 Clear tube w/ red dashes 3 320103 (1) 22-18 AWG (1) 16-14 AWG or (2) 22-18 AWG 25 320125 16–14 1–2 mm2 Clear tube w/ blue dashes 3 320203 (1) 16-14 AWG (1) 12-10 AWG or (2) 16-14 AWG 25 320225 12–10 3–5 mm2 Clear tube w/ yellow dashes 3 320303 (1) 12-10 AWG (1) 8 AWG or (2) 12-10 AWG 25 320325 OR 16–14 AWG Step-Down Connector Example (2) 16–14 AWG (1) 12–10 AWG (1) 16–14 AWG (1) 16–14 AWG Related Products Crimping Tools pages 49–51 Heat Tools page 52 Kit AWG Qty/ Pkg Pkg Part # Assorted (5) 24–22 AWG, (10) 22–18 AWG, (10) 16–14 AWG, (5) 12–10 AWG 30 jar 320000 320000 AWG Qty/ Pkg Pkg Part # 22–18 0.3–0.8 mm2 250 jar 309001 16–14 1–2 mm2 250 jar 309101 12–10 3–5 mm2 200 jar 309201 Assorted (50) 22-18, (150) 16-14, (50) 12-10 AWG 250 jar 309000 Assorted (25) each 75 case 220011 Assorted (10) 22-18, (20) 16-14, (10) 12-10 AWG 40 clam 220012 Heat Shrink Butt Connector Packs • Reusable jar is clear for easy identification and has a flip lid for ease of use • Reusable compact case (6.625"L x 3.125"W x 1.375"D) fits easily in most storage areas 220011 309000 AWG Qty/ Pkg Part # 22–18 0.3–0.8 mm2 3 309003 25 309025 100 309099 500 309002 16–14 1–2 mm2 3 309103 25 309125 100 309199 500 309102 12–10 3–5 mm2 3 309203 25 309225 100 309299 500 309202 8 8 mm2 3 309303 25 309325 500 309302 Heat Shrink Butt Connectors • UL 486C
TERMINALS & LUGS 26 ancorproducts.com Related Products Crimping Tools pages 49–51 Heat Tools page 52 6 pc Kits include: • (2) .250 tab (2) .187 tab (2) .110 tab 90 pc Kit includes: • 22–18 AWG: (10) .110 tab (10) .187 tab (10) .250 tab • 16–14 AWG: (20) .110 tab (20) .187 tab (20) .250 tab • Reusable compact case Universal Speaker Connector Kits Ancor’s universal speaker connector kits include all the connectors required to install speakers regardless of manufacturer. Heat shrink disconnects provide a sealed connection for the harsh marine environment. AWG Qty/ Pkg Pkg Part # 22–18 0.3–0.8 mm2 6 clam SPK2218 16–14 1–2 mm2 6 clam SPK1614 AWG Qty/ Pkg Pkg Part # Assorted 90 case SPKKIT SPK2218 SPK1614 SPKKIT AWG Tab Size Gender Qty/ Pkg Part # 22–18 0.3–0.8 mm2 .110 Female 100 326899 .187 Female 100 336899 .250 Female 3 316803 25 316825 100 316899 .250 Male 3 316903 25 316925 100 316999 16–14 1–2 mm2 .110 Female 100 327899 .187 Female 100 337899 .250 Female 3 317803 25 317825 100 317899 .250 Male 3 317903 25 317925 100 317999 12–10 3–5 mm2 .250 Female 3 320803 25 320825 100 320899 .250 Male 3 320903 25 320925 100 320999 Heat Shrink Disconnects Heat Shrink Flag Disconnects • 90° angle simplifies wire routing and connections • .250 (6.4mm) tab size AWG Gender Qty/ Pkg Part # 22–18 0.3–0.8 mm2 Female 3 356803 25 356825 16–14 1–2 mm2 Female 3 357803 25 357825
