Sperry Catalog 2017

34 / 52

|34 |
NEW
DSA660 7 FUNCTION DIGITAL SNAP-AROUND
SAFELY PROVIDES FAST AND CLEAR READINGS EVERY TIME
The Sperry Instruments DSA660 measures current up to 600A AC and features non-contact voltage detection.
Accurately measures voltage, resistance and frequency. This unit features data hold, peak hold, and relative
functions to maintain the reading on it's backlit display. Ships with carry case, heavy duty leads and three
AAA batteries included in the package.
DSA660
• ETL listed to UL and CSA standards
• Industry standard safety test leads
• Recessed Input Terminals
• Electronic Overload Protection
• Non-contact voltage detection
• 600 Amp AC non-contact current reading
• Min/Max function to hold either minimum
reading or maximum reading on the display
• Data hold capability to maintain
reading on display
• Relative delta displays changes in reading
• Auto power off functionality to
save battery life
• Includes convenient carrying case
• Operates from (3) AAA batteries, included
DSA660 Range Accuracy
AC Current 60A/ 600A ±(2.0%+9)
AC Voltage 6V/ 60V/ 600V ±(1.5%+4)
DC Voltage 600mV/ 6V/ 60V/ 600V ±(1.0%+3)
Resistance
6001/ 6k1 / 60k1/ ±(1.2%+5)
600k1/ 6M1/ 60M1 ±(5.0%+8)
Frequency
100Hz ±(0.5%+4)/
1kHz (Undefined)
Duty Cycle 0.1%-99.9% –
Diode Test
Continuity
600V
