hubbell-acmeelectric.comT A a n d T B S e r i e s O p e n C o r e a n d C o i l I n d u s t r i a l C o n t r o l T r a n s f o r m e r s
Selection Charts
240/416/480/600; 230/400/460/575; 220/380/440/550; 208/500 PRIMARY VOLTS
99/120/130; 95/115/125; 91/110/120; 85/100/110 SECONDARY VOLTS — 1Ø, 50/60 Hz
Approximate Dimensions
(Inches)(Cm.)
VA
Rating @
130V
Catalog
Number
Output
Amps
A
B
C D E
F
Approximate
Ship Weight
(Lbs.)(Kg.)
Primary Fuse
Block Part
Number
Secondary
Fuse Kit
PartNumber
Secondary
Fuse Size
130 Volts
Wiring
Diagram
50
TB32403
0.38
4.08 3.75 3.40 3.13 2.31 .22 x .50
5
PL112701
NA
6 /10 amp
G
(10.4)
(9.5)
(8.6)
(8.0)
(5.9)
(0.6 x 1.3)
(2.3)
150
TB32404
1.15
4.75 4.50 3.84 3.75 3.05 .22 x .50
10
PL112702
NA
1 6 /10 amps
G
(12.1)
(11.4)
(9.8)
(9.5)
(7.7)
(0.6 x 1.3)
(4.5)
250
TB32405
1.92
5.58 4.65 4.15 4.06 4.06 .22 x .50
16
PL112702
NA
3 2 /10 amps
G
(14.2)
(11.8)
(10.5)
(10.3)
(10.3)
(0.6 x 1.3)
(7.3)
350
TB32669
2.69
6.23 4.65 4.15 4.06 5.50 .22 x .50
22
PL112702
NA
4 amps
G
(15.8)
(11.8)
(10.5)
(10.3)
(14.0)
(0.6 x 1.3)
(10.0)
500
TB32406
3.85
6.40 6.75 5.78 5.75 3.69 .22 x .50
23
PL112705
NA
6 1 /4 amps
G
(16.3)
(17.1)
(14.7)
(14.6)
(9.4)
(0.6 x 1.3)
(10.4)
750
TB54523
5.77
7.08 6.75 5.78 5.75 4.13 .31 x .50
29
PL112705
NA
9 amps
G
(18.0)
(17.1)
(14.7)
(14.6)
(10.5)
(0.8 x 1.3)
(13.2)
1000
TB54524
7.69
8.56 6.75 5.78 5.75 4.88 .31 x .50
35
PL112705
NA
12 amps
G
(21.7)
(17.1)
(14.7)
(14.6)
(12.4)
(0.8 x 1.3)
(15.9)
1500
TA254525 11.54 6.75 7.50 7.66 6.50 5.42 .41 x .81
55
PL112706
PL-112601
20 amps
G
(17.1)
(19.1)
(19.5)
(16.5)
(13.8)
(1.0 x 2.1)
(24.9)
2000
TA281202 15.39 7.45 7.50 7.66 6.50 6.12 .41 x .81
55
PL112706
PL-112601
25 amps
G
(18.9)
(19.1)
(19.5)
(16.5)
(15.5)
(1.0 x 2.1)
(24.9)
3000
TA281203 23.08 7.02 11.92 8.83 6.75 5.75 .41 x .81
70
PL112707
—
—
G
(17.8)
(30.3)
(22.4)
(17.1)
(14.6)
(1.0 x 2.1)
(31.8)
5000
TA281205 38.46 7.52 11.92 9.49 6.75 6.25 .41 x .81
110
PL112707
—
—
G
(19.1)
(30.3)
(24.1)
(17.1)
(15.9)
(1.0 x 2.1)
(49.9)
CONNECTION DETAILS FOR WIRING DIAGRAM G
Output Volts
H1-H2
H1-H3
H1-H4
H1-H5
X1-X2
X1-X3
X1-X4
208
––
––
500
85
100
110
220
380
440
550
91
110
120
230
400
460
575
95
115
125
240
416
480
600
99
120
130
