toll free 800.334.5214 ACME ELECTRIC |
Selection Charts F i n g e r / G u a r d ® I n d u s t r i a l C o n t r o l T r a n s f o r m e r s
120 X 240 PRIMARY VOLTS — 24 SECONDARY VOLTS — 1Ø, 50/60 Hz
Approximate Dimensions (Inches)(Cm.) Mounting Slot
VA
Rating
Catalog
Number
European
Rating* A B C D E F
Approximate
Ship Weight
(Lbs.)(Kg.)
Wiring
Diagram
1000 FS11000 870 4.76 (12.1) 6.75 (17.1) 6.03 (15.3) 5.75 (14.6) 2.86 (7.3) .31 x .50 (0.8 x 1.3) 26 (11.8) A
240 X 480, 230 X 460, 220 X 440 PRIMARY VOLTS — 120/115/110 SECONDARY VOLTS — 1Ø, 50/60 Hz
Approximate Dimensions (Inches)(Cm.) Mounting Slot
VA
Rating
Catalog
Number
European
Rating* A B C D E F
Approximate
Ship Weight
(Lbs.)(Kg.)
Wiring
Diagram
1000 FS21000 870 4.76 (12.1) 6.75 (17.1) 6.03 (15.3) 5.75 (14.6) 2.86 (7.3) .31 x .50 (0.8 x 1.3) 26 (11.8) B
1500 FS21500 1290 6.01 (15.3) 6.75 (17.1) 6.03 (15.3) 5.75 (14.6) 4.13 (10.5) .31 x .50 (0.8 x 1.3) 38 (17.2) B
2000 FS22000 1680 6.51 (16.5) 6.75 (17.1) 6.03 (15.3) 5.75 (14.6) 4.63 (11.8) .31 x .50 (0.8 x 1.3) 44 (20.0) B
3000 FS23000 2465 7.44 (18.9) 7.50 (19.1) 6.68 (17.0) 6.50 (16.5) 6.47 (16.4) .41 x .81 (1.0 x 2.1) 60 (27.2) B
