SECTION
AIR CONDITIONING, REFRIGERATION & APPLIANCE TRANSFORMERS
ACME ELECTRIC
•
MILWAUKEE, WI
•
800.334.5214
•
acmetransformer.com
112
GROUP C
PRIMARY VOLTS — 200/220/240 SECONDARY VOLTS — 115, 50/60 Hz
RECEPTACLE
Catalog
VA
Output
approx. dimensions
Approx.
No.
Rating
Amps
Inches (Cm.)
Ship weight
Connections
Height
Width
Depth
Lbs. (Kg.)
Feet (Meters)
T160830
①
200
1.74
9.16 (23.3)
3.89 (9.9)
3.67 (9.3)
6 (2.7)
6 (1.8) primary cord and secondary receptacle
T160831
①
300
2.61
9.16 (23.3)
3.89 (9.9)
3.67 (9.3)
6 (2.7)
6 (1.8) primary cord and secondary receptacle
T160832
①
400
3.48
9.16 (23.3)
3.89 (9.9)
3.67 (9.3)
8 (3.6)
6 (1.8) primary cord and secondary receptacle
T160833
①
500
4.35
9.68 (24.6) 4.75 (12.1) 4.51 (11.5)
10 (4.5) 6 (1.8) primary cord and secondary receptacle
T160834
①
1000
8.70
9.68 (24.6) 4.75 (12.1) 4.51 (11.5)
14 (6.4) 6 (1.8) primary cord and secondary receptacle
T160835
①
2000
17.40
11.50 (29.2) 7.81 (19.8) 7.13 (18.1)
27 (12.2) 6 (1.8) primary cord and secondary receptacle
①
All models can be reverse connected with input voltage applied to secondary terminals and output voltage available at primary terminals.
Do not exceed rating voltages. Transformer VA capacity will remain the same.
