Specifications Range
Accuracy
DC Voltage
200mV, 2V, 20V, 200V, 600V
200mV & 600V (1.0%+5dgt)
2V 20V 200V (0.5%+5dgt)
AC Voltage
200mV, 2V, 20V, 200V, 500V
500V (1.5%+5dgt)
2V 30V 200V (0.8%+5dgt)
Resistance
200, 2K, 200k, 2M, 20M
200
Ω
20M (1.5%+2dgt)
2K 20K 200K 2M (1.0%+2dgt)
Battery Testing 1.5V (2V)
–
Temperature
-40˚F–752˚F
8%+5dgt
Diode Test
3
–
Continuity
3
–
CAT Rating
III 600V
–
600V
CONFORMSTOULSTD.
61010-1& 61010-031
CERTIFIEDTO
CAN/CSASTDC22.2
Nos.61010-1& 61010-031
I
N
T
E
R
T
E
K
L
I
S
T
E
D
CM
C
US
7 Function Digital Multimeter
• Auto ranging capability allows the meter to automatically determine
the resolution based on the application
• Compact, lightweight design
• AC/DC voltage capable with temperature measurement functionality
• Impact resistant housing with protective rubber overmold
• Operates from (2) AAA batteries
Item # DM6250
Manage:
Testers
True RMS 10 Function Digital Snap-Around
• Precise True RMS circuitry
• 1000 Amp non-contact current reading
• Integrated non-contact voltage detection
• Min/Max function to hold either minimum reading or maximum reading on the display
• Data hold capability to maintain reading on display
• Backlit display for low light applications
• Peak hold function to display in-rush current
• Capacitance and temperature measurement functionality
• Auto power off functionality to save battery life
• Includes convenient carrying case
• Operates from (2) AAA batteries
Item # DSA1020TRMS
Specifications Range
Accuracy
Resolution
Overload
Protection
DC Voltage 600mV/6/60/600V 1% ±3dgt
100µV
720V AC/DC
AC Voltage 6/60/600V
1.5% ± 4dgt
1mV
720V AC/DC
DC Current
600/1000A
±1.5%rdg ± 5dgt
100mA 1200A AC/DC
AC Current
600/1000A
2%±5dgt
100mA 1200A AC/DC
Resistance 600/6K/60K/600K/
6M/60M
Ω
1% ±5dgt (600~6M
Ω
)
5% ±8dgt (6M~60M)
100m
Ω
600V AC/DC
Frequency
10/100/1000/10K 0.5%±5dgt
–
–
Diode Test
3
–
–
–
Cont Buzzer
0–600 Ohms
Buzzer Sounds @ 100
Ohms or less
Capacitance 40nF–4000µF
2.5%±20dgt (400nF–40µF)
NA (40nF, 40µF–4000µF)
Temperature 50° to 700°C/
58° to 1292°F
°C ±5°/ °F±9°
CAT Rating IV 600
–
–
–
Includes
Carrying Case
600V
