toll free 800.334.5214 ACME ELECTRIC |
hubbell-acmeelectric.comM e d i u m V o l t a g e T r a n s f o r m e r s
Selection Charts
SINGLE PHASE VOLTAGE SELECTION
XX
Primary Volts
Secondary
Volts
Wiring
Diagrams
01
2400
120/240
1
02
2400
240/480
1
03
2400
600
2
04
4160
120/240
1
05
4160
240/480
1
06
4160
600
2
07
4800
120/240
1
08
4800
240/480
1
09
4800
600
2
SINGLE PHASE, 60Hz, 2.5kV & 5kV CLASS, NEMA 1 ENCLOSED, DOE 2016
kVA
Catalog
Number
Height
(Inches)(Cm.)
Width
(Inches)(Cm.)
Depth
(Inches)(Cm.)
Weight
(Lbs.)(Kg.)
Mounting
Type
(Wall)(Floor)
Knockouts
(Inches)(Cm.)
Optional
Electrostatic
Shield
Design
Figures
15
WB015KXX
①
28.3 (71.8)
20.3 (51.5)
16.3 (41.4)
255 (115.6)
F
NA
NA
E
25
WC025KXX
①
34.8 (88.3)
26.3 (66.8)
22.3 (56.6)
320 (145.1)
F
NA
NA
E
37.5
WC037KXX
①
34.8 (88.3)
26.3 (66.8)
22.3 (56.6)
400 (181.4)
F
NA
NA
E
50
WC050KXX
①
34.8 (88.3)
26.3 (66.8)
22.3 (56.6)
530 (240.4)
F
NA
NA
E
75
WC075KXX
①
34.8 (88.3)
26.3 (66.8)
22.3 (56.6)
690 (312.9)
F
NA
NA
E
100
WC100KXX
①
40.8 (103.6)
32.3 (82.0)
28.3 (71.8)
800 (362.8)
F
NA
NA
E
167
WC167KXX
①
40.8 (103.6)
32.3 (82.0)
28.3 (71.8)
1100 (498.9)
F
NA
NA
E
250
WC250KXX
①
40.8 (103.6)
32.3 (82.0)
28.3 (71.8)
1500 (680.3)
F
NA
NA
E
333
WC333KXX
①
48.0 (121.9)
48.0 (121.9)
32.0 (81.2)
2000 (907.1)
F
NA
NA
E
500
WC500KXX
①
54.0 (137.1)
60.0 (152.4)
40.0 (101.6)
3200 (1451.4)
F
NA
NA
G
①
Add appropriate voltage number code to catalog number
Available with 3R Weathershield
