SECTION
DRY-TYPE DISTRIBUTION TRANSFORMERS
ACME ELECTRIC
•
MILWAUKEE, WI
•
800.334.5214
•
acmetransformer.com
28
①
Wall mounting brackets are available for these sizes, refer to page 133.
380 DELTA PRIMARY VOLTS –– 220Y/127 SECONDARY VOLTS –– 3Ø, 50 Hz
GROUP T
APPROX. DIMENSIONS
APPROX.
TYPE MTG.
Weather Wiring Diagrams &
kVA CATALOG NO.
Inches (Cm.)
SHIP WEIGHT W – Wall
Knockouts Shield
Design Figures
Height
Width
Depth
Lbs. (Kg.)
F – Floor
Inches (Cm.)
P/N
Begin on Page 122
15.0 T3795511S
20.80 (52.8)
20.90 (53.1)
10.20 (25.9)
435 (197.3)
F
NA
NA
24–I
30.0 T2A795523S 25.50 (64.8)
24.40 (62.0)
19.40 (49.3)
365 (165.6)
F
①
NA
WSA1
20–E
45.0 T2A795533S 29.41 (74.7)
28.15 (71.5)
22.37 (56.8)
468 (212.3)
F
①
NA
WSA2
20–E
75.0 T2A795543S 35.47 (90.1)
31.90 (80.0)
26.88 (68.3)
693 (314.3)
F
NA
WSA3
20–E
112.5 T2A795553S 41.52 (105.5)
32.90 (83.6)
29.87 (75.9)
970 (440.0)
F
NA
WSA4
20–E
Notes: 50 Hz units (TP1 exempt)
GROUP U
APPROX. DIMENSIONS
APPROX.
TYPE MTG.
Weather Wiring Diagrams &
kVA CATALOG NO.
Inches (Cm.)
SHIP WEIGHT W – Wall
Knockouts Shield
Design Figures
Height
Width
Depth
Lbs. (Kg.)
F – Floor
Inches (Cm.)
P/N
Begin on Page 122
10.0
TF220105S 18.90 (48.0)
20.30 (51.6)
9.00 (22.9)
245 (111.1)
F
①
NA
NA
73–I
15.0 TF220155S
25.50 (64.8)
24.40 (62.0)
19.40 (49.3)
291 (132.0)
F
①
NA
WSA1
73–E
25.0 TF220255S
25.50 (64.8)
24.40 (62.0)
19.40 (49.3)
375 (170.1)
F
①
NA
WSA1
73–E
50.0 TF220505S
29.41 (74.7)
28.15 (71.5)
22.37 (56.8)
437 (198.2)
F
①
NA
WSA2
73–E
440 DELTA PRIMARY VOLTS –– 220Y/127 SECONDARY VOLTS –– 3Ø, 50 Hz
Notes: 50 Hz units (TP1 exempt)