TERMINALS & LUGS 27 ancorproducts.com AWG Screw Size Qty/ Pkg Part # 22–18 0.3–0.8 mm2 #6 3.6 mm 6 230201 25 210201 #8 4 mm 6 230202 25 210202 100 220202 #10 4.8 mm 6 230203 25 210203 100 220203 1/4" 6.4 mm 5 230204 25 210204 5/16" 7.9 mm 5 230205 25 210205 3/8" 9.5 mm 5 230206 25 210206 16–14 1–2 mm2 #6 3.6 mm 6 230211 25 210211 #8 4 mm 6 230212 25 210212 100 220212 #10 4.8 mm 6 230213 25 210213 100 220213 500 222213 1/4" 6.4 mm 5 230214 25 210214 100 220214 5/16" 7.9 mm 5 230215 25 210215 100 220215 3/8" 9.5 mm 5 230216 25 210216 100 220216 AWG Screw Size Qty/ Pkg Part # 12–10 3–5 mm2 #6 3.6 mm 5 230221 25 210221 #8 4 mm 5 230222 25 210222 100 220222 #10 4.8 mm 5 230223 25 210223 100 220223 1/4" 6.4 mm 4 230224 25 210224 100 220224 5/16" 7.9 mm 4 230225 25 210225 100 220225 3/8" 9.5 mm 4 230226 25 210226 100 220226 1/2" 12.7mm 3 230227 25 210227 8 8 mm2 #10 4.8 mm 2 230233 25 210233 100 222233 1/4" 6.4 mm 2 230234 25 210234 100 222234 5/16" 7.9 mm 2 230235 25 210235 100 222235 3/8" 9.5 mm 2 230236 25 210236 100 222236 1/2" 12.7mm 1 230237 25 210237 AWG Screw Size Qty/ Pkg Part # 6 13 mm2 #10 4.8 mm 1 230243 25 210243 1/4" 6.4 mm 1 230244 25 210244 5/16" 7.9 mm 1 230245 25 210245 3/8" 9.5 mm 1 230246 25 210246 1/2" 12.7mm 1 230247 25 210247 Nylon Ring Terminals • Nylon insulated with insulation grip • Double crimp, funnel entry • UL 486A Marine Grade® Terminals • Ancor’s Marine Grade® terminals differ from automotive terminals by being designed for the harsh marine environment • Tinned copper gives the least electrical resistance but the most corrosion protection • Nylon insulators are easy to crimp and will not split • Barrels are designed to tightly grip the wire with the least effort Related Products Crimping Tools pages 49–51
TERMINALS & LUGS 28 ancorproducts.com AWG Screw Size Qty/ Pkg Part # 22–18 0.3–0.8 mm2 #6 3.6 mm 6 230301 25 210301 #8 4 mm 6 230302 25 210302 #10 4.8 mm 6 230303 25 210303 16–14 1–2 mm2 #6 3.6 mm 6 230311 25 210311 #8 4 mm 6 230312 25 210312 100 220312 #10 4.8 mm 6 230313 25 210313 100 220313 12–10 3–5 mm2 #8 4 mm 5 230322 25 210322 #10 4.8 mm 5 230323 25 210323 100 220323 Nylon Flanged Spades • Nylon insulated with insulation grip • Double crimp, funnel entry • UL 486A AWG Gender Qty/ Pkg Part # 22–18 0.3–0.8 mm2 Female 4 231408 25 211408 100 221408 Male 4 231409 25 211409 100 221409 16–14 1–2 mm2 Female 4 231418 25 211418 100 221418 Male 4 231419 25 211419 100 221419 12–10 3–5 mm2 Female 3 231428 25 211428 100 221428 Male 3 231429 25 211429 100 221429 Nylon Fully Insulated Disconnects • .250 (6.4 mm) tab size • Nylon insulated with insulation grip • Double crimp, funnel entry • UL 310 AWG Gender Qty/ Pkg Part # 22–18 0.3–0.8 mm2 Female 4 230808 25 210808 100 220808 Male 4 230809 25 210809 100 220809 