701
701S
700
Contour Battery Master Switch
This switch offers a number of unique
features, the highlight being the patented
Contour Locking System, allowing it to
be a stand alone unit, or locked together
with other switches.
• Features a control knob which can be
removed by switching to an counter-
clockwise 45° position. The control
knob also features an interchangeable
labeling system allowing a full range of
applications (Item # 713 or 715 on
page 149).
• Three removable side plates on sides
for access of up to 1/0 cables plus a
rear cover insulating the rear terminals
against any short circuits. This ensures
the switch meets ABYC requirements.
• Can be either surface or recess
mounted by cutting a 2.1" (52 mm) hole.
• Available with house knob (OEM #
701B-HB) or with chassis knob (OEM #
701B-CH).
Battery Selector Switch
The 701S is the most compact selector
switch available on the market. Housed
in the same dimensions as the 701, and
includes the same removable side plates
and back cover. While BEP recommends
isolated battery systems as outlined with
our distribution clusters, the 701S offers
a simple economical way of separating
two batteries.
Please note selector switches will not
separate electronics from harmful
engine starting spikes.
Easyfit™ Battery Switch
Created for installations where switches
need to be recessed through varying
thicknesses of panels. It achieves this
through an easily removable threaded ring
allowing for panel thicknesses up to 3/4"
(19 mm). It uses the same features as the
701 with the removable key 45° past the
off position, labelled handle and a
removable back cover covering exposed
terminals to meet ABYC specifications.
The switch can also be surface mounted
offering a unique style compared to other
switches available on the market.
The 700 Easyfit™ switch can easily be
retro - fitted in place of most European
post and lever type switches.
Now molded in high temperature,
fiber reinforced plastics.
Manage:
Standard Battery Switches
BEP Marine Battery Switch Test
Procedures (UL 1107) Continuous (1 hour), intermittent (5 minutes) & Cranking (engine starting – 10 seconds). The test is to
determine the maximum current the switch can handle for the stated time, without the rear terminals exceeding 100°C (212°F)
above the ambient temperature. The continuous and intermittent ratings are tested at 110% of specified ratings. All BEP switches
are tested Independently to this specification by a 3rd party laboratory.
Specifications
- All recessed or surface mount, tin-plated copper studs & nuts, ignition-protected
Item #
OEM #
in
LxWxH
mm
LxWxH
Rating (A DC)
Voltage
(V DC) Operation
Stud size
Studs x (in/mm)
Cont
Inter
Crank
700
700B 2.7"x2.7"x4.3" 68x68x110 mm 275
455
1250 48
On/Off
2 x (3/8" / 10 mm)
701
701B 2.75"x2.75"x3" 69x69x75 mm 275
455
1250 48
On/Off
2 x (3/8" / 10 mm)
701S
701S-B 2.75"x2.75"x3" 69x69x75 mm 200
300
1000 48
1-2-Both-Off 3 x (5/16" / 8 mm)
