TA SERIES OPEN CORE & COIL INDUSTRIAL CONTROL TRANSFORMERS
CATALOG
VA
EUROPEAN*
APPROX. DIMENSIONS INCHES (CM.)
APPROX.
NO.
RATING
RATING
A
B
C
D
E
F
SHIP WEIGHT LBS. (Kg.
)
FS150
FS175
FS1100
FS1150
FS1250
FS1350
FS1500
FS1750
FS11000
1000
870
4.76 (12.1)
6.75 (17.1)
6.03 (15.3)
5.75 (14.6)
2.86 (7.3)
.31 x .50 (0.8 x 1.3)
26 (11.8)
FINGER/GUARD
®
INDUSTRIAL CONTR L RANSFORMERS
240/416/480/600; 230/400/460/575; 220/380/440/550; 208/500 PRIMARY VOLTS
99/120/130; 95/115/125; 91/110/120; 85/100/110 SECONDARY VOLTS—50/60 Hz
240 X 480, 230 X 460, 220 X 440 PRIMARY VOLTS—120/115/110 SECONDARY VOLTS—50/60 Hz
120 X 240 PRIMARY VOLTS—24 SECONDARY VOLTS—50/60 Hz
SELECTION CHARTS
GROUP A
GROUP B
GROUP C
CATALOG
VA
EUROPEAN*
APPROX. DIMENSIONS INCHES (CM.)
APPROX.
NO.
RATING
RATING
A
B
C
D
E
F
SHIP WEIGHT LBS. (Kg.
)
FS350
50
50
2.59 (6.6)
3.75 (9.5)
3.64 (9.2)
3.13 (8.0)
1.70 (4.3)
.22 x .50 (0.6 x 1.3)
5 (2.3)
FS3150
150
150
3.31 (8.4)
4.50 (11.4)
4.15 (10.5)
3.75 (9.5)
2.18 (5.5)
.22 x .50 (0.6 x 1.3)
8 (3.6)
FS3250
250
250
3.61 (9.2)
4.88 (12.4)
4.46 (11.3)
4.06 (10.3)
2.33 (5.9)
.22 x .50 (0.6 x 1.3)
11 (5.0)
FS3350
350
345
4.69 (11.9)
4.88 (12.4)
4.46 (11.3)
4.06 (10.3)
3.48 (8.8)
.22 x .50 (0.6 x 1.3)
17 (7.7)
FS3500
500
490
4.39 (11.2)
6.75 (17.1)
6.03 (15.3)
5.75 (14.6)
2.48 (6.3)
.31 x .50 (0.8 x 1.3)
22 (10.0)
FS3750
750
720
5.18 (13.2)
6.75 (17.1)
6.03 (15.3)
5.75 (14.6)
3.31 (8.4)
.31 x .50 (0.8 x 1.3)
30 (13.6)
FS31000
1000
870
6.18 (15.7)
6.75 (17.1)
6.03 (15.3)
5.75 (14.6)
4.30 (10.9)
.31 x .50 (0.8 x 1.3)
39 (17.7)
FS31500
1500
1290
6.26 (15.9)
7.50 (19.1)
6.68 (17.0)
6.50 (16.5)
5.26 (13.4)
.41 x .81 (1.0 x 2.1)
51 (23.1)
FS32000
2000
1680
7.76 (19.7)
7.50 (19.1)
7.70 (19.6)
6.50 (16.5)
6.75 (17.1)
.41 x .81 (1.0 x 2.1)
66 (29.9)
FS33000
3000
2465
8.88 (22.6)
11.92 (30.3)
8.83 (22.4)
6.75 (17.1)
5.75 (14.6)
.41 x .81 (1.0 x 2.1)
70 (31.8)
Reference Group IC (CE01):
CE Series Industrial Control Transformers
50-750 VA
See Pg 72
Reference Group VIC (CE06):
CE Series Industrial Control Transformers
50-750 VA
See Pg 73
CATALOG
VA
EUROPEAN*
APPROX. DIMENSIONS INCHES (CM.)
APPROX.
NO.
RATING
RATING
A
B
C
D
E
F
SHIP WEIGHT LBS. (Kg.
)
FS250
FS275
FS2100
FS2150
FS2250
FS2300
FS2350
FS2500
FS2750
FS21000
1000
870
4.76 (12.1)
6.75 (17.1)
6.03 (15.3)
5.75 (14.6)
2.86 (7.3)
.31 x .50 (0.8 x 1.3)
26 (11.8)
FS21500
1500
1290
6.01 (15.3)
6.75 (17.1)
6.03 (15.3)
5.75 (14.6)
4.13 (10.5)
.31 x .50 (0.8 x 1.3)
38 (17.2)
FS22000
2000
1680
6.51 (16.5)
6.75 (17.1)
6.03 (15.3)
5.75 (14.6)
4.63 (11.8)
.31 x .50 (0.8 x 1.3)
44 (20.0)
FS23000
3000
2465
7.44 (18.9)
7.50 (19.1)
6.68 (17.0)
6.50 (16.5)
6.47 (16.4)
.41 x .81 (1.0 x 2.1)
60 (27.2)
