Accessories
|
Wiper Systems
MRVWiper Motor
• Easily powers 22" x 22" deluxe arm/blade combinations,
or a 20" x 20" premier arm/blade combination at sweep
sets of 80° or less
• Factory pre-set sweep of 80° or 110° adjustable to 45°,
60°, 80° or 110°
• .625" diameter shaft (16 mm)
• Available in 3 shaft lengths: 1.5", 2.5" and 3.5"
(includes .5" length of knurled arm fitting)
• Corrosion-resistant casing
• Heavy-duty motor with right angle drive
• Two-speed motor, can be operated as one speed
• Solid brass knurled drive nut with brass and stainless steel
drive shaft
• Adjustable right or left self parking, coast to park
• Retail version includes 5 amp fuse and holder
• Stainless steel fasteners and mounting bracket
• Use with three-position switch (not included)
• Compact size – 7.625" L x 4" W x 2" D
• Stall torque: 109 in-lbs (125 kgf/cm: 12.3 Nm)
• Stall current: 11.5–13.0 amps
• No load current: 0.5–1.2 amps
mm)
2.52”(64.0mm)
3.54”(90.0mm)
2.08”(52.8mm)
1.47”(37.38mm)
L = 1.5”,2.5”3.5”
3.96”(100.8mm)
6.06”(154.0mm)
1.47”
(37.38mm)
2.52”(64.0mm)
3.54”(90.0mm)
2.08”(52.8mm)
1.47”(37.38mm)
L = 1.5”,2.5”3.5”
Voltage Sweep Item# OEM #
1.5" Shaft
12V 80°
34001
38001
110°
34011
38011
2.5" Shaft
12V 80°
34000
38000
110°
34010
38010
24V 110°
34210
—
3.5" Shaft
12V 80°
34005
38005
110°
34015
—
MRVWiper Motor Cover
• Constructed of white ABS plastic
• Easily installed
Item # 33025
White
OEM # 33125 White
OEM # 33126 Black
Accessories:
Wiper Motors
