NEW
DM6650T TRUE RMS 10 FUNCTION DIGITAL MULTIMETER
PROVIDES JUST THE RIGHT MIX OF FUNCTIONALITY, DURABILITY, FEATURES AND SAFETY
The Sperry TRMS 10 Function Digital Multimeter has precise True RMS circuitry for accurate readings of non-linear waveforms. Non-
contact voltage detection is integrated into the multimeter design. This multimeter is equipped with a min/max function to hold either
minimum reading or maximum reading on the display. Relative Delta displays change in readings. Data hold feature captures reading
on the display. Large backlit LCD display with bar graph indication. Impact resistant housing with protective rubber boot. Operates
from one 9 volt battery (included).
• Precise True RMS circuitry for accurate readings of non-linear waveforms
• Integrated non-contact voltage detection
• Relative Delta displays change in readings
• Min/Max function to hold either minimum reading or maximum
reading on the display
• Data hold feature captures reading on the display
• Large backlit LCD display with bar graph indication
• Impact resistant housing with protective rubber boot
• Operates from (1) 9 volt battery, included
DM6650T Range Accuracy
AC Voltage 60mV, 600mV, 6V, 60V,
600V, 750V
60mV, 600mV ±(1.2%+5)
6V, 60V, 600V ±(1.0%+3)
750V ±(1.2%+5)
DC Voltage 60mV, 600mV, 6V, 60V,
600V, 1000V
60mV, 600mV ±(0.8%+3)
6V, 60V, 600V ±(0.5%+1)
1000V ±(1.0%+3)
AC Current 600μA, 6000μA, 60mA, 600mA,
6A, 10A
600μA, 6000μA ±(1.2%+5)
60mA, 600mA ±(1.5%+5)
6A 10A ±(2.0%+5)
DC Current 600μA, 6000μA, 60mA
600mA, 6A, 10A
600μA, 6000μA, 60mA,
600mA ±(1.0%+3)
6A, 10A ±(1.2%+5)
Resistance 6001, 6K1, 60K1, 600K1,
6M1, 60M 1
6001 ±(1.2%+2)
6K1, 60K1, 600K1 ±(1.0%+2)
6M1 ±(1.2%+2)
60M 1 ±(1.5%+2)
Capacitance 40nF, 400nF, 4μF, 40μF
400μF, 4000μF
40nF, 400nF, 4μF, 40μF ±(3.0%+5)
400μF ±(4.0%+5), 4000μF undefined
Frequency 10Hz~10MHz ±(0.1%+4)
Duty Cycle 0.1%~99.9% –
1000 V 600 V
IN TERT EK
LISTED
CM
C US
DM6650T
