Automatically adjust grid power to the onboard system
Mastervolt supplies three automatic switching systems for capacities of 6, 9 and 13 kW that—combined with an IVET transformer—
adjust grid power to the onboard system. As a result, a 230V/50Hz system can easily function with an American or Caribbean AC
connection. Do ensure that the frequency on board (50 or 60Hz) is the same as the frequency of the shore current.
Mass GI 3.5
Mass GI 7
IVET-D 16A
3.5 kVA multi tap
IVET 3.5*
Item #
88000355
88000705
86060351
85000350
Input
Input voltage
90–255V
90–255V
220–240V
(110–120V adjustable)
110/220/240V
Input frequency
45–65Hz
45–65Hz
45–65Hz
45–65Hz
Nominal input current at 230V
16A
32A
16A
16A
No load consumption
22 W
44 W
<10 W
<10 W
Earth leakage protection
no
no
no
no
Output
Output voltage (equal to input)
90–255V, ± 5%
90–255V, ± 5%
220–240V, ± 5%
(110–120V adjustable)
110/220/240V, ± 5%
Output frequency (equal to input)
45–65Hz
45–65Hz
45–65Hz
45–65Hz
Soft Start
yes
yes
yes
option
Switch off behaviour breaker
B-characteristic
B-characteristic
B-characteristic
n.a.
Efficiency
>93%
>93%
>93%
>93%
General Specifications
Power
3500 W (up to 4 units
parallel = 14 kW)
7000 W
3500 W
3500 W
Technology
high frequency
high frequency
torroidal
E-core
Dimensions, hxwxd
13.4"x10.3"x5.7"
340x261x144 mm
13.4"x10.3"x9.8"
340x261x250 mm
16"x11.6"x8.7"
407x295x220 mm
13"x7.9"x7.3"
330x200x185 mm
Weight
6 kg / 13.2 lbs
10 kg / 22 lbs
23 kg / 50.7 lbs
30 kg / 66.1 lbs
Ambient temperature
0–40°C, derating power > 40°C / 32–104°F, derating power > 104°F
Switch off at
80°C / 176°F
80°C / 176°F
120°C / 248°F
n.a.
Cooling
variofan
variofan
natural cooling, forced
cooling >80°C / 176°F
natural cooling
Operating humidity
max. 95%
max. 95%
max. 95%
max. 95%
Protection degree
IP23
IP23
IP23
IP00
MasterBus compatible
yes
yes no
no
Options
MasterView Easy
option
option
n.a.
n.a.
77010305
Convert:
Isolation Transformers Specifications
* Also available in 2.5 kW version, Item # 85000250.
** Also available in cabinet, Item # 86001000.
