hubbell-acmeelectric.comD r y - T y p e D i s t r i b u t i o n T r a n s f o r m e r s
Selection Charts
440 DELTA PRIMARY VOLTS — 220Y/127 SECONDARY VOLTS — 3Ø, 50 Hz
kVA
Catalog
Number
Height
(Inches)(Cm.)
Width
(Inches)(Cm.)
Depth
(Inches)(Cm.)
Weight
(Lbs.)(Kg.)
Mounting Type
(Wall)(Floor)
Knockouts
(Inches)(Cm.)
Weather
Shield
Wiring
Diagrams
Design
Figures
10.0 TF220105S 18.90 (48.0)
20.30 (51.6)
9.00 (22.9)
245 (111.1)
F
①
NA
NA
73
I
15.0 TF220155S 25.50 (64.8)
24.40 (62.0)
19.40 (49.3)
291 (132.0)
F
①
NA
WSA1
73
E
25.0 TF220255S 25.50 (64.8)
24.40 (62.0)
19.40 (49.3)
375 (170.1)
F
①
NA
WSA1
73
E
50.0 TF220505S 29.41 (74.7)
28.15 (71.5)
22.37 (56.8)
437 (198.2)
F
①
NA
WSA2
73
E
Notes: 50 Hz units (DOE 2016 exempt)
①
Wall mounting brackets are available for these sizes, refer to page 217.
480 DELTA PRIMARY VOLTS — 208Y/120 SECONDARY VOLTS —MAY BE USED ON A 4 WIRE 480Y/277 VOLTS SUPPLY— 3Ø, 60 Hz
kVA
Catalog
Number
Height
(Inches)(Cm.)
Width
(Inches)(Cm.)
Depth
(Inches)(Cm.)
Weight
(Lbs.)(Kg.)
Mounting Type
(Wall)(Floor)
Knockouts
(Inches)(Cm.)
Optional
Electrostatic
Shield
Wiring
Diagrams
Design
Figures
3.0
②
T2A533081S 10.38 (26.4)
12.37 (31.4)
7.47 (19.0)
75 (34.0)
W
0.75-1.25 (1.9-3.2)
STD.
21
F
6.0
②
T2A533091S 11.83 (30.0)
14.17 (36.0)
8.82 (22.4)
140 (63.5)
W
0.75-1.25 (1.9-3.2)
STD.
21
F
9.0
②
T2A533101S 14.03 (36.0)
17.77 (45.1)
11.52 (29.3)
180 (81.6)
W
0.75-1.25 (1.9-3.2)
STD.
21
F
15.0
②
T3533111S 18.86 (48.0)
20.30 (51.6)
9.03 (22.9)
250 (113.0)
F
①
NA
STD.
21
I
15.0 T3015K0013B 25.50 (64.8)
24.39 (61.9)
19.37 (49.2)
300 (136.0)
F
①
NA
YES
}
22
E
30.0 T3030K0013B 25.50 (64.8)
24.39 (61.9)
19.37 (49.2)
360 (163.2)
F
①
NA
YES
}
22
E
45.0 T3045K0013B 25.50 (64.8)
24.39 (61.9)
19.37 (49.2)
500 (226.8)
F
①
NA
YES
}
22
E
75.0 T3075K0013B 29.41 (74.7)
28.15 (71.5)
22.37 (56.8)
600 (272.2)
F
①
NA
YES
}
22
E
112.5 T3112K0013B 35.47 (90.1)
31.90 (81.0)
26.88 (68.2)
938 (425.5)
F
NA
YES
}
22
E
150.0 T3150K0013B 41.52 (105.4)
32.90 (83.5)
29.87 (75.9)
1213 (550.2)
F
NA
YES
}
22
E
225.0 T3225K0013B 41.52 (105.4)
32.90 (83.5)
29.87 (75.9)
1500 (680.4)
F
NA
YES
}
22
E
300.0 T3300K0013B 45.60 (115.8)
39.50 (100.3)
35.50 (90.1)
1938 (879.0)
F
NA
YES
}
22
E
500.0 T3500K0013B 57.80 (147.0)
45.60 (115.8)
41.50 (105.4)
3100 (1406.1)
F
NA
YES
}
22
G
750.0 T3750K0013B 62.80 (159.5)
54.00 (137.1)
41.50 (105.4)
4500 (2041.1)
F
NA
YES
}
22
G
1000.0 T3001M0012B 62.80 (159.5)
54.00 (137.1)
41.50 (105.4)
5375 (2438.0)
F
NA
YES
}
80
G
①
Wall mounting brackets are available for these sizes, refer to page 217.
②
DOE 2016 exempt, encapsulated unit
}
Add “S” to part number
480 DELTA PRIMARY VOLTS –– COPPER WINDINGS –– 208Y/120 SECONDARY VOLTS –– 3Ø, 60 Hz
kVA
Catalog
Number
Height
(Inches)(Cm.)
Width
(Inches)(Cm.)
Depth
(Inches)(Cm.)
Weight
(Lbs.)(Kg.)
Mounting Type
(Wall)(Floor)
Knockouts
(Inches)(Cm.)
Optional
Electrostatic
Shield
Wiring
Diagrams
Design
Figures
15.0
②
TC533111S 18.86 (48.0)
20.30 (51.6)
9.03 (22.9)
245 (111.0)
F
①
NA
STD.
21
I
15.0 T3015K0013BC 25.50 (64.8)
24.39 (61.9)
19.37 (49.2)
353 (160.1)
F
①
NA
YES
}
22
E
30.0 T3030K0013BC 25.50 (64.8)
24.39 (61.9)
19.37 (49.2)
498 (225.9)
F
①
NA
YES
}
22
E
45.0 T3045K0013BC 25.50 (64.8)
24.39 (61.9)
19.37 (49.2)
572 (259.5)
F
①
NA
YES
}
22
E
75.0 T3075K0013BC 29.41 (74.7)
28.15 (71.5)
22.37 (56.8)
750 (340.2)
F
NA
YES
}
22
E
112.5 T3112K0013BC 35.47 (90.1)
31.90 (81.0)
26.88 (68.2)
1103 (500.3)
F
NA
YES
}
22
E
150.0 T3150K0013BC 41.52 (105.4)
32.90 (83.5)
29.87 (75.9)
1477 (669.9)
F
NA
YES
}
22
E
225.0 T3225K0013BC 41.52 (105.4)
32.90 (83.5)
29.87 (75.9)
1872 (849.1)
F
NA
YES
}
22
E
300.0 T3300K0013BC 45.60 (115.8)
39.50 (100.3)
35.50 (90.1)
2233 (1012.9)
F
NA
YES
}
22
E
500.0 T3500K0013BC 57.80 (147.0)
45.60 (115.8)
41.50 (105.4)
4059 (1841.1)
F
NA
YES
}
22
G
750.0 T3750K0013BC 62.80 (159.5)
54.00 (137.1)
41.50 (105.4)
6192 (2808.6)
F
NA
YES
}
22
G
①
Wall mounting brackets are available for these sizes, refer to page 217.
②
DOE 2016 exempt, encapsulated unit, 115º C rise
}
Add “S” to part number
All Wiring Diagrams begin on page 209.
