toll free 800.334.5214 ACME ELECTRIC |
Selection Charts P a n e l - T r a n ® Z o n e P o w e r C e n t e r s
BOLT-IN BREAKERS
480 PRIMARY VOLTS –– 240/120 SECONDARY VOLTS –– 1Ø, 60 Hz Single Phase
kVA Catalog Number
Secondary Maximum
Circuit ①
120 V 240 V
(1-pole) (2-pole)
Height
(Inches)(Cm.)
Width
(Inches)(Cm.)
Depth
(Inches)(Cm.)
Weight
(Lbs.)(Kg.)
5.0 PT0B1150005LS 16 8 38.00 (96.5) 15.88 (40.3) 11.00 (27.9) 165 (74.8)
7.5 PT0B1150007LS 16 8 38.00 (96.5) 15.88 (40.3) 11.00 (27.9) 165 (74.8)
10.0 PT0B1150010LS 16 8 38.00 (96.5) 17.13 (43.5) 12.38 (31.4) 240 (108.8)
15.0 PT0B1150015LS 16 8 38.00 (96.5) 17.13 (43.5) 12.38 (31.4) 240 (109.0)
25.0 PT0B1150025LS 28 14 45.20 (114.8) 17.88 (45.4) 13.50 (34.3) 330 (150.0)
① The number of secondary circuits shown is only a representation of circuits. Please contact the factory for exact number of secondary circuits available.
304 STAINLESS STEEL/ BOLT-IN BREAKERS
480 PRIMARY VOLTS –– 240/120 SECONDARY VOLTS –– 1Ø, 60 Hz Single Phase
kVA Catalog Number
Secondary Maximum
Circuit ①
120 V 240 V
(1-pole) (2-pole)
Height
(Inches)(Cm.)
Width
(Inches)(Cm.)
Depth
(Inches)(Cm.)
Weight
(Lbs.)(Kg.)
5.0 PT0B1150005SS 16 8 38.00 (96.5) 15.88 (40.3) 11.00 (27.9) 165 (74.8)
7.5 PT0B1150007SS 16 8 38.00 (96.5) 15.88 (40.3) 11.00 (27.9) 165 (74.8)
10.0 PT0B1150010SS 16 8 34.38 (87.3) 17.13 (43.5) 12.38 (31.4) 240 (108.8)
15.0 PT0B1150015SS 16 8 34.38 (87.3) 17.13 (43.5) 12.38 (31.4) 240 (109.0)
25.0 PT0B1150025SS 28 14 41.88 (106.4) 17.88 (45.4) 13.50 (34.3) 330 (150.0)
① The number of secondary circuits shown is only a representation of circuits. Please contact the factory for exact number of secondary circuits available.
BOLT-IN BREAKERS
480 VOLTS to 240/120 VOLTS Circuit Breaker Data
kVA
480 Volts
primary breakers
240/120 Volts
secondary main
Maximum Rating of
Secondary Breakers
5.0 ED42B025L (25A) B230H (30A) 20 amps
7.5 ED42B025L (25A) B240H (40A) 30 amps
10.0 ED42B035L (35A) B250H (50A) 40 amps
15.0 ED42B050L (50A) B270H (70A) 60 amps
25.0 ED42B090L (90A) B2125 (125A) 100 amps
