Male Plug
Short housing, black nylon with internal
strain relief system and recessed
fasteners
Item # 305BP
OEM # 305BP.OEM
Female Connector
Short housing, black nylon with internal
strain relief system and recessed
fasteners
Item # 305BC
Receptacle
Corrosion resistant reinforced nylon.
Accepts 8 gauge stranded wire or up to
6 gauge with spade terminals
Item # 305CRRB
OEM # 305CRRB.OEM
3-wire 30 Amp/125V Locking Charging/Trolling System
Charger Plug (Male)
Item # 2018BP-12
Trolling Motor Plug (Male)
• Connects to trolling motor
• Jumpered internally to supply 12V &
24V power to the trolling motor when
plugged into the receptacle. Black
Item # 2018BP-24
OEM # 2018BP-24.OEM
Receptacle & Bracket
• Spring loaded flip lid cover and
2018BR receptacle, pre assembled
Item # 2018BR-MB
Bracket
• Spring loaded flip lid cover, without
receptacle
Item # 2018MB
OEM # 2018MB.OEM
4-Wire 12/24V Locking Charging / Trolling System
The 4-wire Trolling/Charging System eliminates the need for a charge/run switch.
Install the receptacle on the boat, mount the black trolling motor plug on the trolling
motor, and the red charger plug on the leads of the battery charger. Simply plug in
the black plug to troll, or plug in the red plug to charge.
12/24V
Locking
NEMA
L5-30R
W
G
30A
125V
Locking
Trolling-Charging
System Package
• Includes the 2018BP-12,
2018BP-24, and 2018BR-MB
Item # 2018PKG
Receptacle
• Glass-reinforced corrosion resistant
nylon. Accepts 8 gauge stranded wire
or up to 6 gauge with spade terminals.
Item # 2018BR
OEM # 2018BR.OEM
OEM # 2018BR.OEM.BPS (case pack)
