Convert
|
DC–DC Converters
Magic as power supply
The Magic models can be fully used as a stabilised
power supply: From 12–24V, from 24–12V or from
24–24V. Inputs and outputs are galvanically isolated.
Mac & Magic as battery charger
A 12V starter or emergency power battery can be
charged as well as maintained by Mac or Magic
units. The charging method is identical to the Mass
3-step with voltage levels adjustable by means of
MasterBus PC-Link/MasterAdjust software.
Mac & Magic as dimmer
Light can be dimmed by means of a push button or
plus switch, with a maximum load of 250 Watt for the
Mac. A second Mac can be installed if there are
multiple lamps.
Magic 12/12-20
Magic 12/24-10
81300400
81300300
12V
12V
11–16V DC
11–16V DC
12–16V DC
12–16V DC
10V DC*
10V DC*
30 sec.*
30 sec.*
13.6V DC*
27.2V DC*
10–15V DC
20–28.5V DC
4–13V DC
8–26V DC
2% at extremes of temperatures, load and input
max. 1% peak peak
max. 1% peak peak
300 / 300 W
300 / 300 W
20A
10A
yes, up to 10
yes, up to 10
16A
8A
yes
yes
yes
yes
>90% (at nominal input voltage, full load); 92% peak
yes
yes
yes
yes
yes, by external momentary switch via fast-on connection, to be activated
by DIP-switch setting
yes (fast-on connector)
yes (fast-on connector)
8.9"x6.1"x3.2"
227x154x81 mm
8.9"x6.1"x3.2"
227x154x81 mm
1.8 kg / 4 lbs
1.8 kg / 4 lbs
CE
CE
yes (DIP switch settings)
yes (DIP switch settings)
<115 mA
<115 mA
screw terminals, maximum wire size 16 mm
2
/ AWG5
-25°C–80°C, >40°C derating / -13°F–176°F, >104°F derating
maintenance free vario fans
<48 dBA at 1 mtr
<48 dBA at 1 mtr
IP21
IP21
yes, in combination with a MasterBus Serial Interface (Item #
77030450
)
option
option
option
option
option
option
Convert:
Mac & Magic Specifications
