142 toll free 800.334.5214 ACME ELECTRIC |
P a n e l - T r a n® Z o n e P o w e r C e n t e r s Selection Charts
SNAP-IN BREAKERS
480 PRIMARY VOLTS –– 240/120 SECONDARY VOLTS –– 1Ø, 60 Hz Single Phase
kVA Catalog Number
Secondary Maximum
Circuit ①
120 V 240 V
(1-pole) (2-pole)
Height
(Inches)(Cm.)
Width
(Inches)(Cm.)
Depth
(Inches)(Cm.)
Weight
(Lbs.)(Kg.)
5.0 PT061150005LS 8 4 32.13 (81.6) 13.25 (33.7) 7.63 (19.4) 120 (54.4)
7.5 PT061150007LS 8 4 32.13 (81.6) 15.88 (40.3) 11.00 (27.9) 160 (72.6)
10.0 PT061150010LS 8 4 34.38 (87.3) 15.88 (40.3) 11.00 (27.9) 185 (83.9)
15.0 PT061150015LS 12 6 34.38 (87.3) 17.13 (43.5) 12.38 (31.4) 240 (109.0)
25.0 PT061150025LS 20 10 41.88 (106.4) 17.88 (45.4) 13.50 (34.3) 330 (150.0)
① The number of secondary circuits shown is only a representation of circuits. Please contact the factory for exact number of secondary circuits available.
304 STAINLESS STEEL/ SNAP-IN BREAKERS
480 PRIMARY VOLTS –– 240/120 SECONDARY VOLTS –– 1Ø, 60 Hz Single Phase
kVA Catalog Number
Secondary Maximum
Circuit ①
120 V 240 V
(1-pole) (2-pole)
Height
(Inches)(Cm.)
Width
(Inches)(Cm.)
Depth
(Inches)(Cm.)
Weight
(Lbs.)(Kg.)
5.0 PT061150005SS 8 4 32.13 (81.6) 13.25 (33.7) 7.63 (19.4) 120 (54.4)
7.5 PT061150007SS 8 4 32.13 (81.6) 15.88 (40.3) 11.00 (27.9) 160 (72.6)
10.0 PT061150010SS 8 4 34.38 (87.3) 15.88 (40.3) 11.00 (27.9) 185 (83.9)
15.0 PT061150015SS 12 6 34.38 (87.3) 17.13 (43.5) 12.38 (31.4) 240 (109.0)
25.0 PT061150025SS 20 10 41.88 (106.4) 17.88 (45.4) 13.50 (34.3) 330 (150.0)
① The number of secondary circuits shown is only a representation of circuits. Please contact the factory for exact number of secondary circuits available.
SNAP-IN BREAKERS
480 VOLTS to 240/120 VOLTS Circuit Breaker Data
kVA 480 Volts
primary breakers
240/120 Volts
secondary main
Maximum Rating of
Secondary Breakers
5.0 ED42B025L (25A) Q225 (25A) 20 amps
7.5 ED42B025L (25A) Q240 (40A) 30 amps
10.0 ED42B035L (35A) Q250 (50A) 40 amps
15.0 ED42B050L (50A) Q270 (70A) 60 amps
25.0 ED42B090L (90A) Q2125 (125A) 100 amps
