Connect:
DC Connections
ConnectPro
®
Receptacle
• Works with 12, 24, or 36 volt 2-wire
systems
• For front mount panel installations
• Weather resistant sealing cap
• Drain holes in receptacle keep water
away from electrical components
• Perma-Lock
™
screw terminals will not
loosen under extreme hull vibration
• Fits standard 1-1/8" diameter
mounting hole
• Accepts up to 10 gauge wire
Item # 12VBRS2
OEM #
12VBRS2.OEM
ConnectPro
®
Plug
• O-ring seal for waterproof connections
• Weather resistant plug cover
• Corrosion resistant, plated brass
electrical components
• Accepts 16 to 8 gauge wire
• Ergonomic contoured grip for easy
hook-up and ground blade alignment
• Max. rating is 40 amps
Item # 12VBPS2
OEM #
12VBPS2.OEM
ConnectPro
®
Receptacle & Plug
• 12VBRS2 and 12VBPS2 packaged
together
Item # 12VCPS2
ConnectPro
®
Plug
• O-ring seal for waterproof connections
• Weather resistant plug cover
• Corrosion resistant, plated brass
electrical components
• Accepts 16 to 8 gauge wire
• Ergonomic contoured grip for easy
hook-up and ground blade alignment
Item # 12VBP
OEM #
12VBP.OEM
6 Gauge ConnectPro
®
Wire
Receptacle Adapter
• Allows 6 gauge wire connection to
ConnectPro
®
receptacle
• Corrosion resistant, plated brass
electrical components
Item # 12VBRAD
OEM #
12VBRAD.OEM
PATENTED
3-Wire ConnectPro
®
Charging / Trolling System
ConnectPro
®
Receptacle
• Universal design for 2 or 3-wire
configuration 12, 24, 12/24, 24/36 or
36 volt systems
• Watertight sealing cap
• Corrosion resistant, plated brass
electrical components
• Drain holes in receptacle keep water
away from electrical components
• Perma-Lock
™
screw terminals will not
loosen under extreme hull vibration
• Standard 1-1/8" diameter
mounting hole
• Easy to install, with supplied mounting
plate for front panel installation, or
locking ring for rear access installation
• Accepts 10 and 8 gauge wire
• Easily replaces other trolling motor
plugs and receptacles
Item # 12VBR
OEM #
12VBR.OEM
Mounting plate not included with
12VBR.OEM
ConnectPro
®
Receptacle
& Plug
• 12VBR and 12VBP packaged together
Item # 12VCP
ConnectPro
®
Receptacle,
Plug & 6 Gauge Adapter
• 12VBR and 12VBP and
12 VBRAD packaged together
• Max. rating is 40 amps
Item # 12VCP6
2-Wire ConnectPro
TM
Charging / Trolling System / Downrigger
