toll free 800.334.5214 ACME ELECTRIC |
hubbell-acmeelectric.comA E / C E S e r i e s I n d u s t r i a l C o n t r o l T r a n s f o r m e r s
Selection Charts
240 X 480, 230 X 460, 220 X 440 PRIMARY VOLTS —120/115/110 SECONDARY VOLTS — 1Ø, 50/60 Hz AE SERIES
Approximate Dimensions
(Inches)(Cm.)
Mounting Slot
VA
Rating
Catalog Number
A
B
C
D
E
F
Approximate
Ship Weight
(Lbs.)(Kg.
50
AE060050
2.69 (6.8)
3.00 (7.6)
2.81 (7.1)
2.03 (5.1)
2.53 (6.4)
.20 x .40 (0.5 x 1.0)
2.5 (1.1)
75
AE060075
3.22 (8.1)
3.00 (7.6)
2.81 (7.1)
2.53 (6.4)
2.53 (6.4)
.20 x .40 (0.5 x 1.0)
3.5 (1.6)
100
AE060100
3.28 (8.3)
3.41 (8.6)
3.09 (7.8)
2.41 (6.1)
2.81 (7.1)
.20 x .40 (0.5 x 1.0)
4.0 (1.8)
150
AE060150
3.88 (9.8)
3.84 (9.7)
3.41 (8.6)
2.97 (7.5)
3.13 (7.5)
.20 x .40 (0.5 x 1.0)
6.5 (2.9)
250
AE060250
4.13 (10.4)
4.50 (11.4)
3.84 (9.7)
2.94 (7.4)
3.75 (9.5)
.20 x .40 (0.5 x 1.0)
9.2 (4.2)
350
AE060350
5.00 (12.7)
4.50 (11.4)
3.84 (9.7)
3.78 (9.6)
3.75 (9.5)
.20 x .40 (0.5 x 1.0)
12.7 (5.8)
500
AE060500
5.53 (14.0)
5.25 (13.3)
4.66 (11.8)
4.16 (10.5)
4.34 (11.0)
.31 x .69 (0.8 X 1.7)
19.0 (8.6)
750
AE060750
6.81 (17.3)
5.25 (13.3)
4.66 (11.8)
5.75 (14.6)
4.31 (10.9)
.31 x .69 (0.8 X 1.7)
26.0 (11.8)
230/460/575 PRIMARY VOLTS — 95/115 SECONDARY VOLTS — 1Ø, 50/60 Hz AE SERIES
Approximate Dimensions
(Inches)(Cm.)
Mounting Slot
VA
Rating
Catalog Number
A
B
C
D
E
F
Approximate
Ship Weight
(Lbs.)(Kg.
50
AE120050
2.88 (7.3)
3.00 (7.6)
2.81 (7.1)
2.19 (5.5)
2.53 (6.4)
.20 x .40 (0.5 x 1.0)
2.6 (1.2)
100
AE120100
3.59 (9.1)
3.41 (8.6)
3.09 (7.8)
2.88 (7.3)
2.81 (7.1)
.20 x .40 (0.5 x 1.0)
4.2 (1.9)
150
AE120150
3.94 (10.0)
3.78 (9.6)
3.41 (8.6)
3.28 (8.3)
3.09 (7.8)
.20 x .40 (0.5 x 1.0)
6.8 (3.1)
250
AE120250
4.16 (10.5)
4.50 (11.4)
4.03 (10.2)
3.22 (8.1)
3.75 (9.5)
.20 x .40 (0.5 x 1.0)
9.5 (4.3)
350
AE120350
5.00 (12.7)
4.50 (11.4)
4.03 (10.2)
3.69 (9.3)
4.31 (10.9)
.20 x .40 (0.5 x 1.0)
13.2 (6.0)
500
AE120500
5.84 (14.8)
5.25 (13.3)
4.66 (11.8)
4.66 (11.8)
4.38 (11.1)
.31 x .69 (0.8 X 1.7)
19.2 (8.7)
750
AE120750
6.81 (17.3)
5.25 (13.3)
4.66 (11.8)
5.81 (14.7)
4.38 (11.1)
.31 x .69 (0.8 X 1.7)
27.0 (12.2)
240 X 480 PRIMARY VOLTS — 24 SECONDARY VOLTS — 1Ø, 50/60 Hz
AE SERIES
Approximate Dimensions
(Inches)(Cm.)
Mounting Slot
VA
Rating
Catalog Number
A
B
C
D
E
F
Approximate
Ship Weight
(Lbs.)(Kg.))
50
AE030050
2.69 (6.8)
3.00 (7.6)
2.81 (7.1)
2.03 (5.1)
2.53 (6.4)
.20 x .40 (0.5 x 1.0)
2.5 (1.1)
75
AE030075
3.22 (8.1)
3.00 (7.6)
2.81 (7.1)
2.53 (6.4)
2.53 (6.4)
.20 x .40 (0.5 x 1.0)
3.5 (1.6)
100
AE030100
3.28 (8.3)
3.41 (8.6)
3.09 (7.8)
2.41 (6.1)
2.81 (7.1)
.20 x .40 (0.5 x 1.0)
4.0 (1.8)
150
AE030150
3.88 (9.8)
3.84 (9.7)
3.41 (8.6)
2.97 (7.5)
3.13 (7.9)
.20 x .40 (0.5 x 1.0)
6.5 (2.9)
250
AE030250
4.13 (10.4)
4.50 (11.4)
3.84 (9.7)
2.94 (7.4)
3.75 (9.5)
.20 x .40 (0.5 x 1.0)
9.2 (4.2)
350
AE030350
5.00 (12.7)
4.50 (11.4)
3.84 (9.7)
3.78 (9.6)
3.75 (9.5)
.20 x .40 (0.5 x 1.0)
12.7 (5.8)
500
AE030500
5.53 (14.0)
5.25 (13.3)
4.66 (11.8)
4.16 (10.5)
4.34 (11.0)
.31 x .69 (0.8 X 1.7)
19.0 (8.6)
750
AE030750
6.81 (17.3)
5.25 (13.3)
4.66 (11.8)
5.75 (14.6)
4.38 (11.1)
.31 x .69 (0.8 X 1.7)
26.0 (11.8)
