toll free 800.334.5214 ACME ELECTRIC |
hubbell-acmeelectric.comA E / C E S e r i e s I n d u s t r i a l C o n t r o l T r a n s f o r m e r s
Selection Charts
380/400/415 PRIMARY VOLTS— 110/220 SECONDARY VOLTS— 1Ø, 50/60 Hz CE SERIES
Approximate Dimensions
(Inches)(Cm.)
Mounting Slot
VA
Rating
Catalog Number
A
B
C
D
E
F
Approximate
Ship Weight
(Lbs.)(Kg.
50
CE040050
3.53 (8.9)
3.00 (7.6)
2.81 (7.1)
2.53 (6.4)
2.53 (6.4)
.20 x .40 (0.5 x 1.0)
2.6 (1.2)
100
CE040100
3.53 (8.9)
3.75 (9.5)
3.22 (8.1)
2.53 (6.4)
3.13 (8.0)
.20 x .40 (0.5 x 1.0)
4.3 (1.9)
150
CE040150
3.53 (8.9)
4.34 (11.0)
3.41 (8.6)
2.53 (6.4)
3.75 (9.5)
.20 x .40 (0.5 x 1.0)
6.7 (3.0)
250
CE040250
4.03 (10.2)
4.50 (11.4)
4.22 (10.7)
3.22 (8.1)
3.75 (9.5)
.20 x .40 (0.5 x 1.0)
9.4 (4.3)
350
CE040350
4.91 (12.4)
4.50 (11.4)
4.22 (10.7)
4.06 (10.3)
3.75 (9.5)
.20 x .40 (0.5 x 1.0)
13.0 (5.9)
500
CE040500
6.00 (15.2)
5.25 (13.3)
4.69 (11.9)
4.78 (12.1)
4.38 (11.1)
.31 x .69 (0.8 X 1.7)
18.8 (8.5)
750
CE040750
6.81 (17.3)
5.25 (13.3)
4.69 (11.9)
5.75 (14.6)
4.38 (11.1)
.31 x .69 (0.8 X 1.7)
26.0 (11.8)
240 X 480, 230 X 460, 220 X 440 PRIMARY VOLTS ––120/115/110 SECONDARY VOLTS— 1Ø, 50/60 Hz CE SERIES
Approximate Dimensions
(Inches)(Cm.)
Mounting Slot
VA
Rating
Catalog Number
A
B
C
D
E
F
Approximate
Ship Weight
(Lbs.)(Kg.)
50
CE060050
3.41 (8.6)
3.00 (7.6)
2.81 (7.1)
2.53 (6.4)
2.53 (6.4)
.20 x .40 (0.5 x 1.0)
2.6 (1.2)
75
CE060075
3.41 (8.6)
3.28 (8.3)
2.81 (7.1)
2.53 (6.4)
2.81 (7.1)
.20 x .40 (0.5 x 1.0)
3.6 (1.6)
100
CE060100
3.41 (8.6)
3.75 (9.5)
3.09 (7.8)
2.53 (6.4)
3.13 (7.9)
.20 x .40 (0.5 x 1.0)
4.3 (1.9)
150
CE060150
3.88 (9.8)
4.50 (11.4)
3.47 (8.8)
2.53 (6.4)
3.75 (9.5)
.20 x .40 (0.5 x 1.0)
6.7 (3.0)
250
CE060250
4.13 (10.4)
4.50 (11.4)
4.03 (10.2)
3.22 (8.1)
3.75 (9.5)
.20 x .40 (0.5 x 1.0)
9.4 (4.3)
300
CE060300
4.53 (11.5)
4.50 (11.4)
4.03 (10.2)
3.75 (9.5)
3.75 (9.5)
.20 x .40 (0.5 x 1.0)
10.9 (4.9)
350
CE060350
5.00 (12.7)
5.25 (13.3)
4.03 (10.2)
3.75 (9.5)
4.38 (11.1)
.31 x .69 (0.8 X 1.7)
13.0 (5.9)
500
CE060500
6.00 (15.2)
5.25 (13.3)
4.66 (11.8)
4.78 (12.1)
4.38 (11.1)
.31 x .69 (0.8 X 1.7)
18.8 (8.5)
750
CE060750
6.81 (17.3)
5.25 (13.3)
4.66 (11.8)
5.75 (14.6)
4.38 (11.1)
.31 x .69 (0.8 X 1.7)
26.0 (11.8)
240 X 480 PRIMARY VOLTS –– 24 SECONDARY VOLTS— 1Ø, 50/60 Hz
CE SERIES
Approximate Dimensions
(Inches)(Cm.)
Mounting Slot
VA
Rating
Catalog Number
A
B
C
D
E
F
Approximate
Ship Weight
(Lbs.)(Kg.
50
CE030050
3.00 (7.6)
3.00 (7.6)
2.81 (7.1)
2.25 (5.7)
2.53 (6.4)
.20 x .40 (0.5 x 1.0)
2.5 (1.1)
75
CE030075
3.28 (8.3)
3.28 (8.3)
2.81 (7.1)
2.25 (5.7)
2.81 (7.1)
.20 x .40 (0.5 x 1.0)
3.5 (1.6)
100
CE030100
3.28 (8.3)
3.75 (9.5)
3.09 (7.8)
2.53 (6.4)
3.13 (7.9)
.20 x .40 (0.5 x 1.0)
4.0 (1.8)
150
CE030150
3.88 (9.8)
4.50 (11.4)
3.47 (8.8)
2.53 (6.4)
3.75 (9.5)
.20 x .40 (0.5 x 1.0)
6.5 (2.9)
250
CE030250
4.13 (10.4)
4.50 (11.4)
4.03 (10.2)
3.22 (8.1)
3.75 (9.5)
.20 x .40 (0.5 x 1.0)
9.2 (4.2)
350
CE030350
5.00 (12.7)
5.25 (13.3)
4.03 (10.2)
3.75 (9.5)
4.38 (11.1)
.31 x .69 (0.8 X 1.7)
12.7 (5.8)
500
CE030500
5.53 (14.0)
5.25 (13.3)
4.66 (11.8)
4.28 (10.8)
4.38 (11.1)
.31 x .69 (0.8 X 1.7)
19.0 (8.6)
750
CE030750
7.03 (17.8)
5.25 (13.3)
4.66 (11.8)
5.41 (13.7)
4.38 (11.1)
.31 x .69 (0.8 X 1.7)
26.0 (11.8)
