Coaxial Cable Assemblies

PremiumTinned Copper

• All assemblies come with Ancor™ Adhesive Lined Heat Shrink to seal out

moisture, provide strain relief and fight corrosion.

• 96% Tinned copper braid for optimum protection against signal loss.

• 100% Tinned Copper Center Conductor and Braid

• One end pre-assembled coaxial cable packages for RG58 and RG8X come

with Ancor’s twist-on UHF plugs for easy installation.

• No solder or special tools required.

• Special low loss SAT NAV extensions.

Manage:

Wire & Cable

Wire Type

RG58C/U

RG59U

RG8X

RG213

Insulation Material

PVC*

PVC

PVC*

Nominal O.D.

3/16" / 4.8 mm 1/4" / 6.4 mm 1/4" / 6.4 mm 13/32" / 10.3 mm

AWG

Conductor Stranding 19/33

Solid**

19/29

7/21

Braid Coverage

96%

Wt. per 1000'

26 lbs / 11.8 kg 36 lbs / 16.3 kg 40 lbs / 18.1 kg 110 lbs / 50 kg

Impedance (Ohms)

Capacitance/Ft.

30.8 pF

20.5 pF

26.0 pF

30.8pF

Attenuation/100'

@50MHz

3.3db

2.4db

2.5db

1.3db

@100MHz

4.9db

3.4db

3.7db

1.9db

@1000MHz

21.5db

12.0db

13.5db

8.0db

Velocity of Propagation 66%

66%

78%

66%

* non-contaminating insulation ** copperweld

Ends Description

Wire

Length Item #

RG58CU

Two ends assembled 3'

189800

RG8X

One end assembled 50'

189849

Ancor Recommends

• RG 58CU for interconnecting electronic

equipment.

• RG 59U for TVs and some SAT NAVs.

• RG 8X for VHF runs less than 50 feet.

• Coaxial fittings page 227.

Spool

Length

Item #

RG 58CU

100'

150510

250'

150525

RG 59U

250'

151025

500'

151050

Spool

Length

Item #

RG 213

100'

151710

250'

151725

500'

151750

Spool

Length

Item #

RG 8X

100'

151510

250'

151525

500'

151550

1000'

151560

Coaxial Cable

PremiumTinned Copper

• Features signal loss ratios of up to 50% less than other coaxial cables.

• Tinned copper center conductor as well as tinned copper outer braid for

corrosion resistance and easy soldering.

• 96% braid for best signal strength and least interference with UV inhibited

white jacket for longest life.

Spool

Length

Item #

18/2 AWG

(2x0.8 mm

)

100'

142810

16/2 AWG

(2x1 mm

)

100'

142610

250'

142625

500'

142650

Spool

Length

Item #

14/2 AWG

(2x2 mm

)

100'

142410

250'

142425

1000'

142499

Cable Size

(AWG)

Nominal O.D. Wt. per 1000'

18/2

.265"

29 lbs

6.7 mm 13 kg

16/2

.319"

51 lbs

8.1 mm 23.1 kg

14/2

.345"

65 lbs

8.8 mm 29.5 kg

Super Flex Audio Cable

PremiumTinned Copper

• Super Flexible, easy to run. Clear jacket to blend into the environment.

• Drawn copper, unidirectional lay for ultimate in sound quality.

• Tinned copper for corrosion resistance in the marine environment.

Cable Size

(AWG)

Nominal O.D. Wt. per 1000'

RG 58CU 3/16"

26 lbs

4.8 mm 11.8 kg

RG 59U 1/4"

36 lbs

6.4 mm 16.3 kg

RG 8X

1/4"

40 lbs

6.4 mm 18.1 kg

RG 213 13/32"

110 lbs

10.3 mm 50 kg
