toll free 800.334.5214 ACME ELECTRIC |
hubbell-acmeelectric.comA E / C E S e r i e s I n d u s t r i a l C o n t r o l T r a n s f o r m e r s
120 X 240 PRIMARY VOLTS — 24 SECONDARY VOLTS –– 1Ø, 50/60 Hz AE SERIES
Approximate Dimensions
(Inches)(Cm.)
Mounting Slot
VA
Rating
Catalog Number
A
B
C
D
E
F
Approximate
Ship Weight
(Lbs.)(Kg.)
50
AE010050
2.69 (6.8)
3.00 (7.6)
2.81 (7.1)
2.03 (5.1)
2.53 (6.4)
.20 x .40 (0.5 x 1.0)
2.50 (1.1)
75
AE010075
3.22 (8.1)
3.00 (7.6)
2.81 (7.1)
2.53 (6.4)
2.53 (6.4)
.20 x .40 (0.5 x 1.0)
3.50 (1.6)
100
AE010100
3.28 (8.3)
3.41 (8.6)
3.09 (7.8)
2.41 (6.1)
2.81 (7.1)
.20 x .40 (0.5 x 1.0)
4.05 (1.8)
150
AE010150
3.88 (9.8)
3.78 (9.6)
3.41 (8.6)
2.97 (7.5)
3.13 (7.9)
.20 x .40 (0.5 x 1.0)
6.50 (2.9)
250
AE010250
4.13 (10.4)
4.50 (11.4)
3.84 (9.7)
2.94 (7.4)
3.75 (9.5)
.20 x .40 (0.5 x 1.0)
9.25 (4.2)
350
AE010350
5.00 (12.7)
4.50 (11.4)
3.84 (9.7)
3.78 (9.6)
3.75 (9.5)
.20 x .40 (0.5 x 1.0)
12.75 (5.8)
500
AE010500
5.53 (14.0)
5.25 (13.3)
4.66 (11.8)
4.16 (10.5)
4.38 (11.1)
.31 x .69 (0.8 x 1.7)
19.00 (8.6)
750
AE010750
6.81 (17.3)
5.25 (13.3)
4.66 (11.8)
5.75 (14.6)
4.38 (11.1)
.31 x .69 (0.8 x 1.7)
26.00 (11.8)
200/220/440, 208/230/460, 240/480 PRIMARY VOLTS — 23/110, 24/115, 25/120 SECONDARY VOLTS — 1Ø, 50/60 Hz AE SERIES
Approximate Dimensions
(Inches)(Cm.)
Mounting Slot
VA
Rating
Catalog Number
A
B
C
D
E
F
Approximate
Ship Weight
(Lbs.)(Kg.)
50
AE020050
3.28 (8.3)
3.00 (7.6)
2.78 (7.0)
2.25 (5.7)
2.53 (6.4)
.20 x .40 (0.5 x 1.0)
3.0 (1.4)
75
AE020075
3.28 (8.3)
3.00 (7.6)
3.09 (7.8)
2.53 (6.4)
2.81 (7.1)
.20 x .40 (0.5 x 1.0)
4.0 (1.8)
100
AE020100
3.28 (8.3)
3.41 (8.6)
3.41 (8.6)
2.53 (6.4)
3.13 (7.9)
.20 x .40 (0.5 x 1.0)
4.0 (1.8)
150
AE020150
4.03 (10.2)
3.75 (9.5)
3.41 (8.6)
3.28 (8.3)
3.13 (7.9)
.20 x .40 (0.5 x 1.0)
7.0 (3.2)
250
AE020250
4.38 (11.1)
4.50 (11.4)
4.03 (10.2)
3.75 (9.5)
3.75 (9.5)
.20 x .40 (0.5 x 1.0)
9.0 (4.1)
300
AE020300
5.13 (13.0)
4.50 (11.4)
4.97 (12.6)
3.88 (9.8)
4.38 (11.1)
.31 x .69 (0.8 X 1.7)
11.0 (5.0)
350
AE020350
5.25 (13.3)
4.50 (11.4)
4.97 (12.6)
4.16 (10.5)
4.38 (11.1)
.31 x .69 (0.8 X 1.7)
13.0 (5.9)
500
AE020500
6.31 (16.0)
5.25 (13.3)
4.97 (12.6)
5.25 (13.3)
4.38 (11.1)
.31 x .69 (0.8 X 1.7)
19.0 (8.6)
750
AE020750
6.81 (17.3)
5.25 (13.3)
4.97 (12.6)
5.75 (14.6)
4.38 (11.1)
.31 x .69 (0.8 X 1.7)
27.0 (12.2)
208/230/460 PRIMARY VOLTS —115 SECONDARY VOLTS— 1Ø, 50/60 Hz AE SERIES
Approximate Dimensions
(Inches)(Cm.)
Mounting Slot
VA
Rating
Catalog Number
A
B
C
D
E
F
Approximate
Ship Weight
(Lbs.)(Kg.
50
AE070050
2.84 (7.2)
3.00 (7.6)
2.81 (7.1)
2.16 (5.4)
2.53 (6.4)
.20 x .40 (0.5 x 1.0)
2.6 (1.2)
100
AE070100
3.41 (6.6)
3.41 (8.6)
3.09 (7.8)
2.69 (6.8)
2.81 (7.1)
.20 x .40 (0.5 x 1.0)
4.2 (1.9)
150
AE070150
3.88 (9.8)
3.75 (9.5)
3.41 (8.6)
3.09 (7.8)
3.09 (7.8)
.20 x .40 (0.5 x 1.0)
6.7 (3.1)
250
AE070250
4.16 (10.5)
4.50 (11.4)
4.03 (10.2)
3.28 (8.3)
3.75 (9.5)
.20 x .40 (0.5 x 1.0)
9.5 (4.3)
350
AE070350
5.19 (13.1)
4.50 (11.4)
4.03 (10.2)
4.38 (11.1)
3.75 (9.5)
.20 x .40 (0.5 x 1.0)
13.4 (6.1)
500
AE070500
5.88 (14.9)
5.25 (13.3)
4.66 (11.8)
4.78 (12.1)
4.38 (11.1)
.31 x .69 (0.8 X 1.7)
19.0 (8.6)
750
AE070750
6.81 (17.3)
5.25 (13.3)
4.66 (11.8)
5.75 (14.6)
4.38 (11.1)
.31 x .69 (0.8 X 1.7)
27.0 (12.2)
