Selection Charts
208 PRIMARY VOLTS — 120/240 SECONDARY VOLTS — THREE WINDINGS — 1Ø, 60 Hz
kVA
Catalog
Number
Height
(Inches)(Cm.)
Width
(Inches)(Cm.)
Depth
(Inches)(Cm.)
Weight
(Lbs.)(Kg.)
Mounting Type
(Wall)(Floor)
Knockouts
(Inches)(Cm.)
Weather
Shield
Wiring
Diagrams
Design
Figures
37.5
TP536491S 25.50 (64.8)
24.40 (62.0)
19.40 (49.3)
257 (117.0)
F
②
N/A
WSA1
58
E
50.0
TP536503S 25.50 (64.8)
24.40 (62.0)
19.40 (49.3)
340 (154.2)
F
②
N/A
WSA1
17
E
75.0
TP536513S 35.40 (89.9)
31.90 (81.0)
26.88 (68.2)
420 (190.5)
F
N/A
WSA3
17
E
Notes: 1.0 kVA through 25.0 kVA encapsulated (exempt from DOE 2016), 37.5 through 75 kVA DOE 2016 compliant
②
Wall mounting brackets are available for these sizes, refer to page 217.
190/208/220/240 X 380/416/440/480 PRIMARY VOLTS — 120/240 SECONDARY VOLTS — 1Ø, 50/60 Hz EXPORT MODEL
kVA
Catalog
Number
Height
(Inches)(Cm.)
Width
(Inches)(Cm.)
Depth
(Inches)(Cm.)
Weight
(Lbs.)(Kg.)
Mounting Type
(Wall)(Floor)
Knockouts
(Inches)(Cm.)
Weather
Shield
Wiring
Diagrams
Design
Figures
*1.0
TF279260S 10.50 (26.7)
5.50 (14.0)
5.13 (13.0)
24 (10.9)
W
0.50-0.75 (1.3-1.9)
NA
64
B
*2.0
TF279261S 13.00 (33.0)
5.50 (14.0)
5.13 (13.0)
38 (17.2)
W
0.50-0.75 (1.3-1.9)
NA
64
B
*3.0
TF279262S 11.50 (29.2)
10.31 (26.2)
7.13 (18.1)
55 (24.9)
W
0.75-1.25 (1.9-3.2)
NA
64
C
*5.0
TF279263S 14.38 (36.5)
10.31 (26.2)
7.13 (18.1)
75 (34.0)
W
0.75-1.25 (1.9-3.2)
NA
64
C
*7.5
TF279264S 15.19 (38.6)
13.50 (34.3)
10.84 (27.5)
115 (52.2)
W
0.75-1.25 (1.9-3.2)
NA
64
D
*10.0 TF279265S 15.19 (38.6)
13.50 (34.3)
10.84 (27.5)
125 (56.7)
W
0.75-1.25 (1.9-3.2)
NA
64
D
*15.0 TF279266S 16.94 (43.0)
14.12 (35.9)
11.59 (29.4)
170 (77.1)
W
1.00-1.50 (2.5-3.8)
NA
64
D
*25.0 TF279267S 18.44 (46.8)
16.13 (41.0)
13.34 (33.9)
300 (136.1)
W
1.00-1.50 (2.5-3.8)
NA
64
D
*CE Marked
Maximum exciting current 5% at 50 Hz.
240 PRIMARY VOLTS — 120/240 SECONDARY VOLTS — 1Ø, 60 Hz AUTO-TRANSFORMERS
kVA
Catalog
Number
Height
(Inches)(Cm.)
Width
(Inches)(Cm.)
Depth
(Inches)(Cm.)
Weight
(Lbs.)(Kg.)
Mounting Type
(Wall)(Floor)
Knockouts
(Inches)(Cm.)
Weather
Shield
Wiring
Diagrams
Design
Figures
1.0
T253060
9.06 (23.0)
4.37 (11.1)
4.20 (10.7)
15 (6.8)
W
0.50-0.75 (1.3-1.9)
NA
12
B
1.5
T253061
9.68 (24.6)
4.50 (11.4)
4.51 (11.5)
19 (8.6)
W
0.50-0.75 (1.3-1.9)
NA
12
B
2.0
T253062
10.50 (26.7)
5.50 (14.0)
5.13 (13.0)
24 (10.9)
W
0.50-0.75 (1.3-1.9)
NA
12
B
3.0
T253063
11.62 (29.5)
5.50 (14.0)
5.13 (13.0)
30 (13.6)
W
0.50-0.75 (1.3-1.9)
NA
12
B
5.0
T253064
13.00 (33.0)
5.50 (14.0)
5.13 (13.0)
38 (17.2)
W
0.50-0.75 (1.3-1.9)
NA
12
B
7.5
T253065
11.50 (29.2)
10.31 (26.2)
7.13 (18.1)
55 (24.9)
W
0.75-1.25 (1.9-3.2)
NA
12
C
10.0
T253066
15.19 (38.6)
13.50 (34.3)
10.84 (27.5)
115 (52.2)
W
0.75-1.25 (1.9-3.2)
NA
12
D
15.0
T253067
15.19 (38.6)
13.50 (34.3)
10.84 (27.5)
115 (52.2)
W
0.75-1.25 (1.9-3.2)
NA
12
D
All Wiring Diagrams begin on page 209.
