Generate:
Solar ChargeMaster
The sun as extra energy source
As photovoltaic cells generate energy when exposed to sunlight,
they can provide a sustainable energy source and charge the
batteries on your yacht.
All Mastervolt’s know-how in the field of solar power has been
included in the Solar ChargeMaster, which offers maximum efficiency
from the often irregular availability of sunlight. The design provides a
pure charge current in all conditions while the 3-step charging
method ensures a safe charging process and a longer lifespan for
your batteries.
Features
• Works with nearly all solar panels (PV-modules).
• Suitable for 12 V and 24 V battery systems.
• Clear LCD display and graphics.
• 3-Step charging method.
• Automatic night detection.
• Extensive alarm system (buzzer).
• Automatically switches off load when battery current is low.
• Battery temperature sensor included with each unit.
• Optional USB Interface for Solar ChargeMaster for PC and laptop.
SCM-N 20
SCM-N 40
Item #
131802000
131804000
Charge current
20A
40A
Max. DC load
20A
40A
Solar input voltage window 12–50V DC
12–50V DC
System voltage (battery)
12/24V auto detect
12/24V auto detect
No load
< 4 mA
< 4 mA
Functions LCD display
battery status/V/A/charge & discharge
Connections
screw terminal
screw terminal
Settings
load/disconnect, 3-step charge characteristic
Dimensions, hxwxd
5.5"x4.1"x1.6"
140x105x41 mm
5.5"x4.1"x1.6"
140x105x41 mm
Protection degree cabinet
IP20
IP20
Weight
2 lbs / 189 gr
2 lbs / 189 gr
Options
USB Interface
option
option
for Solar ChargeMaster
21730400
USB Interface and DataControl software, for faultless
communication between your PC and the Solar ChargeMaster.
Solar ChargeMaster Specifications
Generate
|
Regulators & Alternators
New MPPT Solar
Charge regulators
coming soon
On top of the existing
models, Mastervolt will
introduce a line of MPPT
(Maximum Power Point
Tracking) solar charge
regulators. This new range
has a charge current up to
60 A, and will increase the
energy production of your
solar panels up to 30%.
