Sperry Catalog 2017

33 / 52

|33 |
NEW
NEW
CLAMP METERS
DSA500A 7 FUNCTION & DSA540A 10 FUNCTION DIGITAL SNAP-AROUND
• ETL listed to UL
and CSA standards
• Industry standard safety test leads
• Recessed Input Terminals
• Electronic Overload Protection
• Non-contact voltage detection (DSA500)
• Relative delta displays changes
in reading (DSA540)
• 400 Amp non-contact current reading
• Data hold capability to maintain
reading on display
• Auto power off functionality to save battery life
• Compact lightweight design
• Includes convenient carrying case
• Operates from (3) AAA batteries, included
DSA500A
DSA540A Range Accuracy
AC Current
40A ±(3.0%+8)
400A 40.0-299.9A ±(3.5%+6)/
300.0-400.0A ±(4.0%+6)
AC Voltage 4V/ 40V/ 400V/ 600V ±(2.0%+5)
DC Voltage 400mV/ 4V/ 40V/ 400V/ 600V ±(1.5%+5) )
DC Current
40A ±(3.0%+8)
400A
40.0-299.9A ±(3.5%+6)/
300.0-400.0A ±(4.0%+6)
Resistance 4001/ 4k1/ 40k1/ 400k1/ 4M1/ 40M1 ±(2.0%+5)
Capacitance
50.00nF ±(4.0%+25)
500.0nF/ 5.000uF/ 50.00uF/ 100.0uF ±(4.0%+5)
Frequency
10Hz~1MHz ±(0.1%+3
10MHz Undefined
Diode Test
Continuity
DSA500A Range Accuracy
AC Current 200A/ 400A ±(2.0%+5)
AC Voltage 2V/ 20V/ 200V/ 600V ±(2.0%+5)
DC Voltage 200mV/ 2V/ 20V/ 200V/ 600V ±(1.5%+5)
Resistance 2001/ 2k1/ 20k1/ 200k1/ 2M1/ 20M1 ±(2.0%+5)
Diode Test
Continuity
DESIGNED TO BE SIMPLE TO USE WITH ADVANCED PERFORMANCE
The DSA540A Sperry Instruments Clamp Meter is a 10 function, 26 range auto-ranging unit with non-contact voltage detection
engineered to measure AC/DC Current (40-400A), AC/DC Voltage (400/600V), Resistance (400/40001), Frequency, and Continuity.
Advanced data management including relative measurement and data hold. Ships with carry case, heavy duty leads and three
AAA batteries included in the package.
DSA540A
300V 600V
