toll free 800.334.5214 ACME ELECTRIC |
hubbell-acmeelectric.comD r y - T y p e D i s t r i b u t i o n T r a n s f o r m e r s
Selection Charts
208 DELTA PRIMARY VOLTS — 480Y/277 SECONDARY VOLTS — 3Ø, 60 Hz
kVA
Catalog
Number
Height
(Inches)(Cm.)
Width
(Inches)(Cm.)
Depth
(Inches)(Cm.)
Weight
(Lbs.)(Kg.)
Mounting Type
(Wall)(Floor)
Knockouts
(Inches)(Cm.)
Optional
Electrostatic
Shield
Wiring
Diagrams
Design
Figures
15.0
②
T3793671S 18.86 (48.0)
20.30 (51.6)
9.03 (22.9)
245 (111.0)
F
①
NA
STD.
48
I
15.0 T3015K0034B 25.50 (64.8)
24.39 (61.9)
19.37 (49.2)
300 (136.0)
F
①
NA
YES
}
46
E
30.0 T3030K0034B 25.50 (64.8)
24.39 (61.9)
19.37 (49.2)
360 (163.2)
F
①
NA
YES
}
46
E
45.0 T3045K0034B 25.50 (64.8)
24.39 (61.9)
19.37 (49.2)
500 (226.8)
F
①
NA
YES
}
46
E
75.0 T3075K0034B 29.41 (74.7)
28.15 (71.5)
22.37 (56.8)
600 (272.2)
F
①
NA
YES
}
46
E
112.5 T3112K0034B 35.47 (90.1)
31.90 (81.0)
26.88 (68.2)
938 (425.5)
F
NA
YES
}
46
E
150.0 T3150K0034B 41.52 (105.4)
32.90 (83.5)
29.87 (75.9)
1188 (538.9)
F
NA
YES
}
46
E
225.0 T3225K0034B 41.52 (105.4)
32.90 (83.5)
29.87 (75.9)
1500 (680.4)
F
NA
YES
}
46
E
300.0 T3300K0034B 45.60 (115.8)
39.50 (100.3)
35.50 (90.1)
1938 (879.0)
F
NA
YES
}
46
E
①
Wall mounting brackets are available for these sizes, refer to page 217.
②
DOE 2016 exempt, encapsulated unit
}
Add “S” to part number
THREE PHASE
190/200/208/220/230/240 DELTA PRIMARY VOLTS — 400Y/231 SECONDARY VOLTS — 3Ø, 60 Hz
kVA
Catalog
Number
Height
(Inches)(Cm.)
Width
(Inches)(Cm.)
Depth
(Inches)(Cm.)
Weight
(Lbs.)(Kg.)
Mounting Type
(Wall)(Floor)
Knockouts
(Inches)(Cm.)
Optional
Electrostatic
Shield
Wiring
Diagrams
Design
Figures
15.0
②
T379083S 18.86 (47.9)
20.30 (51.6)
9.03 (22.9)
300 (136.1)
F
①
NA
STD.
75
E
15.0 T3015K0170BS 25.50 (64.8)
24.39 (61.9)
19.37 (49.2)
300 (136.0)
F
①
NA
STD.
74
E
30.0 T3030K0170BS 25.50 (64.8)
24.39 (61.9)
19.37 (49.2)
360 (163.2)
F
①
NA
STD.
74
E
45.0 T3045K0170BS 25.50 (64.8)
24.39 (61.9)
19.37 (49.2)
675 (306.1)
F
①
NA
STD.
74
E
75.0 T3075K0170BS 29.41 (74.7)
28.15 (71.5)
22.37 (56.8)
600 (272.2)
F
①
NA
STD.
74
E
①
Wall mounting brackets are available for these sizes, refer to page 217.
②
DOE 2016 exempt, encapsulated unit
208 DELTA PRIMARY VOLTS — 208Y/120 SECONDARY VOLTS — 3Ø, 60 Hz
kVA
Catalog
Number
Height
(Inches)(Cm.)
Width
(Inches)(Cm.)
Depth
(Inches)(Cm.)
Weight
(Lbs.)(Kg.)
Mounting Type
(Wall)(Floor)
Knockouts
(Inches)(Cm.)
Optional
Electrostatic
Shield
Wiring
Diagrams
Design
Figures
3.0
②
T2A792681S 10.38 (26.4)
12.37 (31.4)
7.47 (19.0)
75 (34.0)
W
0.75-1.25 (1.9-3.2)
STD.
60
F
6.0
②
T2A792691S 11.83 (30.0)
14.17 (36.0)
8.82 (22.4)
140 (63.5)
W
0.75-1.25 (1.9-3.2)
STD.
60
F
9.0
②
T2A792701S 14.03 (36.0)
17.77 (45.1)
11.52 (29.3)
180 (81.6)
W
0.75-1.25 (1.9-3.2)
STD.
60
F
15.0
②
T3792711S 18.86 (48.0)
20.30 (51.6)
9.03 (22.9)
245 (111.0)
F
①
NA
STD.
60
I
15.0 T3015K0064BS 25.50 (64.8)
24.39 (61.9)
19.37 (49.2)
300 (136.0)
F
①
NA
STD.
61
E
30.0 T3030K0064BS 25.50 (64.8)
24.39 (61.9)
19.37 (49.2)
360 (163.2)
F
①
NA
STD.
61
E
45.0 T3045K0064BS 25.50 (64.8)
24.39 (61.9)
19.37 (49.2)
441 (200.0)
F
①
NA
STD.
61
E
75.0 T3075K0064BS 29.41 (74.7)
28.15 (71.5)
22.37 (56.8)
600 (272.2)
F
①
NA
STD.
61
E
①
Wall mounting brackets are available for these sizes, refer to page 217.
②
DOE 2016 exempt, encapsulated unit
All Wiring Diagrams begin on page 209.
208 DELTA PRIMARY VOLTS — 208Y120 SECONDARY VOLTS — 3Ø, 60 Hz NEMA 4X
kVA
Catalog
Number
Height
(Inches)(Cm.)
Width
(Inches)(Cm.)
Depth
(Inches)(Cm.)
Weight
(Lbs.)(Kg.)
Mounting Type
(Wall)(Floor)
Knockouts
(Inches)(Cm.)
Optional
Electrostatic
Shield
Wiring
Diagrams
Design
Figures
3.0
①
T3003K0061X
10.38 (26.3)
12.37 (31.4)
7.47 (18.9)
75 (34.0)
W
NA
NA
60
J
6.0
①
T3006K0061X
11.83 (30.0)
14.17 (35.9)
8.82 (22.4)
140 (63.5)
W
NA
NA
60
J
9.0
①
T3009K0061X
14.03 (35.6)
17.77 (45.1)
11.52 (29.2)
180 (81.6)
W
NA
NA
60
J
①
DOE 2016 exempt, encapsulated unit
