toll free 800.334.5214 ACME ELECTRIC |
Selection Charts T A a n d T B S e r i e s O p e n C o r e a n d C o i l I n d u s t r i a l C o n t r o l T r a n s f o r m e r s
600 PRIMARY VOLTS — 120/240 SECONDARY VOLTS — 1Ø, 60 Hz
Approximate Dimensions (Inches)(Cm.)
VA
Rating
Catalog
Number
Output Amps
@120V A B C D E F
Approximate
Ship Weight
(Lbs.)(Kg.))
Primary Fuse
Block Part
Number
Wiring
Diagram
50 TA83310 0.42 4.13 3.00 2.59 2.50 2.30 .22 x .50 4 PL112700 K
(10.5) (7.6) (6.6) (6.4) (5.8) (0.6 x 1.3) (1.8)
100 TA83311 0.83 4.90 3.00 2.59 2.50 3.35 .22 x .50 4 PL112700 K
(12.4) (7.6) (6.6) (6.4) (8.5) (0.6 x 1.3) (1.8)
150 TA83312 1.25 4.92 3.75 3.21 3.13 2.81 .22 x .50 6 PL112701 K
(12.5) (9.5) (8.2) (8.0) (7.1) (0.6 x 1.3) (2.7)
250 TA83313 2.08 5.38 4.50 3.84 3.75 3.05 .22 x .50 9 PL112702 K
(13.7) (11.4) (9.8) (9.5) (7.7) (0.6 x 1.3) (4.1)
500 TA83314 4.17 6.06 4.88 4.15 4.06 4.06 .22 x .50 13 PL112703 K
(15.4) (12.4) (10.5) (10.3) (10.3) (0.6 x 1.3) (5.9)
750 TA83315 6.25 6.43 5.25 4.47 4.38 4.00 .31 x .50 21 PL112704 K
(16.3) (13.3) (11.4) (11.1) (10.2) (0.8 x 1.3) (9.5)
1000 TA83316 8.33 7.34 6.75 5.72 5.75 3.69 .31 x .50 24 PL112705 K
(18.6) (17.1) (14.5) (14.6) (9.4) (0.8 x 1.3) (10.9)
TA & TB SERIES PROTECTIVE DEVICES— Primary Fuse Kits
FUSES ARE NOT INCLUDED. CONSULT CATALOG FOR PROPER FUSE SELECTION
Catalog Number Approximate Ship Weight
(Lbs.)(Kg.)
PL112700 1 (0.5)
PL112701 1 (0.5)
PL112702 1 (0.5)
PL112703 1 (0.5)
PL112704 1 (0.5)
PL112705 1 (0.5)
PL112706 1 (0.5)
PL112707 1 (0.5)
TB SERIES PROTECTIVE DEVICES — Secondary Fuse Kits
Catalog Number VA Description Approximate Ship Weight
(Lbs.)(Kg.)
PL79924 Fuse Kit: Secondary Fuse 1/4" x 1-1/4" w/ARM 1.0 (0.5)
PL79928 50–350 Link: Small Jumper Links (Qty. 2) 1.0 (0.5)
PL79929 500 & 750 Link: Large Jumper Links (Qty. 2) 1.0 (0.5)
PL79930 50–350 Fuse Kit: Secondary Fuse Midget w/ARM 1.0 (0.5)
PL79931 500 & 1000 Fuse Kit: Secondary Fuse Midget w/ARM 1.0 (0.5)
TA SERIES PROTECTIVE DEVICES — Secondary Fuse Kits
FOR USE WITH INDUSTRIAL CONTROL TRANSFORMERS THROUGH 1500 VA
Catalog Number Approximate Ship Weight
(Lbs.)(Kg.)
PL112600 0.5 (0.2)
PL112601 0.5 (0.2)
PL112602 1 (0.5)
PL112603 1 (0.5)
