toll free 800.307.6702 MASTERVOLT | mastervolt.com MARINCO | marinco.com ANCOR | ancorproducts.com
Store:
AGM Batteries
AGM Series
• Excellent starter function.
• Perfect upgrade for wet lead acid batteries.
• Same initial power surge in an AGM 12/90 Ah as in a 180 Ah wet lead-acid battery.
• Glass-fiber technology ensures low internal resistance.
• Use of thicker plates extends lifespan.
• Also for cyclic use.
• Two year warranty
AGM SlimLine Series
• Ideal universal battery; also for starter functions.
• Compressed AGM technology.
• Saves up to 15% in volume.
• Saves up to 15% in weight.
• Miniscule footprint; 2x 200 Ah for a 200 Ah battery footprint.
• Two-year warranty.
AGM 6 Volt Series
• Ideal solution for cyclic applications, such as electric
propulsion, wheelchairs, golf carts, etc.
• Easy configuration of 12/24/48V battery terminals, with
high capacity.
• Double pole for easy installation.
• No gas formation with normal use.
• Two-year warranty.
AGM 12/55
AGM 12/70
AGM 12/90
AGM 12/130
AGM 12/160
AGM 12/225
AGM 12/270
Item #
62000550
62000700
62000900
62001300
62001600
62002250
62002700
Nominal voltage 12V
12V
12V
12V
12V
12V
12V
Capacity C20* 55 Ah
70 Ah
90 Ah
130 Ah
160 Ah
225 Ah
270 Ah
CCA to DIN 300A
385A
535A
585A
630A
815A
1000A
CCA to SAE 480A
615A
850A
935A
1000A
1300A
1600A
Max. outer
Dimensions**
lxwxh
10.1x5.2x8.2"
257x132x207 mm
13.7x6.6x7.2"
348x167x183 mm
13x6.8x9.3"
330x173x237 mm
16.1x7x9"
410x177x228 mm
19.1x6.7x9.6"
485x170x245 mm
20.6x9.4x9.5"
522x240x241 mm
20.6x10.6x9.6"
522x268x243 mm
Weight
37.5 lbs / 17 kg 46 lbs / 21 kg
62 lbs / 28 kg
83 lbs / 37.6 kg 93 lbs / 42.3 kg 140 lbs / 63.5 kg 161 lbs / 73 kg
* C20 = battery capacity at a discharge time of 20 hours, till 1.75V per cell. **Including terminals and grip handles
AGM 6/260
AGM 6/400
Item #
61002600
61004000
Nominal voltage 6V
6V
Capacity C20* 260 Ah
400 Ah
Max. outer
Dimensions**
lxwxh
11.6x7.1x11.7 in
295x180x298 mm
11.6x7.1x16.9 in
295x180x428 mm
Weight
77.8 lbs / 35.3 kg 116.8 lbs / 53 kg
* C20 = battery capacity at a discharge time of 20 hours, till 5.25V.
**Including terminals and grip handles
AGM-SL 12/150 AGM-SL 12/200
Item #
63001500
63001851
Nominal voltage 12V
12V
Capacity C20* 150 Ah
200 Ah
CCA to DIN 610A
750A
CCA to SAE 1020A
1250A
Max. outer
Dimensions**
lxwxh
22x4.3x11 in
560x110x280 mm
22x5x11 in
560x126x280 mm
Weight
89 lbs / 40.5 kg 113 lbs / 51.2 kg
* C20 = battery capacity at a discharge time of 20 hours, till 1.75V per cell.
**Including terminals and grip handles
