Shore Power Cord
• High visibility yellow jacket is oil and sunlight resistant.
• Ultra flexible insulation is abrasion resistant for
“hard service” applications.
• 600 volt rated for extra heavy-duty service.
• 16/3 is 300 volt cable.
Cable Size
Conductor
Colors
Spool
Length Item #
16/3 Phone Black, White,
Green
300'
153530
10/3 STOW Black, White,
Green
250'
153725
10/3 STW
Black, White,
Green
250'
SPC103
6/3 STOW
Black, White,
Green
250'
153925
per/ft**
100320
6/4 STW
Black, White,
Green, Red
per/ft**
100319
*SPC103, 100320 and 100319 are not tinned wire
**50 ft minimum
Cable Size
(AWG)
Nominal O.D. Wt. per 1000'
16/3 Phone 5/16"
6 mm
75 lbs
34 kg
10/3 STOW 21/32"
17 mm
284 lbs
129 kg
10/3 STW 21/32"
17 mm
284 lbs
129 kg
6/3 STOW 7/8"
22 mm
540 lbs
254.4 kg
6/4 STW 29/32"
23 mm
695 lbs
316 kg
Manage:
Wire & Cable
Premium Battery Cable Assemblies
UL-1426 Tinned Boat Cable
Ancor™ Marine Grade Standard Battery Cable Assemblies are manufactured
with Ancor’s premium UL1426 tinned copper battery cable. The battery cable
is fine stranded to produce maximum conductivity and flexibility. In addition, all
Ancor™ battery cable is flame retarded, UV inhibited, rated to 600V and 105˚C.
The lugs are tinned copper to avoid corrosion and last longer. Each end has a
piece of Ancor's adhesive lined 3:1 heatshrink tubing placed over the electrical
connection. The heatshrink tubing seals out moisture and other corrosive
elements found in the marine environment, and provides strain relief to ensure
a longer lasting battery connection.
For Continuous
Current Draws up to:
Use Battery Cable
Assemblies
136 amps
4 AWG
178 amps
2 AWG
Color Length
Stud Size
Item #
4 AWG
(21 mm
2
)
Black 18"
45.7 cm 5/16"
7.93 mm
189130
32"
81.2 cm 5/16"
7.93 mm
189134
48"
121.9 cm 5/16"
7.93 mm
189136
Red 18"
45.7 cm 3/8"
9.5 mm
189131
32"
81.2 cm 3/8"
9.5 mm
189135
48"
121.9 cm 3/8"
9.5 mm
189137
2 AWG
(34 mm
2
)
Black 18"
45.7 cm 5/16"
7.93 mm
189140
32"
81.2 cm 5/16"
7.93 mm
189144
48"
121.9 cm 5/16"
7.93 mm
189146
Red 18"
45.7 cm 3/8"
9.5 mm
189141
32"
81.2 cm 3/8"
9.5 mm
189145
48"
121.9 cm 3/8"
9.5 mm
189147
