240 X 480 PRIMARY VOLTS — 120/240 SECONDARY VOLTS — FOUR WINDINGS — 1Ø, 60 Hz
kVA
Catalog
Number
Height
(Inches)(Cm.)
Width
(Inches)(Cm.)
Depth
(Inches)(Cm.)
Weight
(Lbs.)(Kg.)
Mounting Type
(Wall)(Floor)
Knockouts
(Inches)(Cm.)
Weather
Shield
Wiring
Diagrams
Design
Figures
.05
①
T153004
6.41 (16.3)
3.14 (8.0)
3.05 (7.7)
4 (1.8)
W
0.875 (2.2)
NA
1
A
.10
①
T153005
7.16 (18.2)
3.89 (9.9)
3.67 (9.3)
5 (2.3)
W
0.875 (2.2)
NA
1
A
.15
①
T153006
7.16 (18.2)
3.89 (9.9)
3.67 (9.3)
7 (3.2)
W
0.875 (2.2)
NA
1
A
.25
①
T253007S 8.68 (22.0)
4.08 (10.4)
3.88 (9.9)
10 (4.5)
W
0.50-0.75 (1.3-1.9)
NA
2
B
.50
①
T253008S 9.06 (23.0)
4.37 (11.1)
4.20 (10.7)
15 (6.8)
W
0.50-0.75 (1.3-1.9)
NA
2
B
.75
①
T253009S 9.68 (24.6)
4.75 (12.1)
4.50 (11.4)
19 (8.6)
W
0.50-0.75 (1.3-1.9)
NA
2
B
1.00
T253010S 10.50 (26.7)
5.50 (14.0)
5.13 (13.0)
24 (10.9)
W
0.50-0.75 (1.3-1.9)
NA
2
B
1.50
T253011S 11.62 (29.5)
5.50 (14.0)
5.13 (13.0)
30 (13.6)
W
0.50-0.75 (1.3-1.9)
NA
2
B
2.00
T253012S 13.00 (33.0)
5.50 (14.0)
5.13 (13.0)
38 (17.2)
W
0.50-0.75 (1.3-1.9)
NA
2
B
3.00
T253013S 11.50 (29.2)
10.31 (26.2)
7.13 (18.1)
55 (24.9)
W
0.75-1.25 (1.9-3.2)
NA
2
C
3.00 T2530134S 11.50 (29.2)
10.31 (26.2)
7.13 (18.1)
55 (24.9)
W
0.75-1.25 (1.9-3.2)
NA
3
C
5.00
T253014S 14.38 (36.5)
10.31 (26.2)
7.13 (18.1)
75 (34.0)
W
0.75-1.25 (1.9-3.2)
NA
2
C
5.00 T2530144S 14.38 (36.5)
10.31 (26.2)
7.13 (18.1)
75 (34.0)
W
0.75-1.25 (1.9-3.2)
NA
3
C
7.50 T2535153S 15.19 (38.6)
13.50 (34.3)
10.84 (27.5)
115 (52.2)
W
0.75-1.25 (1.9-3.2)
NA
4
D
10.00 T2535163S 15.19 (38.6)
13.50 (34.3)
10.84 (27.5)
125 (56.7)
W
0.75-1.25 (1.9-3.2)
NA
4
D
15.00 T2535173S 16.94 (43.0)
14.12 (35.9)
11.59 (29.4)
170 (77.1)
W
1.00-1.50 (2.5-3.8)
NA
4
D
25.00 T2535183S 18.44 (46.8)
16.13 (41.0)
13.34 (33.9)
250 (113.0)
W
1.00-1.50 (2.5-3.8)
NA
4
D
37.50 TP530193S 25.50 (64.8)
24.39 (61.9)
19.37 (49.2)
280 (127.0)
F
②
NA
WSA1
5
E
50.00 TP530203S 25.50 (64.8)
24.39 (61.9)
19.37 (49.2)
350 (158.8)
F
②
NA
WSA1
5
E
75.00 TP530213S 35.47 (90.1)
31.90 (81.0)
26.88 (68.3)
430 (195.0)
F
NA
WSA3
5
E
100.00 TP530223S 41.52 (105.4)
32.90 (83.5)
29.87 (75.9)
525 (238.0)
F
NA
WSA4
5
E
167.00 TP530233S 45.60 (115.8)
39.50 (100.3)
35.50 (90.1)
1050 (476.3)
F
NA
WSA5
5
E
250.00 TP530243S 45.60 (115.8)
39.50 (100.3)
35.50 (90.1)
1440 (653.2)
F
NA
WSA5
5
E
Notes: 0.05 through 25.0 kVA encapsulated (exempt from DOE 2016), 37.5 through 250.0 kVA DOE 2016 compliant
①
Suitable for 50/60Hz
②
Wall mounting brackets are available for these sizes, refer to page 217.
240 X 480 PRIMARY VOLTS — 120/240 SECONDARY VOLTS — FOUR WINDINGS — 1Ø, 60 Hz 316 STAINLESS STEEL
kVA
Catalog
Number
Height
(Inches)(Cm.)
Width
(Inches)(Cm.)
Depth
(Inches)(Cm.)
Weight
(Lbs.)(Kg.)
Mounting Type
(Wall)(Floor)
Knockouts
(Inches)(Cm.)
Weather
Shield
Wiring
Diagrams
Design
Figures
0.25
①
T253007SS 8.68 (22.0)
4.08 (10.4)
3.88 (9.9)
10 (4.5)
W
NA
NA
2
B
0.50
①
T253008SS 9.06 (23.0)
4.37 (11.1)
4.20 (10.7)
15 (6.8)
W
NA
NA
2
B
0.75
①
T253009SS 9.68 (24.6)
4.75 (12.1)
4.50 (11.4)
19 (8.6)
W
NA
NA
2
B
1.00 T253010SS 10.50 (26.7)
5.50 (14.0)
5.13 (13.0)
24 (10.9)
W
NA
NA
2
B
1.50 T253011SS 11.62 (29.5)
5.50 (14.0)
5.13 (13.0)
30 (13.6)
W
NA
NA
2
B
2.00 T253012SS 13.00 (33.0)
5.50 (14.0)
5.13 (13.0)
38 (17.2)
W
NA
NA
2
B
3.00 T253013SS 11.50 (29.2)
10.31 (26.2)
7.13 (18.1)
55 (24.9)
W
NA
NA
3
C
5.00 T253014SS 14.38 (36.5)
10.31 (26.2)
7.13 (18.1)
75 (34.0)
W
NA
NA
3
C
7.50 T253515SS 15.19 (38.6)
13.50 (34.3)
10.84 (27.5)
115 (52.2)
W
NA
NA
4
D
10.00 T253516SS 15.19 (38.6)
13.50 (34.3)
10.84 (27.5)
125 (56.7)
W
NA
NA
4
D
15.00 T253517SS 16.94 (43.0)
14.12 (35.9)
11.59 (29.4)
170 (77.1)
W
NA
NA
4
D
25.00 T253518SS 18.44 (46.8)
16.13 (41.0)
13.34 (33.9)
250 (113.0)
W
NA
NA
4
D
Notes: 0.25 through 25.0 kVA encapsulated (exempt from DOE 2016)
①
Suitable for 50/60Hz
All Wiring Diagrams begin on page 209.
