sperryinstruments.comNEW
IRT200 TEMP CHECK™
GUN STYLE INFRARED THERMOMETER
NON-CONTACT TEMPERATURE MEASUREMENT
Safety is the number one priority on any job site. Any test unit that can be used to measure or review an application without
coming in contact with a live conductor is a necessity. The NEWLY UPGRADED IRT-200 TempCheck™ Non-Contact Infrared
Thermometer allows for critical temperature measurements to be taken without having to touch an energized circuit. The D:S ratio,
or distance to spot ratio has been upgraded to 12:1, which is a rating used to state the distance, in feet, that the test unit should
be from the target in order to measure a one foot diameter section. We have also upgraded the temperature range to give an even
greater range of testing possibilities. Other upgraded features include adjustable emissivity and quicker response time.
IRT200
• Measures temperature without contacting an objects surface
• Fast and easy - provides results in seconds
• Laser pointer to guide accuracy
• Backlit screen for superior visibility in most applications
• 12:1 Distance to spot ratio
• Max hold reading on the display
• Auto power off
• Operates from (1) 9 volt battery, included
IRT200
Range
Temperature Range
-26˚F to 716˚F (-32˚C to 380˚C)
Accuracy
-32°C to 0°C; ± (2.5°C + .05°C / degree)
0°C to 100°C; ± 2.5°C, 100°C to 380°C ± 2.5%
-26°F to 32°F; ± 4.5°F + .09°F / degree
32°F to 212°F; ± 4.5°F, 212°F to 716°F ± 2.5%
Distance to Spot Ratio
12:1*
Response Time
500ms
Emissivity
0.1-1.0 (adjustable)
Spectral Response
6.5 to 18μM
Laser Pointer
Max Temperature Hold
Low Battery Indicator
Auto Shut-off
Data Hold
