Connect
|
Cordsets & Adapters
Connect:
Cordsets
EEL ShorePower Cordsets
One Hand. A simple twist. Full Power.
The EEL (Easily Engaged Lock) ShorePower Cordset has a patented,
industry first, jaw-clamp design providing one-handed operation and
a secure waterproof seal which completely eliminates the need for a
locking ring. The EEL connection is built for the harshest
environments and is UL approved. This easy-to-use cordset features
a built-in cord light which serves as an alert to boaters when the cord
is left plugged in. And, best of all, it works with your current inlet. In
addition to cordsets with the EEL System, Marinco also has a full set
of Pigtail and Y adapters all using the new EEL technology.
Patented EEL Technology:
• Designed for use with standard inlets (NEMA)
• Single-handed operation
• No sealing ring required
• Patented jaw-clamp technology provides a watertight
seal every time
Features & Benefits:
• Built-in cord light for added safety – alert light indicates if
you are plugged into the dock and cord is powered
• Power indicator light on both ends informs you full power
is flowing through the cord
• Meets and exceeds rigorous UL testing standards
• 30 Amp and 50 Amp cordset models, 12', 25' and 50' lengths
in white and yellow available
• EEL product line includes connectors, pigtail, straight and
“Y” adapters
Length Color
Item #
30 Amp 125V Cordsets
12'
yellow
CS30-12
25'
yellow
CS30-25
50'
yellow
CS30-50
50'
white
CS30-50W
50 Amp 125V Cordsets
25'
yellow
CS503-25
50'
yellow
CS503-50
50 Amp 125/250V Cordsets
25'
yellow
CS504-25
25'
white
CS504-25W
50'
yellow
CS504-50
50'
white
CS504-50W
CS504-50W
CS30-50
G
X
Y
W
50A 125/250V
Locking
NEMA
SS-2
NEMA
L5-30R
W
G
30A 125V
Locking
NEMA
SS-1
G
W
50A 125V
Locking
®
®
