Accessories
|
Lighting
Wireless Remote Spot Light
• Universal 12/24 volt circuit with bright 100W, H3 halogen bulb
• UV resistant, IP56 Weatherproof ABS housing and Lexan
®
lens
• O-ring sealed housing, designed for the harsh marine environment
– moisture, salt, shock and vibration tested
• Universal snap-in mounting system (can be mounted upside down)
• Super-quiet, all-weather motor with limit stops provides a full range
of coverage
• 370° sweep and 120° Tilt (75° up and 45° down)
• One touch auto sweep and S.O.S. function
• Wireless dash mount remote standard;
(hard wired & handheld remotes are optional)
• 3-Year limited warranty
• Available in white,
black and chrome
Accessories:
Spot/Flood Lights
Bulb:
100 Watt, H3 Halogen
Power (Input voltage):
12V or 24V
Current draw (idle/in use): 0.03 amps / 7.0 amps
Peak Beam Intensity:
210,000 Cp
Peak Beam Distance:
917 ft (280 m)
Lux @ 66' (20 m):
525 Lux
Coverage at 66' (20 m):
132 sq ft
(12 sq m)
Rotation:
370° (built in limit stops)
Tilt:
120° Tilt (75° up & 45° down)
Wireless range:
200 ft (65 m)
Dimensions:
7.5"W x 7.5"H x 9.25"D
(19cm x19cm x 23.5cm)
Weight:
3.30 lbs (1.5 kg)
Housing material:
UV resistant PC/ASA
Lens material:
UV resistant Lexan
®
operating temp range:
5°F–113°F (-15°C–45°C)
IP Rating:
IP56
SPLR-2
SPLR-1
SPLR-3
Included
(optional)
(optional)
Remote Specifications
Wireless Bridge Remote
Hand Held Bridge Remote
Wired Bridge Remote
Power
12 or 24 volt (hard wired)
CR2450 button cell battery
12 or 24 volt (hard wired)
Current draw (idle / in use) negligible
negligible
negligible
Wireless range
200 ft (65m)
200 ft (65m)
—
Estimated battery life
—
> 40 hours (continuous use)
—
Dimensions
3.5"Wx2.25"Hx.75"D
88x57x19 mm
2.0"Wx3.78"Hx1"D
51x96x25 mm
3.5"Wx2.25"Hx.75"D
88x57x19 mm
Weight
2.12 oz (60g)
2.82 oz (80g)
2.12 oz (60g)
Housing material
UV resistant PC/ASA
UV resistant PC/ASA
UV resistant PC/ASA
Button material
Silicone (glow in the dark)
Silicone (glow in the dark)
Silicone (glow in the dark)
Operating temp range
5°F–113°F (-15°C–45°C)
5°F–113°F (-15°C–45°C)
5°F–113°F (-15°C–45°C)
IP Rating
IP54
IP56
IP54
Remote Options
Description
Color
Item #
OEM #
12/24 Volt, 100 Watt
white
SPL-12W
—
12/24 Volt, 100 Watt
black
SPL-12B
—
12/24 Volt, 100 Watt
chrome
SPL-12C
—
12 Volt, 100 Watt
white
— SPL-12W.OEM
12 Volt, 100 Watt
black
— SPL-12B.OEM
12 Volt, 100 Watt
chrome — SPL-12C.OEM
24 Volt, 100 Watt
white
— SPL-24W.OEM
24 Volt, 100 Watt
black
— SPL-24B.OEM
24 Volt, 100 Watt
chrome — SPL-24C.OEM
Replacement Bulbs
Description
Item #
12 Volt, H3 Halogen
202319
24 Volt, H3 Halogen
202320
