Selection Charts A E / C E S e r i e s I n d u s t r i a l C o n t r o l T r a n s f o r m e r s
120 X 240 PRIMARY VOLTS –– 24 SECONDARY VOLTS — 1Ø, 50/60 Hz CE SERIES
Approximate Dimensions (Inches)(Cm.) Mounting Slot
VA
Rating Catalog Number A B C D E F
Approximate
Ship Weight
(Lbs.)(Kg.
50 CE010050 2.69 (6.8) 3.00 (7.6) 2.81 (7.1) 2.25 (5.7) 2.56 (6.5) .20 x .40 (0.5 x 1.0) 2.5 (1.2)
75 CE010075 3.22 (8.1) 3.41 (8.6) 2.81 (7.1) 2.25 (5.7) 2.88 (7.3) .20 x .40 (0.5 x 1.0) 3.5 (1.6)
100 CE010100 3.28 (8.3) 3.75 (9.5) 3.09 (7.8) 2.53 (6.4) 3.13 (7.9) .20 x .40 (0.5 x 1.0) 4.2 (1.9)
150 CE010150 3.88 (9.8) 4.50 (11.4) 3.41 (8.6) 2.53 (6.4) 3.84 (9.7) .20 x .40 (0.5 x 1.0) 6.6 (3.0)
250 CE010250 4.13 (10.4) 4.50 (11.4) 4.03 (10.2) 3.22 (8.1) 3.84 (9.7) .20 x .40 (0.5 x 1.0) 9.4 (4.3)
350 CE010350 5.00 (12.7) 5.25 (13.3) 4.03 (10.2) 3.75 (9.5) 4.50 (11.4) .31 x .69 (0.8 X 1.7) 13.0 (5.9)
500 CE010500 5.50 (13.9) 5.25 (13.3) 4.66 (11.8) 4.28 (10.8) 4.50 (11.4) .31 x .69 (0.8 X 1.7) 19.1 (8.7)
750 CE010750 7.03 (17.8) 5.25 (13.3) 4.66 (11.8) 5.75 (14.6) 4.50 (11.4) .31 x .69 (0.8 X 1.7) 26.6 (12.1)
200/220/440, 208/230/460, 240/480 PRIMARY VOLTS — 23/110, 24/115, 25/120 SECONDARY VOLTS –– 1Ø, 50/60 Hz CE SERIES
Approximate Dimensions (Inches)(Cm.) Mounting Slot
VA
Rating
Catalog Number A B C D E F
Approximate
Ship Weight
(Lbs.)(Kg.
50 CE020050 3.28 (8.3) 3.28 (8.3) 2.81 (7.1) 2.25 (5.7) 2.81 (7.1) .20 x .40 (0.5 x 1.0) 2.7 (1.2)
100 CE020100 4.03 (10.2) 3.75 (9.5) 3.13 (7.9) 3.22 (8.1) 3.16 (8.0) .20 x .40 (0.5 x 1.0) 4.3 (1.9)
150 CE020150 4.03 (10.2) 4.50 (11.4) 3.41 (8.6) 2.81 (7.1) 3.75 (9.5) .20 x .40 (0.5 x 1.0) 6.8 (3.0)
250 CE020250 4.78 (12.1) 4.50 (11.4) 4.03 (10.2) 4.06 (10.3) 3.75 (9.5) .20 x .40 (0.5 x 1.0) 9.7 (4.4)
350 CE020350 5.53 (14.0) 5.25 (13.3) 4.03 (10.2) 4.28 (10.8) 4.38 (11.1) .31 x .69 (0.8 X 1.7) 13.5 (6.1)
500 CE020500 7.25 (18.4) 5.25 (13.3) 4.69 (11.9) 6.00 (15.2) 4.38 (11.1) .31 x .69 (0.8 X 1.7) 19.6 (8.9)
750 CE020750 6.81 (17.3) 5.28 (13.4) 4.69 (11.9) 5.75 (14.6) 4.44 (11.2) .31 x .69 (0.8 X 1.7) 27.0 (12.2)
208, 220/380/440, 230/400/460, 240/416/480 PRIMARY VOLTS—
85/100/110, 91/110/120, 95/115/125, 99/120/130 SECONDARY VOLTS— 1Ø, 50/60 Hz CE SERIES
Approximate Dimensions (Inches)(Cm.) Mounting Slot
VA
Rating
Catalog Number A B C D E F
Approximate
Ship Weight
(Lbs.)(Kg..)
50 CE050050 4.03 (10.2) 3.41 (8.6) 3.09 (7.8) 2.47 (6.2) 2.81 (7.1) .20 x .40 (0.5 x 1.0) 2.7 (1.2)
150 CE050150 3.88 (9.8) 4.34 (11.0) 3.41 (8.6) 2.88 (7.3) 3.75 (9.5) .20 x .40 (0.5 x 1.0) 6.7 (3.0)
250 CE050250 5.13 (13.0) 4.50 (11.4) 4.03 (10.2) 4.38 (11.1) 3.75 (9.5) .20 x .40 (0.5 x 1.0) 9.5 (4.3)
350 CE050350 5.91 (15.0) 5.25 (13.3) 4.03 (10.2) 4.78 (12.1) 4.38 (11.1) .31 x .69 (0.8 X 1.7) 13.3 (6.0)
500 CE050500 5.91 (15.0) 5.25 (13.3) 4.66 (11.8) 4.63 (11.7) 4.38 (11.1) .31 x .69 (0.8 X 1.7) 19.0 (8.6)
750 CE050750 7.09 (18.0) 5.25 (13.3) 4.66 (11.1) 5.81 (14.7) 4.38 (11.1) .31 x .69 (0.8 X 1.7) 27.0 (12.2)
