Heat Shrink Step-Down/Multi-Wire Connectors
Ancor’s new assortment of adhesive lined heat shrink butt connectors can be used as a
step-down from one gauge size to another or as a multi-wire connector for one gauge size
wire. These connectors offer a sealed alternative for products such as a quick-tap or 3-way
connector in areas where corrosion is a concern.
• 4:1 shrink ratio tubing to ensure a watertight seal between wires
• Flared barrel with uniform copper wall ensures an easy and proper mechanical crimp
• Crimp indicator on barrel for proper placement of installation tool
• Clear heat shrink tubing ensures crimp accuracy
• Colored stripes on the barrel indicate which crimp die to use, regardless of application
NEW
NEW
NEW
NEW
Universal Speaker Connector Kits
Marine speakers are equipped with male disconnects in two sizes
(.250 tab for positive and either .188 tab or .110 tab for negative)
depending on speaker manufacturer. Ancor’s new universal speaker
connector kits include (2) .250 tab, (2) .188 tab and (2) .110 tab
female adhesive lined heat shrink disconnects to allow a user to
install two speakers regardless of manufacturer. Female heat shrink
disconnects are the optimal connector for speaker installation as they
provide a sealed connection for the harsh marine environment.
AWG
Qty/
Pkg Item #
22–18
0.3–0.8 mm
2
6
SPK2218
16–14
1–2 mm
2
6
SPK1614
AWG
Pkg
Qty Item # Tubing Color
Crimp Die
(Color on Barrel)
Wire
24–22
0.2–0.3 mm
2
3
320003
Clear /
White Dashes
Side 1: White (24–22 AWG)
One 24-22 AWG
25
320025
Side 2: Red (22–18 AWG)
Two 24-22 AWG or One 22-18 AWG
22–18
0.3–0.8 mm
2
3
320103
Clear /
Red Dashes
Side 1: Red (22–18 AWG One 22-18 AWG
25
320125
Side 2: Blue (16–14 AWG)
Two 22-18 AWG or One 16-14 AWG
16–14
1–2 mm
2
3
320203
Clear /
Blue Dashes
Side 1: Blue (16–14 AWG)
One 16-14 AWG
25
320225
Side 2: Yellow (12–10 AWG)
Two 16-14 AWG or One 12-10 AWG
12–10
3–5 mm
2
3
320303
Clear /
Yellow Dashes
Side 1: Yellow (12–10 AWG)
One 12-10 AWG
25
320325
Side 2: Red (8 AWG)
Two 12-10 AWG or One 8 AWG