16–14 1–2 mm2 Female 4 230818 25 210818 100 220818 Male 4 230819 25 210819 100 220819 12–10 3–5 mm2 Female 3 230828 25 210828 100 220828 Male 3 230829 25 210829 100 220829 Nylon Disconnects • .250 (6.4 mm) tab size • Nylon insulated with insulation grip • Double crimp, funnel entry • UL 310 AWG Qty/ Pkg Part # 22–18 0.3–0.8 mm2 7 230100 25 210100 100 220100 500 222100 16–14 1–2 mm2 7 230110 25 210110 100 220110 500 222110 12–10 3–5 mm2 5 230120 25 210120 100 220120 500 222120 Nylon Single Crimp Butt Connectors • Nylon insulated seamless • UL 486C AWG Qty/ Pkg Part # 22–18 0.3–0.8 mm2 3 230161 25 210161 100 220161 500 222161 16–14 1–2 mm2 3 230162 25 210162 100 220162 500 222162 12–10 3–5 mm2 2 230163 25 210163 100 220163 500 222163 Nylon Double Crimp Butt Connectors • Nylon insulated with insulation grip • Funnel entry • UL 486C AWG Gender Qty/ Pkg Part # 22–18 0.3–0.8 mm2 Female 4 231601 25 211601 16–14 1–2 mm2 Female 4 231611 25 211611 12–10 3–5 mm2 Female 3 231621 25 211621 Nylon Flag Disconnects • .250 (6.4 mm) tab size • Nylon insulated with insulation grip
TERMINALS & LUGS 29 ancorproducts.com Vinyl Step Down Butt Connectors • Vinyl insulated • UL 486C AWG Qty/ Pkg Part # 8 8 mm2 2 230130 25 210130 6 13 mm2 1 230140 25 210140 4 21 mm2 1 230150 25 210150 Vinyl Butt Connectors • Vinyl insulated • UL 486C Qty/ Pkg Part # 5 230613 25 210613 Double Male-Female Adapter • .250 (6.4mm) tab size AWG Gender Qty/ Pkg Part # 22–18 0.3–0.8 mm2 Female 4 230709 25 210709 Male 4 230708 25 210708 16–14 1–2 mm2 Female 4 230719 25 210719 100 220719 Male 4 230718 25 210718 100 220718 Nylon Snap Plugs • Nylon insulated with insulation grip • Double crimp, funnel entry AWG Qty/ Pkg Part # 16–14 to 22–18 1–2 to 0.3–0.8 mm2 3 230164 25 210164 12–10 to 16–14 3–5 to 1–2 mm2 3 230165 25 210165 8 to 12–10 8 to 3–5 mm2 3 230166 25 210166 Related Products Crimping Tools pages 49–51 AWG Qty/ Pkg Part # 16–14 1–2 mm2 1 230510 25 210510 12–10 3–5 mm2 1 230520 25 210520 Nylon 3-Way Connectors • Nylon insulated with insulation grip • Double crimp, funnel entry AWG Qty/ Pkg Part # 22–18 0.3–0.8 mm2 3 230602 25 210602A 100 220602 16–14 1–2 mm2 3 230612 25 210612 100 220612 12–10 3–5 mm2 3 230622 25 210622 100 220622 Nylon Multi-Stack Connectors • .250 (6.4mm) tab size • Nylon insulated with insulation grip • Double crimp, funnel entry • UL 310
