toll free 800.334.5214 ACME ELECTRIC |
B u c k - B o o s t T r a n s f o r m e r s
Encapsulated
Single Phase, .05 to 10.0 kVA
Features
Q UL listed, CSA certified and UL 3R enclosure, meets or exceeds all listing criteria, including NEMA, ANSI, and
OSHA standards
Q Flexibility, can be used in single phase and three pase configurations
Q Reduce (buck) or raise (boost) line voltage from 5 - 20%
Q All copper lead wire terminations
Q Long Life, 80° C rise up to 0.15 kVA, and 115° C rise above 0.25 kVA
Q Can be used in Three Phase applications
Encapsulated
Three Phase, 3.0 to 150 kVA
Features
Q UL listed, CSA certified and UL 3R enclosure, meets or exceeds all listing criteria, including NEMA, ANSI,
and OSHA standards
Q One unit, instead of multiple for 3 phase applications
Q Time and installation cost savings as units come pre-wired from the factory
Q Smaller footprint compared to using three individual single phase units
Q Long Life, UL class 180° C insulation system, 115° C rise
Encapsulated NEMA 4X
Single Phase, 0.25 to 10.0 kVA
Features
Q UL listed NEMA 4X enclosure
Q Flexibility, can be used in single phase and three pase configurations
Q Reduce (buck) or raise (boost) line voltage from 5 - 20%
Q All copper lead wire terminations
Q Long Life, 80° C rise up to 0.15 kVA, and 115° C rise above 0.25 kVA
Q Can be used in Three Phase applications
