sperryinstruments.comNEW
DSA1020TRMS
TRUE RMS 10 FUNCTION DIGITAL SNAP-AROUND
DSA1020TRMS
Range
Accuracy
AC Current
600A/ 1000A
±(2.5%+5)
DC Current
600A/ 1000A
±(2.5%+5)
AC Voltage
6V/ 60V/ 600V
±(1.5%+4)(50/60Hz)/
±(3.5%+5)(40~400Hz)
DC Voltage
600mV/ 6V/ 60V/ 600V
±(1.0%+3)
Resistance
600
1
/ 6k
1
/ 60k
1
±(1.2%+5)
600k
1
/ 6M
1
/ 60M
1
±(5.0%+8)
Capacitance
60nF
±(3.0%+50)
600nF/ 6uF/ 60uF/ 600uF
±(4.0%+20)
6mF
±10.0%
60mF
Undefined
Frequency
100Hz/ 1kHz
±(0.5%+5)
Temperature ˚C
-40˚ to 40˚C
40˚ to 1000˚C
± (2.8% + 6)
± (2.5% + 4)
Temperature ˚F
-40˚ to 104˚F
104˚ to 1832˚F
± (5% + 12)
± (4.5% + 8)
Duty Cycle
0.1%-99.9%
±(2.5%+5)
Diode Test
Continuity
• ETL listed to UL and
CSA standards
• Industry standard safety test leads
• Precise True RMS circuitry
• Recessed Input Terminals
• Electronic Overload Protection
• Non-contact voltage detection
• Relative delta displays changes in reading
• 1000 Amp AC/DC non-contact current reading
• Min/Max function to hold either minimum
reading or maximum reading on the display
• Data hold capability to maintain
reading on display
• Backlit 5999 Count LCD screen
• Bar graph
• Peak hold function to display in-rush current
• Capacitance and temperature
measurement functionality
• Auto power off functionality to save battery life
• Includes convenient carrying case
• Operates from (3) AAA batteries
, included
CONSTRUCTED WITH ALL THE ESSENTIAL FEATURES AND FUNCTIONS TO SAFELY OBTAIN ACCURATE READINGS
Engineered to exceed the expectations of the professional electrician the DSA1020TRMS is a 12 Function/ 29 range Digital Snap-Around
Clamp Meter with precise True RMS circuitry and a 1000 Amp non-contact current reading. Designed with integrated non-contact voltage
detection and a Min/Max data hold capable function which allows you to hold either minimum reading or maximum reading on the display.
This auto ranging unit measures up to 1000A AC/DC current, 600V AC/DC voltage, 60M
1
resistance, 1kHz frequency, non-contact AC voltage
detection, temperature from -40 to 1832˚F and capacitance to 60mF. Also able to test continuity, diodes, and duty cycle, this unit features a
backlit LCD display ideal for low light applications and an auto power of functionality to save battery life. We consider safety first, this instrument
has been designed, tested and certified to cETLus standards at CAT IV 600V and includes a limited lifetime warranty. Unit ships with test leads,
temp probe, carrying case and 3 AAA batteries (required for use).
DSA1020TRMS
600V