TERMINALS & LUGS 30 ancorproducts.com Tinned Copper Lugs • Ancor Marine Grade® lugs are manufactured from heavy-duty annealed tinned copper, providing for maximum current flow • 100% tin plated copper resists corrosion from salt and moisture • Seamless barrel design allows for maximum strength when crimped • Closed end design seals out moisture so cables stay dry and corrosion free • UL 486A AWG Screw Size Qty/ Pkg Part # 8 8 mm2 #10 4.8 mm 2 252233 25 242233 100 244233 1/4" 6.4 mm 2 252234 25 242234 100 244234 5/16" 7.9 mm 2 252235 25 242235 100 244235 3/8" 9.5 mm 2 252236 25 242236 100 244236 1/2" 12.7 mm 2 252237 10 242237 6 13 mm2 #10 4.8 mm 2 252243 25 242243 1/4" 6.4 mm 2 252244 25 242244 100 244244 5/16" 7.9 mm 2 252245 25 242245 100 244245 3/8" 9.5 mm 2 252246 25 242246 100 244246 1/2" 12.7 mm 2 252247 10 242247 5/16" & 3/8" 7.9 & 9.5 mm 1/1 252241 AWG Screw Size Qty/ Pkg Part # 4 21 mm2 #10 4.8 mm 2 252253 25 242253 1/4" 6.4 mm 2 252254 25 242254 100 244254 5/16" 7.9 mm 2 252255 25 242255 100 244255 3/8" 9.5 mm 2 252256 25 242256 100 244256 1/2" 12.7 mm 2 252257 10 242257 5/16" & 3/8" 7.9 & 9.5 mm 1/1 252251 2 34 mm2 1/4" 6.4 mm 2 252264 25 242264 5/16" 7.9 mm 2 252265 25 242265 100 244265 3/8" 9.5 mm 2 252266 25 242266 100 244266 1/2" 12.7 mm 2 252267 10 242267 5/16" & 3/8" 7.9 & 9.5 mm 1/1 252261 1 42 mm2 1/4" 6.4 mm 2 252274 25 242274 5/16" 7.9 mm 2 252275 25 242275 100 244275 3/8" 9.5 mm 2 252276 25 242276 100 244276 1/2" 12.7 mm 2 252277 10 242277 AWG Screw Size Qty/ Pkg Part # 1/0 53 mm2 1/4" 6.4 mm 2 252284 25 242284 5/16" 7.9 mm 2 252285 25 242285 100 244285 3/8" 9.5 mm 2 252286 25 242286 100 244286 1/2" 12.7 mm 2 252287 10 242287 2/0 68 mm2 1/4" 6.4 mm 2 252294 25 242294 5/16" 7.9 mm 2 252295 25 242295 100 244295 3/8" 9.5 mm 2 252296 25 242296 100 244296 1/2" 12.7 mm 2 252297 10 242297 3/0 85 mm2 5/16" 7.9 mm 2 252715 10 242715 3/8" 9.5 mm 2 252716 10 242716 1/2" 12.7 mm 2 252717 10 242717 4/0 107 mm2 5/16" 7.9 mm 2 252725 10 242725 100 244725 3/8" 9.5 mm 2 252726 10 242726 100 244726 1/2" 12.7 mm 2 252727 10 242727 Related Products Crimping Tools pages 49–51 B A C Lug Dimensions AWG A B C 8 0.465" 0.190" 1.313" 6 0.540" 0.232" 1.512" 4 0.545" 0.280" 1.606" 2 0.650" 0.336" 1.622"–1.772" 1 0.645" 0.360" 1.718"–1.845" 1/0 0.725" 0.410" 1.845" AWG A B C 2/0 0.825" 0.460" 2.236"–2.268" 3/0 0.910" 0.510" 2.323" 4/0 1.015" 0.560" 2.563"
TERMINALS & LUGS 31 ancorproducts.com Heavy-duty Butt Connectors 100% Tinned Copper AWG Qty/ Pkg Part # 8 8 mm2 2 252130 25 242130 6 13 mm2 2 252140 25 242140 4 21 mm2 2 252150 25 242150 2 34 mm2 2 252160 25 242160 1 42 mm2 2 252170 25 242170 1/0 53 mm2 2 252180 25 242180 2/0 68 mm2 2 252190 25 242190 90° Tinned Copper Lugs 90° bend for ease of wire routing AWG Screw Size Qty/ Pkg Part # 6 13 mm2 5/16" 7.9 mm 2 262245 3/8" 9.5 mm 2 262246 4 21 mm2 5/16" 7.9 mm 2 262255 3/8" 9.5 mm 2 262256 2 34 mm2 5/16" 7.9 mm 2 262265 3/8" 9.5 mm 2 262266 1 42 mm2 5/16" 7.9 mm 2 262275 3/8" 9.5 mm 2 262276 1/0 53 mm2 5/16" 7.9 mm 2 262285 3/8" 9.5 mm 2 262286 2/0 68 mm2 5/16" 7.9 mm 2 262295 3/8" 9.5 mm 2 262296 3/0 85 mm2 5/16" 7.9 mm 2 262715 3/8" 9.5 mm 2 262716 4/0 107 mm2 5/16" 7.9 mm 2 262725 3/8" 9.5 mm 2 262726
