AE/CE SERIES INDUSTRIAL CONTROLTRANSFORMERS
The Acme Electric AE and CE Series Industrial Control Transformers are designed specifically for machine tool control circuit
applications. These transformers have the ability to handle potentially damaging high in-rush currents that occur when
electromagnetic components are energized, without sacrificing the required stable output voltage. Designed to meet or
exceed the demands of international standards, combined with the full breadth of product offering, the AE and CE Series
Transformers from Acme Electric are the ideal solution for your industrial control applications.
Cooler. Cleaner. More Compact.
The AE and CE Series design improves the dissipation of the heat away from the core and coil assembly providing cooler
operation. In addition, the AE and CE Series industrial control transformers seal the transformer’s windings and internal
terminations within an epoxy encapsulant encased in a durable thermoplastic end cap, protecting them from potentially damaging
moisture, dirt and other ambient contaminants. Furthermore, Acme’s compact design helps minimize the mounting footprint,
providing more flexibility in applications where space is at a premium.
Features
Q
Epoxy encapsulated design protects core & coil assembly from potentially damaging contaminants
Q
Integrally molded terminal blocks with isolation barriers to prevent arc over, terminal blocks allow full access for ring
terminals for easy installation and solid termination
Q
Heavy gauge steel mounting feet
Q
Available factory or field installed fuse blocks provide
integral fusing on the primary or primary and secondary
Q
Dual labeling for easy product identification when equipped with a fuse block
Q
50-750 VA, 50/60 Hz
Q
UL and cUL Listed, CE Marked (CE Series only)
Q
Ten-year limited warranty
Q
55°C Temperature Rise
Q
105°C Insulation Class
CE Series for Global Applications
Acme’s CE Series Encapsulated Industrial Control Transformers carry the CE mark, indicating it complies with the requirements
established by the International Electrotechnical Commission (IEC) for use of control circuit transformers in the countries of the
European Union. Regulations that apply to control transformers include Low Voltage Directive 2006/95/EC and Electromagnetic
Compatibility (EMC) Directive 2004/108/EC.
