PRIMARY FUSE SIZING CHART
RECOMMENDED RATING FOR CURRENT LIMITING CLASS CC FUSES
VA
120 V
208 V
230 V
240 V
277 V
380 V
416 V
440 V
460 V
480 V
550 V
600 V
50
1.2
0.6
0.6
0.6
0.6
0.3
0.3
0.3
0.3
0.3
0.3
0.3
75
1.9
1.0
1.0
1.0
0.8
0.6
0.6
0.6
0.5
0.5
0.4
0.4
100
2.5
1.5
1.3
1.3
1.0
0.8
0.8
0.6
0.6
0.6
0.6
0.5
150
3.8
2.0
2.0
1.9
1.5
1.2
1.2
1.0
1.0
1.0
0.8
0.8
250
3.5
3.5
3.5
3.0
3.0
2.0
1.8
1.8
1.5
1.5
1.4
1.2
300
4.0
4.0
4.0
3.5
3.0
2.5
2.5
2.0
2.0
1.9
1.5
1.5
350
5.0
5.0
4.5
4.0
4.0
2.5
2.5
2.5
2.0
2.0
1.9
1.8
500
7.0
4.0
3.5
3.5
5.5
4.0
3.5
3.5
3.5
3.0
3.0
2.5
750
10.0
6.0
5.5
5.0
4.5
6.0
5.5
5.0
5.0
5.0
4.0
4.0
SECONDARY FUSE SIZING CHART
RECOMMENDED RATING FOR CURRENT LIMITING MIDGET FUSES
VA
24 V
85 V
91 V
99 V
100 V
110 V
115 V
120 V
125 V
130 V
50 VA
3.2
0.9
0.9
0.8
0.8
0.7
0.7
0.6
0.6
0.6
75 VA
5.0
1.4
1.2
1.2
1.2
1.0
1.0
1.0
1.0
0.8
100 VA
6.0
1.5
1.5
1.5
1.5
1.5
1.5
1.2
1.2
1.2
150 VA
10.0
2.5
2.5
2.5
2.5
2.0
2.0
2.0
2.0
1.5
250 VA
12.0
4.5
4.5
4.0
4.0
3.5
3.5
3.0
3.0
3.0
300 VA
15.0
5.5
5.5
5.0
5.0
4.5
4.5
4.0
4.0
3.5
350 VA
20.0
6.5
6.0
5.5
5.5
5.0
5.0
4.5
4.5
4.5
500 VA
25.0
9.0
9.0
8.0
8.0
7.0
7.0
6.0
6.0
6.0
750 VA
40.0
12.0
12.0
12.0
12.0
10.0
10.0
10.0
10.0
9.0
CONNECTION DETAILS FOR AE05 & CE05
H1-H2
H1-H3
H1-H4
X1-X2
X1-X3
X1-X4
208
85
100
110
220
380
440
91
110
120
230
400
460
95
115
125
240
416
480
99
120
130