TERMINALS & LUGS 32 ancorproducts.com Battery Terminal Boots Description Size Color Qty/ Pkg Part # Wing Nut Style 4 & 2 (19 & 32 mm2) Black/Red 1/1 260350 Right Angle 8–2 (8-32 mm2) Red 1 260381 260350 260381 Lead Battery Terminals Description Positive/ Negative Stud Size Qty/ Pkg Part # Wing Nut Style Yellow Brass Nut Negative 5/16" (8 mm) 1 260100 Positive 3/8" (10 mm) 1 260200 Pos/Neg 5/16" & 3/8" (8 & 10 mm) 1/1 260325 260100 260200 Tinned Brass Battery Terminals Description Positive/ Negative Stud Size Qty/ Pkg Part # Wing Nut Style Yellow Brass Nut Negative 5/16" (8 mm) 1 260010 Positive 3/8" (10 mm) 1 260012 Pos/Neg 5/16" & 3/8" (8 & 10 mm) 1/1 260322 260010 260012
TERMINALS & LUGS 33 ancorproducts.com Battery Clips Color Size Qty/ Pkg Part # Red/Black 10A 1/1 260505 Battery Terminal Cleaner • High impact construction • Wide, easy grip • Excellent for hard-to-reach batteries Part # 700103 Dielectric Silicone Compound • Fights oxidation to improve conductivity • Penetrates aluminum oxide to maintain current paths • Temperature rated at 40° to 500°F / 4°C to 260°C • 1/3 oz tube Part # 700115
Overlapping clamping spines allow for superior pull-out resistance and protection. Strain relief fittings are resistant to salt water, acids, oil, and are not corrosive for marine applications. Wire Seals WIRE MANAGEMENT Ancor uses crosslinked polyolefin material for its superior strength and burn resistance. A heat activated adhesive lining creates an impervious seal and provides strain relief. Adhesive Lined Heat Shrink Tubing A wide range of repair tape and electrical tape in multiple colors. Ancor offers a wide variety of materials, sizes and styles including the innovative SelfCutting Cable Tie which is now available in a mounting version. Cable Ties Repair & Electrical Tape 36 38 39 44
WIRE MANAGEMENT Ancor offers a wide variety of preassembled kits for all of your wire management projects. Provides abrasion resistance for wires passing through panel holes. Flexible construction makes installation simple. Grommets Stainless steel and Nylon cable clamps are corrosion resistant for marine applications. They absorb shock and vibrations; reducing unwanted noise. Cable Clamps Wire management is integral in making sure that wires and connections are kept organized and protected per ABYC Allows flexible routing of cable harnesses and provides abrasion resistance for wire and cable. Split Loom & Spiral Wrap Wire Management Kits 43 44 44 45
