MVSV 2 Volt Gel Series
• Long lifespan.
• Many charging and discharging cycles.
• Charges quickly.
• Extremely sustainable battery for large installations.
• Robust build for longer lifespan.
• Deep discharging without problems.
• Can be installed horizontally or vertically.
• Seven-year warranty (pro rate).
MVSV 1250
MVSV 1500
MVSV 1650
MVSV 2200
MVSV 2700
Item #
68001250
68001500
68001650
68002200
68002700
Nominal voltage
2V
2V
2V
2V
2V
Capacity C10*
1250 Ah
1500 Ah
1650 Ah
2200 Ah
2700 Ah
Max. outer
Dimensions** lxwxh
8.3"x9.3"x27.2"
212x235x690 mm
8.3"x10.9"x27.2"
212x277x690 mm
8.3"x10.9"x30"
211x276x762 mm
8.5"x15.7"x32.1"
216x400x816 mm
8.4"x19.3"x32.1"
214x489x816 mm
Weight
80 kg / 176 lbs
95 kg / 209 lbs
115 kg / 254 lbs
160 kg / 353 lbs
198 kg / 437 lbs
* C10 = battery capacity at a discharge time of 10 hours, till 1.80V per cell. **Including terminals and grip handles
MVSV 280
MVSV 420
MVSV 500
MVSV 580
MVSV 750
MVSV 1000
Item #
68000280
68000420
68000500
68000580
68000750
68001000
Nominal voltage
2V
2V
2V
2V
2V
2V
Capacity C10*
280 Ah
420 Ah
500 Ah
580 Ah
750 Ah
1000 Ah
Max. outer
Dimensions** lxwxh
5"x8.2"x15.7"
126x208x399 mm
5"x8.2"x20.3"
126x208x515 mm
5.8"x8.2"x20.3"
147x208x515mm
6.6"x8.2"x20.3"
168x208x515 mm
5.8"x8.2"x27.2"
147x208x690 mm
8.3"x7.6"x27.2"
212x193x690 mm
Weight
23 kg / 50.7 lbs
30 kg / 66.1 lbs
35 kg / 77.2 lbs
39 kg / 86 lbs
49 kg / 108 lbs
66 kg / 146 lbs
* C10 = battery capacity at a discharge time of 10 hours, till 1.80V per cell. **Including terminals and grip handles
Store:
Gel Batteries
Options
(for all models)
MasterShunt
MasterBus integrated battery monitor, with detailed
information on the status of your batteries for a optimised
charging process, incl. voltage, current, remaining time and
consumption capacity in percentage.
77020100
Masterlink BTM-III
Provides an accurate indication of the current, amperage,
remaining time and remaining capacity of battery bank 1,
and the current and estimated capacity of battery banks 2
and 3. The built-in microprocessor calculates the remaining
capacity and stores historic data.
70403163
