|12 |
VD6505 ADJUSTABLE VOLT SENSOR™ NON-CONTACT 12–1000 VAC
VD6504 VOLT SENSOR™ NON-CONTACT 50-1000 VAC
ST6401 SCREWDRIVER-VOLTAGE-CONTINUITY TESTER
VD6504
Simple One-Button
Operation
Audible and
Visual Indication
Verify the presence of AC voltage prior
to working on any application.
• Non-contact sensing circuit detects 50–1000 VAC
• Audible and 360° visual indication
• Patented battery self-test feature
• Pocket clip
• Operates from (1) AAA battery, included
VD6504 Range
AC Voltage 50–1000V
Frequency 50–60Hz
Adjustable –
VC6505
The adjustable Volt Sensor™ allows for sensitivity adjustments in
multiple-wire applications when precision and safety are crucial.
• Adjustable non-contact sensitivity detects voltage
from 12–1000 VAC
• Audible and 360° visual indication
• Patented battery self-test feature
• Pocket clip
• Operates from (1) AAA battery, included
Adjustable
Sensitivity
Low-Voltage
Applications
VD6505 Range
AC Voltage 12–1000V
Frequency 50–60Hz
Adjustable
600 V 1000 V
Patented
600 V 1000 V
Patented
ST6401
From mechanical to electrical, this three function unit
is perfect for multiple applications.
• Tests both AC and DC voltages from 12 to 250 Volts
• Verifies continuity in unenergized circuits
• 360° visual indication
• Reinforced flat head screwdriver tip designed for most faceplate screws
• Pocket Clip
• Over-molded rubber grips
• Operates from (2) LR44 button cell batteries, included
ST6401 Range
AC Voltage 12–250V
DC Voltage 12–250V
Continuity
Test AC Voltage