WIRE MANAGEMENT 36 ancorproducts.com Adhesive Lined Heat Shrink Tubing (ALT) • Cross Linked polyolefin tubing is much stronger than PVC tubing and will not burn like PVC • Heat activated adhesive lining provides impervious seal to salt water, oil, acids, and sunlight as well as providing strain relief • Highest shrink ratio - shrinks to 1/3 original size • Shrinks at 257°F / 125°C • Operating temperature range of -40°F to 230°F / -40°C to 110°C Kits Wire Range ALT Dia Color Length Qty/ Pkg Part # 20–2/0 AWG .5–62 mm2 3/16"–3/4" 4.8–19 mm Black 3" 7.6 cm 8 301503 6" 15.2 cm 8 301506 12–8 AWG 3–8 mm2 3/8" 9.5 mm Assorted (yw, wh, bl, gr, rd) 3" 30.5 cm 5 304503 6" 122 cm 5 304506 8–2/0 AWG 8–62 mm2 3/4" 19 mm Assorted (yw, wh, bl, gr) 3" 7.6 cm 4 306503 Adhesive Lined Tubing Specifications (3:1 ratio) Size Shrinks to Wire Range (AWG) 1/8" 3.2 mm 1/32" 0.8 mm <18 < 0.8 mm2 3/16" 4.8 mm 1/16" 1.6 mm 20–12 0.5–3 mm2 1/4" 6.4 mm 5/64" 2 mm 16–10 1–5 mm2 3/8" 9.5 mm 1/8" 3.2 mm 12–8 3–8 mm2 1/2" 12.7 mm 5/32" 4 mm 8–4 8–19 mm2 3/4" 19 mm 1/4" 6.4 mm 8–2/0 13–62 mm2 1" 25.4 mm 5/16" 7.9 mm 2–4/0 32–103 mm2 Wire Range ALT Dia Color Length Qty/ Pkg Part # 8–2/0 AWG 13–62 mm2 3/4" 19 mm Black 3" 7.6 cm 3 306103 6" 15.2 cm 4 306106 12" 30.5 cm 4 306124 48" 122 cm 1 306148 Black/Red 3" 7.6 cm 1/1 306602 Red 3" 7.6 cm 3 306603 6" 15.2 cm 4 306606 12" 30.5 cm 4 306624 48" 122 cm 1 306648 Yellow 3" 7.6 cm 3 306903 6" 15.2 cm 4 306906 12" 30.5 cm 4 306924 48" 122 cm 1 306948 2–4/0 AWG 32–103 mm2 1" 25.4 mm Black 3" 7.6 cm 3 307103 6" 15.2 cm 3 307106 12" 30.5 cm 3 307124 48" 122 cm 1 307148 Black/Red 3" 7.6 cm 1/1 307602 Red 3" 7.6 cm 3 307603 6" 15.2 cm 3 307606 12" 30.5 cm 3 307624 48" 122 cm 1 307648 Yellow 3" 7.6 cm 3 307903 6" 15.2 cm 4 307906 12" 30.5 cm 4 307924 48" 122 cm 1 307948 Wire Range ALT Dia Color Length Qty/ Pkg Part # <18 AWG <0.8 mm2 <1/8" <3.2 mm Black 3" 7.6 cm 3 301103 6" 15.2 cm 10 301106 12" 30.5 cm 10 301124 48" 122 cm 1 301148 20–12 AWG 0.5–3 mm2 3/16" 4.8 mm Black 3" 7.6 cm 3 302103 6" 15.2 cm 10 302106 12" 30.5 cm 10 302124 48" 122 cm 1 302148 Red 3" 7.6 cm 3 302603 6" 15.2 cm 10 302606 12" 30.5 cm 10 302624 48" 122 cm 1 302648 16-10 AWG 1–5 mm2 1/4" 6.4 mm Black 3" 7.6 cm 3 303103 6" 15.2 cm 10 303106 12" 30.5 cm 10 303124 48" 122 cm 1 303148 Black/Red 3" 7.6 cm 1/1 303602 Red 3" 7.6 cm 3 303603 6" 15.2 cm 5 303606 12" 30.5 cm 10 303624 48" 122 cm 1 303648 12–8 AWG 3–8 mm2 3/8" 9.5 mm Black 3" 7.6 cm 3 304103 6" 15.2 cm 5 304106 12" 30.5 cm 5 304124 48" 122 cm 1 304148 Black/Red 3" 7.6 cm 1/1 304602 Red 3" 7.6 cm 3 304603 6" 15.2 cm 5 304606 12" 30.5 cm 5 304624 48" 122 cm 1 304648 8–4 AWG 8–19 mm2 1/2" 12.7 mm Black 3" 7.6 cm 3 305103 6" 15.2 cm 5 305106 12" 30.5 cm 5 305124 48" 122 cm 1 305148 Black/Red 3" 7.6 cm 1/1 305602 Red 3" 7.6 cm 3 305603 6" 15.2 cm 5 305606 12" 30.5 cm 5 305624 48" 122 cm 1 305648 Related Products Nylon terminals page 27 Heat Tools page 52
