Accessories
|
Ventilation
Installation
All Marinco
™
ventilation products include clear, easy-to-understand
installation instructions. These instructions address all of the key
factors of a professional installation, such as:
• Proper hole measurement and cutting procedures
• Proper deck plate installation
• Use of sealants to waterproof your vent installation
• Installing vents in hatches
• Installing vents in “cambered” or slightly curved decks
• Use of interior trim rings to “dress up” the cabin
The high quality level of Marinco
™
Ventilation products must be
combined with a sound installation to guarantee that your vent
performs in all conditions. Marinco will make sure that your installation
will be easy and successful so that you can enjoy the benefits of
installation for a long time to come.
Marinco
™
Ventilation Installation Systems
Snap-In Deck Plate Installation
The 12 volt vent, 12 volt combo vent and cowl vents use the Marinco
™
Snap-In deck plate system. The Snap-In system allows the easy
exchange of any Snap-In part for upgrading or convenience, as well
as the use of a Snap-In cover that completely seals the deck plate
making it water tight.
Direct-To-Deck Installation
The Day/Night Plus, MiniVent 1000 and AirVent 500 are designed to
be installed directly to the deck without the requirement for a deck
plate. All of these vent systems have built-in shut-off dampers that
operate from below.
PROCESS
BLUE
RUBINE
RED
109
YELLOW
BLACK
INSTALLATIONGUIDE INKS
06a-Sanding.ilp
Deck Plate
Deck
Plastic Interior
Trim Ring
Airflow
Size
Hole
Size Dia
Deck
Plate
Mounting
Flange
Depth
Operation
Cubic Feet
of Air
Intake Exhaust
Day
Night
Day/Night Plus
4"
102 mm
4-3/4"
None
(Direct to
Deck
Mounting)
1.75"
Solar
Rechargeable
Battery Power
1000 ft
3
/hour
20 m
3
24,400 ft
3
/day
672 m
3
Fan
Fan
3"
76 mm
3-3/4"
None
(Direct to
Deck
Mounting)
1.75"
Solar
Rechargeable
Battery Power
600 ft
3
/hour
17 m
3
16,800 ft
3
/day
408 m
3
Fan
Fan
MiniVent 1000
3"
76 mm
3-3/4"
None
(Direct to
Deck
Mounting)
1"
Solar
Passive
700 ft
3
/hour
20 m
3
5,600 ft
3
/day
160 m
3
Exhaust
fan only
Fan
AirVent 500
3"
76 mm
3-3/4"
None
(Direct to
Deck
Mounting)
1"
Passive
Passive
600 ft
3
/hour
17 m
3
In a 15 Knot
Breeze
Exhaust
fan only
Passive
Cowl Vents
4"
102 mm
4-3/4"
Snap-In
(6" Outer
Diameter)
1"
Passive
Passive
—
Passive Passive
3"
76 mm
3-3/4"
Snap-In
(5" Outer
Diameter)
1"
Passive
Passive
—
Passive Passive
