hubbell-acmeelectric.comA c m e F i n g e r / G u a r d
®
I n d u s t r i a l C o n t r o l T r a n s f o r m e r s
The Acme FINGER/GUARD
®
line of Touch-Protected Industrial Control Transformers offers the most advanced and versatile
design concepts available to the marketplace today
They are designed to meet Acme’s rigid standards for mechanical durability as well as surpass Agency and Industry electrical
standards.The FINGER/GUARD
®
line is designed for all control applications and features integrally installed, durable molded
plastic terminations designed to protect against contact with live components. No slip-on plastic covers to be broken, lost or
misplaced.
All FINGER/GUARD
®
products use copper windings, high-permeability silicon steel cores and 130 degree C (Class B)
insulation. All FINGER/GUARD
®
products meet or exceed ANSI, IEC and NEMA standards. They are third party witness tested
and are UL Listed (File E79947), CSA Certified (File 7357) and CE Marked (to EN60742)...ON ALL SIZES. The product is
suitable for both 50 and 60 Hertz applications and is available in sizes ranging from 50 VA to 3000 VA.
Features
Q
Constructed with high quality silicon steel lamination to minimize core losses and increase efficiency.
Q
Designs incorporate precision wound coils for improved regulation.
Q
Copper windings on all groups.
Q
50 VA through 3000 VA sizes, 50/60 Hz.
Q
130°C (Class B) Insulation 80°C temperature rise.
Q
Voltage regulation exceeds NEMA requirements.
Q
UL Listed, CSA Certified and CE Marked.
Q
Attractive finish, nameplate, and design features enhance the end product.
Q
Ten-year limited warranty.
Q
Smaller, lighter weight design.
CEMARKING Series for Global Applications
The CE Marking, standing for Conformité Européene, is a European Mark of conformity indicating that a product or sys-
tem to which it is applied, complies with European law (Directives) regulating a necessary level of protection in Europe
with respect to safety, health, environmental and consumer protection; however, it is not intended as a guarantee of
quality for the consumer. The CE Marking must be applied to products being placed on the European market. The CE
Marking does allow a product to be moved freely within the internal market of the European Union.
The Directives that apply to Control or Power Distribution Transformers are:
Q
Low Voltage Directive,2006/95/EC
Q
Electromagnetic Compatibility (EMC) Directive,2004/108/EC
The stringent testing required to obtain a third party certification mark in many cases is significantly more rigid than
domestic requirements. This ensures that not only the Acme FINGER/GUARD
®
product, but all of our CE Marked prod-
ucts are designed to meet a higher level of safety standards than non-CE Marked products.
All Acme transformers are manufactured in a facility
certified by Underwriters Laboratories to ISO-9001.
Durable molded plastic
terminal is designed for
protection against contact
with live components
Easy to read nameplate
clearly identifies
important data
Easy access front opening in
terminal makes for fast wire
connections with one screw
Wide range of primary and
secondary voltages
