Split Loom & Spiral Wrap

• Permits flexible routing of cable harnesses.

• Provides abrasion protection for wire and cable.

• Allows lead outs at any point for greatest ease of installation.

ABYC Recommends:

“Conductors that may be

exposed to physical damage

shall be protected by self-

draining; loom, conduit, tape,

raceways, or other equivalent

protection.” 11.14.6.7.

“When AC and DC conductors

are run together, the AC

conductors shall be sheathed,

bundled, or otherwise kept

separate from the DC

conductors.” 11.14.6.4.

“Loom used to cover conductors

shall be self-extinguishing. The

base product (or resin) shall be

classified as V-2 or better, in

accordance with UL 94, Tests For

Flammability Of Plastic

Materials.” 11.14.6.8.

Marine Grade

™

Spiral Wrap

Diameter

Ft/Pkg Item #

1/4" 6 mm 10'

452251

3/8" 10 mm 10'

452381

100'

452385

1/2" 13 mm 10'

452501

100'

452505

3/4" 19 mm 10'

452751

100'

452755

25 mm 5'

452900

100'

452905

Self-extinguishing Split Loom

Diameter

Ft/Pkg Item #

3/8" 10 mm 10'

453382

100'

453386

1/2" 13 mm 10'

453502

3/4" 19 mm 10'

453752

100'

453756

25 mm 5'

453901

Spiral Wrap Specifications

Nominal

Diameter

Bundle Range

Min.

Max.

1/4"

0.188 2.0

6 mm 4.8 mm 5 cm

3/8"

0.313 3.0

10 mm 8 mm 7.6 cm

1/2"

0.375 4.0

13 mm 10 mm 10.2 cm

3/4"

0.750 5.0

19 mm 19 mm 12.7 cm

1.000 7.0

25 mm 25 mm 17.8 cm

Manage:

Wire Management

Grommets

• Provide instant abrasion resistance to wires

passing through panel holes.

• Flexible black vinyl makes installation simple.

Hole Size

Inside

Diameter

Panel Width

Qty/

Pkg Item #

3/8" 10 mm 1/4" 6 mm 3/32" 2 mm 5

760375

1/2" 13 mm 3/8" 10 mm 1/16" 2 mm 5

760500

1/4–3/4" Assortment Combo Pack

750000
