37 / 52
sperryinstruments.com
|
37
|
NEW
DSA2009TRMS
TRUE RMS 6 FUNCTION DIGISNAP™ DIGITAL SNAP-AROUND
CLAMP METERS
DSA2009TRMS
Range
Accuracy
AC Current
660.0A/ 2000A
±(2.5%+5)
AC Voltage
6.600V/ 66.00V/ 660.0V
±(1.2%+5)
1000V
±(1.5%+5)
DC Voltage
6.600V
±(0.8%+3)
66.00V/ 660.0V
±(0.8%+1)
1000V
±(1.0%+3)
DC Current
660.0A/ 2000A
±(2.5%+5)
Resistance
660.0
1
±(1.2%+2)
6.600k
1
/ 66.00k
1
/ 660.0k
1
±(1.0%+2)
6.600M
1
±(1.2%+2)
66.00M
1
±(1.5%+2)
Frequency
66.00Hz/ 660.0Hz/ 6.600kHz/ 66.00kHz/
660.0kHz/ 6.600MHz/ 20.00MHz
±(0.1%+3)
Diode Test
Continuity
ENGINEERED WITH SAFETY IN MIND TO LAST LONG AND ALWAYS REMAIN ACCURATE
The DSA2009TRMS features True RMS circuitry and measurement of up to 2000A AC/DC. Features low pass
filtering, InRush current, oscilloscope output, and a backlit display with bar graph to meet the toughest jobs head on.
CAT IV 600V rated with a lifetime warranty to ensure safety and reliability in the field. Ships with wrist strap, heavy
duty leads and 9V battery included in the package.
DSA2009TRMS
• ETL listed to UL and
CSA standards
• Industry standard safety test leads
• Precise True RMS circuitry
• Recessed Input Terminals
• Electronic Overload Protection
• Non-contact voltage detection
• 1000 AC/DC Amp non-contact
current reading
• Min/Max function to hold either minimum
reading or maximum reading on the display
• Data hold capability to maintain reading
on display
• Backlit 5999 Count LCD screen
• Peak Hold function to display in-rush current
• Auto power off functionality to
save battery life
• Includes convenient wrist strap
• Operates from (1) 9 volt battery, included
1000V
600V
