toll free 800.334.5214 ACME ELECTRIC |
hubbell-acmeelectric.comSelection Charts
D r y - T y p e D i s t r i b u t i o n T r a n s f o r m e r s
600 PRIMARY VOLTS — 120/240 SECONDARY VOLTS — THREE WINDINGS — 1Ø, 60 Hz
kVA
Catalog
Number
Height
(Inches)(Cm.)
Width
(Inches)(Cm.)
Depth
(Inches)(Cm.)
Weight
(Lbs.)(Kg.)
Mounting Type
(Wall)(Floor)
Knockouts
(Inches)(Cm.)
Weather
Shield
Wiring
Diagrams
Design
Figures
.05
①
T153104
6.41 (16.3)
3.14 (8.0)
3.05 (7.7)
4 (1.8)
W
0.875 (2.2)
NA
8
A
.10
①
T153105
7.16 (18.2)
3.89 (9.9)
3.67 (9.3)
5 (2.3)
W
0.875 (2.2)
NA
8
A
.15
①
T153106
7.16 (18.2)
3.89 (9.9)
3.67 (9.3)
7 (3.2)
W
0.875 (2.2)
NA
8
A
.25
①
T253107S 8.68 (22.0)
4.08 (10.4)
3.88 (9.9)
10 (4.5)
W
0.50-0.75 (1.3-1.9)
NA
9
B
.50
①
T253108S 9.06 (23.0)
4.37 (11.1)
4.20 (10.7)
15 (6.8)
W
0.50-0.75 (1.3-1.9)
NA
9
B
.75
①
T253109S 9.68 (24.6)
4.75 (12.1)
4.50 (11.4)
19 (8.6)
W
0.50-0.75 (1.3-1.9)
NA
9
B
1.00
T253110S 10.50 (26.7)
5.50 (14.0)
5.13 (13.0)
24 (10.9)
W
0.50-0.75 (1.3-1.9)
NA
9
B
1.50
T253111S 11.62 (29.5)
5.50 (14.0)
5.13 (13.0)
30 (13.6)
W
0.50-0.75 (1.3-1.9)
NA
9
B
2.00
T253112S 13.00 (33.0)
5.50 (14.0)
5.13 (13.0)
38 (17.2)
W
0.50-0.75 (1.3-1.9)
NA
9
B
3.00 T2531131S 11.50 (29.2)
10.31 (26.2)
7.13 (18.1)
55 (24.9)
W
0.75-1.25 (1.9-3.2)
NA
10
C
5.00 T2531141S 14.38 (36.5)
10.31 (26.2)
7.13 (18.1)
75 (34.0)
W
0.75-1.25 (1.9-3.2)
NA
10
C
7.50 T2536151S 15.19 (38.6)
13.50 (34.3)
10.84 (27.5)
115 (52.2)
W
0.75-1.25 (1.9-3.2)
NA
10
D
10.00 T2536161S 15.19 (38.6)
13.50 (34.3)
10.84 (27.5)
125 (56.7)
W
0.75-1.25 (1.9-3.2)
NA
10
D
15.00 T2536171S 16.94 (43.0)
14.12 (35.9)
11.59 (29.4)
170 (77.1)
W
1.00-1.50 (2.5-3.8)
NA
10
D
25.00 T2536181S 18.44 (46.8)
16.13 (41.0)
13.34 (33.9)
250 (113.0)
W
1.00-1.50 (2.5-3.8)
NA
10
D
37.50 TP531193S 25.50 (64.8)
24.40 (62.0)
19.40 (49.3)
275 (125.0)
F
②
NA
WSA1
11
E
50.00 TP531203S 29.90 (76.0)
28.15 (71.5)
22.37 (56.8)
340 (154.0)
F
②
NA
WSA2
11
E
75.00 TP531213S 35.47 (90.0)
31.90 (81.0)
26.88 (68.3)
430 (195.0)
F
NA
WSA3
11
E
100.00 TP531223S 41.52 (105.4)
32.90 (83.5)
29.87 (75.9)
525 (238.0)
F
NA
WSA4
11
E
167.00 TP531233S 45.60 (115.8)
39.5 (100.3)
35.5 (90.2)
1050 (476.3)
F
NA
WSA5
11
E
Notes: 0.05 kVA through 25.0 kVA encapsulated (exempt from DOE 2016), 37.5 through 167.0 kVA DOE 2016 compliant
①
Suitable for 50/60Hz
②
Wall mounting brackets are available for these sizes, refer to page 217.
All Wiring Diagrams begin on page 209.
600 PRIMARY VOLTS — 120/240 SECONDARY VOLTS — 1Ø, 60 Hz NEMA 4X
kVA
Catalog
Number
Height
(Inches)(Cm.)
Width
(Inches)(Cm.)
Depth
(Inches)(Cm.)
Weight
(Lbs.)(Kg.)
Mounting Type
(Wall)(Floor)
Knockouts
(Inches)(Cm.)
Optional
Electrostatic
Shield
Wiring
Diagrams
Design
Figures
0.25 T1250V0200X 8.7 (22.0)
4.1 (10.4)
3.9 (9.9)
10 (4.5)
W
NA
NA
2
J
0.50 T1500V0200X 9.7 (24.6)
4.75 (12.0)
4.5 (11.4)
15 (6.8)
W
NA
NA
2
J
0.75 T1750V0200X 9.7 (24.6)
4.75 (12.0)
4.5 (11.4)
19 (8.6)
W
NA
NA
2
J
1.00 T1001K0200X 12.5 (31.7)
5.5 (13.9)
5.13 (13.0)
24 (10.9)
W
NA
NA
2
J
1.50 T1105K0200X 12.5 (31.7)
5.5 (13.9)
5.13 (13.0)
30 (13.6)
W
NA
NA
2
J
2.00 T1002K0200X 12.5 (31.7)
5.5 (13.9)
5.13 (13.0)
38 (17.2)
W
NA
NA
2
J
3.00 T1003K0200X 14.0 (35.5)
10.31 (26.1)
7.13 (18.1)
55 (24.9)
W
NA
NA
2
J
5.00 T1005K0200X 14.0 (35.5)
10.31 (26.1)
7.13 (18.1)
75 (34.0)
W
NA
NA
2
J
