toll free 800.334.5214 ACME ELECTRIC |
hubbell-acmeelectric.comSelection Charts
D r y - T y p e D i s t r i b u t i o n T r a n s f o r m e r s
240 DELTA PRIMARY VOLTS — 208Y/120 SECONDARY VOLTS — 3Ø, 60 Hz
kVA
Catalog
Number
Height
(Inches)(Cm.)
Width
(Inches)(Cm.)
Depth
(Inches)(Cm.)
Weight
(Lbs.)(Kg.)
Mounting Type
(Wall)(Floor)
Knockouts
(Inches)(Cm.)
Optional
Electrostatic
Shield
Wiring
Diagrams
Design
Figures
9.0
②
T2A533601S 14.03 (36.0)
17.77 (45.1)
11.52 (29.3)
180 (81.6)
W
0.75-1.25 (1.9-3.2)
STD.
18
F
15.0
②
T3533611S 18.86 (48.0)
20.30 (51.6)
9.03 (23.0)
250 (113.0)
F
①
NA
STD.
18
I
15.0 T3015K0044B 25.50 (64.8)
24.39 (61.9)
19.37 (49.2)
300 (136.0)
F
①
NA
YES
}
19
E
30.0 T3030K0044B 25.50 (64.8)
24.39 (61.9)
19.37 (49.2)
360 (163.2)
F
①
NA
YES
}
19
E
45.0 T3045K0044B 25.50 (64.8)
24.39 (61.9)
19.37 (49.2)
438 (198.6)
F
①
NA
YES
}
19
E
75.0 T3075K0044B 29.41 (74.7)
28.15 (71.5)
22.37 (56.8)
600 (272.2)
F
①
NA
YES
}
19
E
112.5 T3112K0044B 35.47 (90.1)
31.90 (81.0)
26.88 (68.2)
870 (394.6)
F
NA
YES
}
19
E
150.0 T3150K0044B 41.52 (105.4)
32.90 (83.5)
29.87 (75.9)
1223 (554.7)
F
NA
YES
}
19
E
225.0 T3225K0044B 41.52 (105.4)
32.90 (83.5)
29.87 (75.9)
1500 (680.4)
F
NA
YES
}
19
E
①
Wall mounting brackets are available for these sizes, refer to page 217.
②
DOE 2016 exempt, encapsulated unit
240 DELTA PRIMARY VOLTS — 480Y/277 SECONDARY VOLTS — 3Ø, 60 Hz
kVA
Catalog
Number
Height
(Inches)(Cm.)
Width
(Inches)(Cm.)
Depth
(Inches)(Cm.)
Weight
(Lbs.)(Kg.)
Mounting Type
(Wall)(Floor)
Knockouts
(Inches)(Cm.)
Optional
Electrostatic
Shield
Wiring
Diagrams
Design
Figures
15.0
②
T3796931S 18.90 (48.0)
20.30 (51.6)
9.00 (22.9)
245 (111.1)
F
①
NA
STD.
70
I
15.0 T3015K0074B 25.50 (64.8)
24.39 (61.9)
19.37 (49.2)
300 (136.0)
F
①
NA
YES
}
71
E
30.0 T3030K0074B 25.50 (64.8)
24.39 (61.9)
19.37 (49.2)
360 (163.2)
F
①
NA
YES
}
71
E
45.0 T3045K0074B 25.50 (64.8)
24.39 (61.9)
19.37 (49.2)
475 (215.5)
F
①
NA
YES
}
71
E
75.0 T3075K0074B 29.41 (74.7)
28.15 (71.5)
22.37 (56.8)
600 (272.2)
F
①
NA
YES
}
71
E
112.5 T3112K0074B 35.47 (90.1)
31.90 (81.0)
26.88 (68.2)
859 (389.6)
F
NA
YES
}
71
E
150.0 T3150K0074B 41.52 (105.4)
32.90 (83.5)
29.87 (75.9)
1216 (551.6)
F
NA
YES
}
71
E
①
Wall mounting brackets are available for these sizes, refer to page 217.
②
DOE 2016 exempt, encapsulated unit
}
Add “S” to part number
380 DELTA PRIMARY VOLTS — 220Y/127 SECONDARY VOLTS — 3Ø, 50 Hz
kVA
Catalog
Number
Height
(Inches)(Cm.)
Width
(Inches)(Cm.)
Depth
(Inches)(Cm.)
Weight
(Lbs.)(Kg.)
Mounting Type
(Wall)(Floor)
Knockouts
(Inches)(Cm.)
Weather
Shield
Wiring
Diagrams
Design
Figures
15.0 T3795511S 20.80 (52.8)
20.90 (53.1)
10.20 (25.9)
435 (197.3)
F
NA
NA
24
I
30.0 T2A795523S 25.50 (64.8)
24.40 (62.0)
19.40 (49.3)
365 (165.6)
F
①
NA
WSA1
20
E
45.0 T2A795533S 29.41 (74.7)
28.15 (71.5)
22.37 (56.8)
468 (212.3)
F
①
NA
WSA2
20
E
75.0 T2A795543S 35.47 (90.1)
31.90 (80.0)
26.88 (68.3)
693 (314.3)
F
NA
WSA3
20
E
112.5 T2A795553S 41.52 (105.4)
32.90 (83.5)
29.87 (75.9)
970 (440.0)
F
NA
WSA4
20
E
Notes: 50 Hz units (DOE 2016 exempt)
①
Wall mounting brackets are available for these sizes, refer to page 217.
All Wiring Diagrams begin on page 209
240 DELTA PRIMARY VOLTS — 208Y120 SECONDARY VOLTS — 3Ø, 60 Hz NEMA 4X
kVA
Catalog
Number
Height
(Inches)(Cm.)
Width
(Inches)(Cm.)
Depth
(Inches)(Cm.)
Weight
(Lbs.)(Kg.)
Mounting Type
(Wall)(Floor)
Knockouts
(Inches)(Cm.)
Optional
Electrostatic
Shield
Wiring
Diagrams
Design
Figures
3.0
①
T3003K0041X
10.38 (26.3)
12.37 (31.4)
7.47 (18.9)
75 (34.0)
W
NA
NA
18
J
6.0
①
T3006K0041X
11.83 (30.0)
14.17 (35.9)
8.82 (22.4)
140 (63.5)
W
NA
NA
18
J
9.0
①
T3009K0041X
14.03 (35.6)
17.77 (45.1)
11.52 (29.2)
180 (81.6)
W
NA
NA
18
J
①
DOE 2016 exempt, encapsulated unit
