NEW
CLAMP METERS
DSA600TRMS
TRUE RMS 12 FUNCTION DIGITAL CLAMP METER
DURABLE, SAFE UNIT SUITED FOR A WIDE ARRAY OF ELECTRICAL APPLICATIONS
The Sperry Instruments DSA600TRMS 600A True RMS Clamp Meter has more features and functions without the extra
cost! This clamp meter offers a large range of superior functions including inrush current, a built-in work light, frequency and
advanced temperature measurement. This unit features data hold, peak hold, and relative functions to maintain the reading on
the 5999 count backlit screen and auto power-off functionality to extend battery life. Ships with carry case, heavy duty leads and
three AAA batteries included in the package.
DSA600TRMS
• ETL listed to UL and
CSA standards
• Industry standard safety test leads
• Precise True RMS circuitry
• Recessed Input Terminals
• Electronic Overload Protection
• Non-contact voltage detection
• Max reading hold
• 600A AC non-contact current reading
• Data hold capability to maintain
reading on display
• Auto power off functionality to save battery life
• Compact lightweight design
• Includes convenient carrying case
• Operates from (3) AAA batteries, included
DSA600TRMS
Range
Accuracy
AC Current
6A
± (3.5% + 20)
60A/ 600A
± (2.5% + 8)
AC Voltage
6V
± (1.2% + 5)
60V/ 600V
± (0.8% + 5)
DC Voltage
60mV/ 600mV/ 6V/ 60V/ 600V
± (0.5% + 5)
Resistance
600
1
± (0.8% + 10)
6k
1
/ 60k
1
/ 600K
1
± (0.8% + 3)
6M
1
/ 60M
1
± (1.2% + 3)
Capacitance
6nF/ 60nF/ 600nF/ 6μF/ 60μF/ 600μF
± (3% + 5)
Frequency
99.99Hz/ 999.9Hz/ 9.999kHz/ 9999HZ/
99.99kHz
± (.5% + 3)
Temperature ˚C
0˚ to 300˚C
301˚ to 1000˚C
± (1.0% + 3)
± (1.2% + 6)
Temperature ˚F
32˚ to 600˚F
601˚ to 1832˚F
± (1.2% + 6)
± (1.9% + 6)
InRush Current
6A
60A/600A
<20 Reference Only
± (5% + 60)
Duty Cycle
0.1–99.9%
± 3% + 5
Diode Test
Continuity
600 V
