toll free 800.334.5214 ACME ELECTRIC |
hubbell-acmeelectric.comD r y - T y p e D i s t r i b u t i o n T r a n s f o r m e r s
Selection Charts
600 DELTA PRIMARY VOLTS — 480Y/277 TAP SECONDARY VOLTS — 3Ø, 60 Hz
kVA
Catalog
Number
Height
(Inches)(Cm.)
Width
(Inches)(Cm.)
Depth
(Inches)(Cm.)
Weight
(Lbs.)(Kg.)
Mounting Type
(Wall)(Floor)
Knockouts
(Inches)(Cm.)
Optional
Electrostatic
Shield
Wiring
Diagrams
Design
Figures
3.0
②
T2A795161S 10.38 (26.4)
12.37 (31.4)
7.47 (19.0)
75 (34.0)
W
0.75-1.25 (1.9-3.2)
STD.
55
F
6.0
②
T2A795171S 11.83 (30.0)
14.17 (36.0)
8.82 (22.4)
140 (63.5)
W
0.75-1.25 (1.9-3.2)
STD.
55
F
9.0
②
T2A795181S 14.03 (38.8)
17.77 (45.1)
11.52 (29.3)
180 (81.6)
W
0.75-1.25 (1.9-3.2)
STD.
55
F
15.0
②
T3795191S 18.86 (47.9)
20.30 (51.6)
9.03 (22.9)
250 (113.0)
F
①
NA
STD.
55
I
15.0 T3015K0093BS 25.50 (64.8)
24.39 (61.9)
19.37 (49.2)
300 (136.0)
F
①
NA
STD.
51
E
30.0 T3030K0093BS 25.50 (64.8)
24.39 (61.9)
19.37 (49.2)
360 (163.3)
F
①
NA
STD.
51
E
45.0 T3045K0093BS 25.50 (64.8)
24.39 (61.9)
19.37 (49.2)
500 (226.8)
F
①
NA
STD.
51
E
75.0 T3075K0093BS 29.41 (74.7)
28.15 (71.5)
22.37 (56.8)
600 (272.2)
F
①
NA
STD.
51
E
112.5 T3112K0093BS 35.47 (90.1)
31.90 (81.0)
26.88 (68.2)
938 (425.5)
F
NA
STD.
51
E
150.0 T3150K0093BS 41.52 (105.4)
32.90 (83.5)
29.87 (75.9)
1406 (637.8)
F
NA
STD.
51
E
①
Wall mounting brackets are available for these sizes, refer to page 217.
②
DOE 2016 exempt, encapsulated unit
600 DELTA PRIMARY VOLTS — 240 DELTA/120 TAP SECONDARY VOLTS — 3Ø, 60 Hz
kVA
Catalog
Number
Height
(Inches)(Cm.)
Width
(Inches)(Cm.)
Depth
(Inches)(Cm.)
Weight
(Lbs.)(Kg.)
Mounting Type
(Wall)(Floor)
Knockouts
(Inches)(Cm.)
Optional
Electrostatic
Shield
Wiring
Diagrams
Design
Figures
15.0 T3015K0323BS 25.50 (64.8)
24.39 (61.9)
19.37 (49.2)
300 (136.0)
F
①
NA
STD.
69
E
30.0 T3030K0323BS 25.50 (64.8)
24.39 (61.9)
19.37 (49.2)
360 (163.3)
F
①
NA
STD.
69
E
45.0 T3045K0323BS 25.50 (64.8)
24.39 (61.9)
19.37 (49.2)
500 (226.8)
F
①
NA
STD.
69
E
75.0 T3075K0323BS 29.41 (74.7)
28.15 (71.5)
22.37 (56.8)
600 (272.2)
F
①
NA
STD.
69
E
①
Wall mounting brackets are available for these sizes, refer to page 217.
600 DELTA PRIMARY VOLTS — 208Y120 SECONDARY VOLTS — 3Ø, 60 Hz NEMA 4X
kVA
Catalog
Number
Height
(Inches)(Cm.)
Width
(Inches)(Cm.)
Depth
(Inches)(Cm.)
Weight
(Lbs.)(Kg.)
Mounting Type
(Wall)(Floor)
Knockouts
(Inches)(Cm.)
Optional
Electrostatic
Shield
Wiring
Diagrams
Design
Figures
3.0
①
T3003K0081X
10.38 (26.3)
12.37 (31.4)
7.47 (18.9)
75 (34.0)
W
NA
NA
28
J
6.0
①
T3006K0081X
11.83 (30.0)
14.17 (35.9)
8.82 (22.4)
140 (63.5)
W
NA
NA
28
J
9.0
①
T3009K0081X
14.03 (35.6)
17.77 (45.1)
11.52 (29.2)
180 (81.6)
W
NA
NA
28
J
①
DOE 2016 exempt, encapsulated unit
600 DELTA PRIMARY VOLTS — 480Y DELTA/277 TAP SECONDARY VOLTS — 3Ø, 60 Hz NEMA 4X
kVA
Catalog
Number
Height
(Inches)(Cm.)
Width
(Inches)(Cm.)
Depth
(Inches)(Cm.)
Weight
(Lbs.)(Kg.)
Mounting Type
(Wall)(Floor)
Knockouts
(Inches)(Cm.)
Optional
Electrostatic
Shield
Wiring
Diagrams
Design
Figures
3.0
①
T3003K0091X
10.38 (26.3)
12.37 (31.4)
7.47 (18.9)
75 (34.0)
W
NA
NA
55
J
6.0
①
T3006K0091X
11.83 (30.0)
14.17 (35.9)
8.82 (22.4)
140 (63.5)
W
NA
NA
55
J
9.0
①
T3009K0091X
14.03 (35.6)
17.77 (45.1)
11.52 (29.2)
180 (81.6)
W
NA
NA
55
J
①
DOE 2016 exempt, encapsulated unit
All Wiring Diagrams begin on page 209.
